JVC FS-SD58V - Electrical Parts List

FS-SD58V/FS-SD78V/FS-SD98V
3-6
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
A
C 1 NCB31HK-223X C CAPACITOR
C 2 NCB31HK-102X C CAPACITOR
C 3 NCB31CK-473X C CAPACITOR
C 4 NCB31HK-103X C CAPACITOR
C 5 QEK41CM-106 E CAPACITOR 10MF 20% 16V
C 6 NCB31HK-102X C CAPACITOR
C 9 NCB31HK-102X C CAPACITOR
C 12 NDC31HJ-100X C CAPACITOR
C 13 NCB31CK-473X C CAPACITOR
C 14 NCB31HK-103X C CAPACITOR
C 21 NCB31CK-473X C CAPACITOR
C 30 QEK41CM-476 E.CAPACITOR 47MF 20% 16V
C 32 NCB31HK-102X C CAPACITOR
C 33 QEKC1AM-107Z E.CAPACITOR 100MF 20% 10V
C 34 NDC31HJ-150X C CAPACITOR
C 35 NCB31HK-102X C CAPACITOR
C 36 QEK41CM-106 E CAPACITOR 10MF 20% 16V
C 37 NCB31CK-473X C CAPACITOR
C 39 NCB31CK-473X C CAPACITOR
C 40 NCB31HK-103X C CAPACITOR
C 41 QEKC1HM-104Z E CAPACITOR .10MF 20% 50V
C 42 QEK41HM-474 E CAPACITOR .47MF 20% 50V
C 44 NDC31HJ-221X C CAPACITOR
C 45 QEKC1HM-335Z E CAPACITOR 3.3MF 20% 50V
C 46 NCB31HK-223X C CAPACITOR
C 47 NCB31HK-103X C CAPACITOR
C 49 NCB31EK-183X C CAPACITOR
C 50 NCB31EK-183X C CAPACITOR
C 51 QEKC1HM-475Z E.CAPACITOR 4.7MF 20% 50V
C 52 QEKC1HM-475Z E.CAPACITOR 4.7MF 20% 50V
C 60 QEKC1AM-107Z E.CAPACITOR 100MF 20% 10V
C 61 NDC31HJ-120X C CAPACITOR
C 62 NDC31HJ-120X C CAPACITOR
C 63 NCB31CK-473X C CAPACITOR
C 65 NCB31HK-102X C CAPACITOR
C 66 NDC31HJ-151X C CAPACITOR
C 67 NDC31HJ-101X C.CAPACITOR
C 68 NDC31HJ-101X C.CAPACITOR
C 69 QEKC1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 70 NCB31HK-392X C CAPACITOR
C 71 QEKC1HM-335Z E CAPACITOR 3.3MF 20% 50V
C 72 NCB31HK-102X C CAPACITOR
C 91 NCB31HK-103X C CAPACITOR
CF 1 QAX0419-001Z C FILTER FM IF
CF 2 QAX0419-001Z C FILTER FM IF
CF 3 QAX0418-001Z C FILTER
CF 4 QAX0409-001 CERA LOCK
CN101 QGF1201F3-08 CONNECTOR TO.FUNC.
CN102 QGA2501C1-06 6P CONNECTOR TO.PO.
CN103 QGB1216J1-08S CONNECTOR TO.FRONT
CN104 QGF1201F3-09 CONNECTOR TO.MICOM
CN105 QGF1201F3-20 FFC/FPC CONNE TO.MICOM
CN106 QGA2501C1-02 2P CONNECTOR TO.MOTOR
CN181 QGA2001C1-02 PLUG ASSY
CN191 QGA7901C1-02 CONNECTOR UF
A
PRI.
CN191 QGA7901C1-04 CONNECTOR UB,US
A
CN192 QGA3901C1-04 4P CONNECTOR SEC.
CN193 QGA2501C1-07 7P CONNECTOR
A
TO.PO.
CN301 QGA2501F1-04 CONNECTOR FROM SP.JACK
CN801 QGB1216K1-08S CONNECTOR TO AMP/TUNER
CN802 QGB1216K1-14S CONNECTOR TO MICON/CD
CN803 QGA2001C1-02 PLUG ASSY TO BACK LIGHT
CP191 ICP-N15-T ICP I/M
A
VCD5V
C1102 QFVJ1HJ-224Z MF CAPACITOR FS-SD98V/78V
C1102 QFVJ1HJ-154Z MF CAPACITOR FS-SD58V
C1103 QFN31HJ-823Z MYLAR CAPACITOR FS-SD58V/78V
C1103 QFVJ1HJ-563Z MF CAPACITOR FS-SD98V
C1104 QFVJ1HJ-563Z MF CAPACITOR FS-SD98V
C1104 QFN31HJ-823Z MYLAR CAPACITOR FS-SD58V/78V
C1105 QTE1C06-476Z E CAPACITOR AHB
C1106 QTE1C06-226Z E CAPACITOR AHB
C1107 QETN1HM-475Z E CAPACITOR HP
C1108 NDC31HJ-151X C CAPACITOR HP
C1109 NCB31HK-562X C CAPACITOR HP
C1110 NCB31HK-102X C CAPACITOR
C1111 NCB31HK-182X C CAPACITOR AHB/*
C1202 QFVJ1HJ-224Z MF CAPACITOR FS-SD98V/78V
C1202 QFVJ1HJ-154Z MF CAPACITOR FS-SD58V
C1203 QFN31HJ-823Z MYLAR CAPACITOR FS-SD58V/78V
C1203 QFVJ1HJ-563Z MF CAPACITOR FS-SD98V
C1204 QFVJ1HJ-563Z MF CAPACITOR FS-SD98V
C1204 QFN31HJ-823Z MYLAR CAPACITOR FS-SD58V/78V
C1205 QTE1C06-476Z E CAPACITOR AHB
C1206 QTE1C06-226Z E CAPACITOR AHB
C1207 QETN1HM-475Z E CAPACITOR HP
C1208 NDC31HJ-151X C CAPACITOR HP
C1209 NCB31HK-562X C CAPACITOR HP
C1210 NCB31HK-102X C CAPACITOR
C1211 NCB31HK-182X C CAPACITOR AHB/*
C1301 QETN1CM-106Z E CAPACITOR AHB
C1302 QEK41CM-476 E.CAPACITOR AHB
C1303 QTE1C06-226Z E CAPACITOR AHB
C1304 QEKC1HM-105Z E.CAPACITOR AHB
C1305 QETN1EM-107Z E CAPACITOR HP
C1306 QETN1CM-476Z E CAPACITOR HP
C1307 QETN1CM-106Z E CAPACITOR HP.MUTE.D
C1308 QETN1CM-106Z E CAPACITOR S.MUTE.D
C1801 QETN1EM-106Z E CAPACITOR M.DRIVE
C1802 QETN1EM-107Z E CAPACITOR M.DRIVE
C1803 NCB31HK-102X C CAPACITOR M.DRIVE
C1901 QFVF1HJ-104Z MF CAPACITOR
A
HV
C1902 QFVF1HJ-104Z MF CAPACITOR
A
HV
C1903 QFVF1HJ-104Z MF CAPACITOR
A
HV
C1904 QFVF1HJ-104Z MF CAPACITOR
A
HV
C1905 QFVF1HJ-104Z MF CAPACITOR
A
LV
C1906 QFVF1HJ-104Z MF CAPACITOR
A
LV
C1907 QFVF1HJ-104Z MF CAPACITOR
A
LV
C1908 QFVF1HJ-104Z MF CAPACITOR
A
LV
C1910 QETM1EM-828 E CAPACITOR
A
HV
C1911 QETM1EM-688 E CAPACITOR
A
LV
C1912 NDC31HJ-221X C CAPACITOR SW10
C1913 NCB31HK-103X C CAPACITOR SW10
C1914 QETN1EM-476Z E CAPACITOR SW10
C1915 QEKC1CM-107Z E.CAPACITOR L.FIL
C1916 NDC31HJ-221X C CAPACITOR CD6.5
C1917 NCB31HK-103X C CAPACITOR CD6.5
C1918 QTE1C03-476Z E CAPACITOR CD6.5
C1919 QETN1CM-106Z E CAPACITOR BL7
C1920 QETN1EM-226Z E CAPACITOR BL7
C1921 QFVJ1HJ-104Z MF CAPACITOR US5
C1922 QETN1EM-106Z E CAPACITOR US5
C1923 QEKC1HM-475Z E.CAPACITOR TU5
C1924 QEKC1CM-107Z E.CAPACITOR TU5
C1925 QFZ0160-223Z PP CAPA IM FS-SD98V
C1925 QFN31HJ-103Z M.M.CAPACITOR FS-SD58V/78V
C1926 QCBB1HK-103Y C CAPACITOR
A
LV
(Main board)
Item
Parts number Parts name Area
Remarks
A
