Printed in Japan
200011(V)
VICTOR COMPANY OF JAPAN, LIMITED
AUDIO & COMMUNICATION BUSINESS DIVISION
PERSONAL & MOBILE NETWORK BUSINESS UNIT. 10-1,1Chome,Ohwatari-machi,Maebashi-city,371-8543,Japan
No.20882
FS-SD58V / FS-SD78V / FS-SD98V
42
44
Table of Contents
Service Manual
1
Table of Contents
1
Important for Laser Products
3
Preventing Static Electricity
4
Dismantling and Assembling the Traverse Unit
5
Disassembly Method
6
Maintenance of Laser Pickup
15
Replacement of Laser Pickup
15
Flow of Functional Operation until TOC Read
16
Method of Connecting
17
Description of Major Ics
18
Block Diagram
36
Printed Circuit Boards
50
Parts List
54
Exploded View of General Assembly and Parts List
56
Electrical Parts List
59
Fs-Sd58V
68
Packing Materials and Accessories Parts List
68
Fs-Sd78V/Fs-Sd98V
69
Fs-Sd58V
70
Fs-Sd78V / Fs-Sd98V
71
