FS-SD58V/FS-SD78V/FS-SD98V
3-7
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
A
C1927 QCBB1HK-103Y C CAPACITOR
A
HV
C1928 QCBB1HK-103Y C CAPACITOR RY
C1929 NCB31HK-103X C CAPACITOR RY
C1930 NDC31HJ-151X C CAPACITOR VCD5V
C1931 QETN1EM-107Z E CAPACITOR VCD5V
C1932 QEK41CM-106 E CAPACITOR FAN CONTROL
C3101 QTE1V06-106Z E CAPACITOR IN
C3102 QDGB1HK-681Y C CAPACITOR FS-SD78V/98V
C3102 QDGB1HK-821Y C CAPACITOR FS-SD58V
C3103 QCBB1HK-104Y TF CAPACITOR OUT
C3104 QCBB1HK-104Y TF CAPACITOR OUT
C3105 QFN31HJ-332Z M CAPACITOR E.ONLY
C3201 QTE1V06-106Z E CAPACITOR IN
C3202 QDGB1HK-681Y C CAPACITOR FS-SD78V/98V
C3202 QDGB1HK-821Y C CAPACITOR FS-SD58V
C3203 QCBB1HK-104Y TF CAPACITOR OUT
C3204 QCBB1HK-104Y TF CAPACITOR OUT
C3205 QFN31HJ-332Z M CAPACITOR E.ONLY
C3301 QETN1CM-106Z E CAPACITOR BEEP
C3302 NCS21HJ-152X C CAPACITOR
C3303 QCBB1HK-104Y TF CAPACITOR FS-SD98V
C3303 QCBB1HK-103Y CER.CAPACITOR-S FS-SD58V/78V
C3304 QETN1HM-105Z E CAPACITOR
A
1.0MF 20% 50V
C3306 QTE1E06-476Z E CAPACITOR FS-SD98V
C3306 QCBB1HK-103Y CER.CAPACITOR-S FS-SD58V/78V
C3308 QETN1CM-336Z E CAPACITOR ON.TIME
C3309 QETN1HM-105Z E CAPACITOR AHB NF
C3310 QETN1HM-105Z E CAPACITOR AHB NF
C3311 QCBB1HK-473Y C CAPACITOR AHB NF
C3312 QCBB1HK-473Y C CAPACITOR AHB NF
C3313 QETN1EM-227Z E CAPACITOR
A
FOR VH
C8001 NCB31HK-103X C CAPACITOR
C8002 QER41AM-107 E CAPACITOR 100MF 20% 10V
C8003 NCB31HK-223X C CAPACITOR
C8004 NDC31HJ-101X C.CAPACITOR
C8005 NCB31HK-103X C CAPACITOR
C8101 QETN1AM-107Z E CAPACITOR 100MF 20% 10V
C8102 NCB31HK-103X C CAPACITOR
C8201 QETN1AM-107Z E CAPACITOR 100MF 20% 10V
C8202 NCB31HK-103X C CAPACITOR
D 1 1SS133-T2 SI DIODE
D 2 1SS133-T2 SI DIODE
D 3 1SS133-T2 SI DIODE
D 4 1SS133-T2 SI DIODE
DI801 QLD0120-001 LCD
D1301 1SS133-T2 SI DIODE AHB
D1302 MTZJ5.1A-T2 ZENER DIODE AHB
D1303 1SS133-T2 SI DIODE AHB
D1304 1SS133-T2 SI DIODE HP.MUTE
D1305 1SS133-T2 SI DIODE S.MUTE
D1801 DSK10C-T1 DIODE M.DRIV
D1901 D5SBA20-S1 SI DIODE
A
HV
D1902 D3SBA20-S1 DIODE
A
LV
D1903 1SS133-T2 SI DIODE SW10
D1904 MTZJ5.6C-T2 ZENER DIODE SW10
D1905 MTZJ10A-T2 ZENER DIODE SW10
D1906 MTZJ11A-T2 Z.DIODE I.M L.FIL
D1907 1SS133-T2 SI DIODE L.FIL
D1908 1SS133-T2 SI DIODE CD6.5
D1909 MTZJ6.8B-T2 NER DIODE CD6.5
D1910 6A10E2 SI DIODE
A
LV
D1911 MTZJ6.8A-T2 ZENER DIODE BL8
D1912 MTZJ10A-T2 ZENER DIODE
A
BL8
D1913 MTZJ6.8B-T2 NER DIODE
A
US5V
D1914 MTZJ3.9B-T2 Z DIODE IM TU5
D1915 1SS133-T2 SI DIODE TU5
D1916 1SS133-T2 SI DIODE TU5
D1917 1SS133-T2 SI DIODE RY
D1918 1SS133-T2 SI DIODE VCD5V
D1919 MTZJ5.6C-T2 ZENER DIODE VCD5V
D1921 MTZJ6.8A-T2 ZENER DIODE
A
VCD5V
D1922 MTZJ8.2B-T2 DIODE VCD5V/*
D1923 RB160L-40-X SB DIODE VCD5V
D3302 1SS133-T2 SI DIODE AHB NF
D3303 1SS133-T2 SI DIODE AHB NF
D8001 SPR-39MVWF LED POWER/STANDBY
D8002 1SS133-T2 SI DIODE
D8003 1SS133-T2 SI DIODE
D8004 1SS133-T2 SI DIODE
D8021 TLYH156P/ST/ LED FS-SD98V
D8021 SELU1E50CM LED FS-SD58V/78V
D8022 SELU1E50CM LED FS-SD58V78V
D8022 TLYH156P/ST/ LED FS-SD98V
D8025 MTZJ10C-T2 ZENER DIODE FS-SD58V/78V
D8031 TLYH156P/ST/ LED FS-SD98V
D8031 SELU1E56BM LED FS-SD58V/78V
D8032 SELU1E56BM LED FS-SD58V/78V
D8032 TLYH156P/ST/ LED FS-SD98V
D8035 MA3100/M/-X ZENER DIODE FS-SD58V/78V
EP131 QNZ0136-001Z EARTH PLATE
IC 1 TA2057N IC
IC 2 LC72136N IC
IC101 NJM4580D-D IC AHB
IC102 BA15218F-XE IC HP
IC108 TA8409F-W IC M.DRIVE
IC191 UPC78L05J-T I C
A
US5
IC301 LA4905 IC
A
IC801 GP1U271X RM RECIVER
J 1 QNB0014-001 ANT TERMINAL AM/FM ANT COAX
J1901 QNC0030-001 AC INLET
A
J3001 QNB0092-001 SPK TERMINAL
J8301 QNS0162-001 JACK HP.JACK
K1801 QQR0779-001Z INDUCTOR
K8301 QQR0601-001Z FERRITE BEADS
L 1 QQR0796-001 COIL BLOCK MW RF/OSC
L 4 QQL231K-221Y INDUCTOR
LF191 QQR1145-001 LINE FILTER
A
EXCEPT J
LF311 QQR0797-002 INDUCTOR E.ONLY
LF321 QQR0797-002 INDUCTOR E.ONLY
L1801 QQL25CK-221Z INDUCTOR M.DRIVER
L1901 QQL28AK-101 CHOKE COIL VCD5V
L8101 QQL231K-470Y INDUCTOR
L8201 QQL231K-470Y INDUCTOR
PP101 QZW0038-001 WIRE CLAMP
PP102 QZW0038-001 WIRE CLAMP
Q
1 2SC2668/O/-T TRANSISTOR
Q
6 DTA114YKA-X TRANSISTOR
Q
7 2SA1037AK/R/-X TRANSISTOR
Q
8 2SA1037AK/R/-X TRANSISTOR
Q
1101 2SD2114K/VW/-X CHIP TR.C.M AHB
Q
1102 2SC2412K/R/-X TRANSISTOR HP.MUTE
Q
1201 2SD2114K/VW/-X CHIP TR.C.M AHB
Q
1202 2SC2412K/R/-X TRANSISTOR HP.MUTE
Q
1301 DTA123EKA-X DIGITAL.TR S.MUTE.D
Q
1302 DTA123EKA-X DIGITAL.TR HP.MUTE.D
Q
1801 DTC143EKA-X DIGI TRANSISTOR M.DRIV
(Main board)
Item
Parts number Parts name Area
Remarks
A
