FS-SD58V/FS-SD78V/FS-SD98V
3-8
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
A
Q
1901 2SA1359/OY/ TRANSISTOR
A
SW10
Q
1902 2SC2412K/R/-X TRANSISTOR SW10
Q
1903 2SC2412K/R/-X TRANSISTOR SW10
Q
1904 2SA1037AK/R/-X TRANSISTOR SW10
Q
1905 DTA144TKA-X TRANSISTOR SW10
Q
1906 DTC144TKA-X TRANSISTOR SW10
Q
1907 2SD2144S/VW/-T TRANSISTOR L.FIL
Q
1908 2SA1359/OY/ TRANSISTOR
A
CD6.5
Q
1909 2SC2412K/R/-X TRANSISTOR CD6.5
Q
1910 2SC2412K/R/-X TRANSISTOR
A
CD6.5
Q
1912 2SA1175/FE/-T TRANSISTOR
A
BL7
Q
1913 2SC2412K/R/-X TRANSISTOR BL7
Q
1914 2SA1037AK/R/-X TRANSISTOR
A
TU5
Q
1915 2SC2412K/R/-X TRANSISTOR TU5
Q
1916 2SA934/QR/-T TRANSISTOR
A
VCD5V
Q
1917 2SC2785/FE/-T TRANSISTOR
A
VCD5V
Q
1918 2SC2412K/R/-X TRANSISTOR VCD5V
Q
1920 2SA1037AK/R/-X TRANSISTOR FAN CONTROL
Q
1921 DTC143EKA-X DIGI TRANSISTOR FAN CONTROL
Q
1922 DTC143EKA-X DIGI TRANSISTOR FCD CONTROL
Q
3101 2SD2114K/VW/-X CHIP TR.C.M S.MUTE
Q
3201 2SD2114K/VW/-X CHIP TR.C.M S.MUTE
Q
3301 DTA143TKA-X TRANSISTOR S.MUTE BUFF
Q
8001 DTC114TKA-X TRANSISTOR
Q
8002 DTC114EKA-X TR
Q
8003 DTA114EKA-X DIGITAL.TRANSIS
Q
8101 2SD2114K/VW/-X CHIP TR.C.M
Q
8201 2SD2114K/VW/-X CHIP TR.C.M
R 1 NRSA63J-102X MG RESISTOR
R 2 NRSA63J-820X MG RESISTOR
R 12 NRSA63J-102X MG RESISTOR
R 13 NRSA63J-104X MG RESISTOR
R 20 NRSA63J-331X MG RESISTOR
R 21 NRSA63J-224X MG RESISTOR
R 22 NRSA63J-331X MG RESISTOR
R 23 NRSA63J-270X MG RESISTOR
R 24 NRSA63J-271X MG RESISTOR
R 25 NRSA63J-473X MG RESISTOR
R 27 NRSA63J-223X MG RESISTOR
R 29 NRSA63J-473X MG RESISTOR
R 30 NRSA63J-103X MG RESISTOR
R 31 NRSA63J-103X MG RESISTOR
R 32 NRSA63J-473X MG RESISTOR
R 34 NRSA63J-333X MG RESISTOR
R 35 NRSA63J-333X MG RESISTOR
R 36 NRSA63J-103X MG RESISTOR
R 37 NRSA63J-472X MG RESISTOR
R 38 NRSA63J-392X MG RESISTOR
R 39 NRSA63J-392X MG RESISTOR
R 42 NRSA63J-102X MG RESISTOR
R 43 NRSA63J-102X MG RESISTOR
R 44 NRSA63J-102X MG RESISTOR
R 45 NRSA63J-102X MG RESISTOR
R 46 NRSA63J-473X MG RESISTOR
R 48 NRSA63J-102X MG RESISTOR
R 52 NRSA63J-472X MG RESISTOR
R 54 NRSA63J-472X MG RESISTOR
R 55 NRSA63J-182X MG RESISTOR
R 56 NRSA63J-332X MG RESISTOR
R 57 NRSA63J-102X MG RESISTOR
R 66 NRSA63J-222X MG RESISTOR
R 68 NRSA63J-223X MG RESISTOR
R 69 NRSA63J-222X MG RESISTOR
RY191 QSK0116-001 RELAY
A
VH
R1103 NRSA63J-103X MG RESISTOR AHB
R1104 NRSA63J-332X MG RESISTOR LPF
R1105 NRSA63J-272X MG RESISTOR FS-SD98V/78V
R1105 NRSA63J-392X MG RESISTOR FS-SD58V
R1106 NRSA63J-152X MG RESISTOR FS-SD58V
R1106 NRSA63J-392X MG RESISTOR FS-SD98V/78V
R1107 NRSA63J-153X MG RESISTOR AHB
R1108 NRSA63J-302X MG RESISTOR FS-SD58V
R1108 NRSA63J-432X MG RESISTOR FS-SD98V/78V
R1109 NRSA63J-153X MG RESISTOR AHB
R1110 NRSA63J-184X MG RESISTOR FS-SD58V
R1110 NRSA63J-224X MG RESISTOR FS-SD98V/78V
R1111 NRSA63J-103X MG RESISTOR AHB
R1112 NRSA63J-332X MG RESISTOR HP
R1113 NRSA63J-563X MG RESISTOR HP
R1114 NRSA63J-102X MG RESISTOR HP
R1115 NRSA63J-471X MG RESISTOR HP
R1116 NRSA63J-222X MG RESISTOR HP.MUTE
R1203 NRSA63J-103X MG RESISTOR AHB
R1204 NRSA63J-332X MG RESISTOR LPF
R1205 NRSA63J-272X MG RESISTOR FS-SD98V/78V
R1205 NRSA63J-392X MG RESISTOR FS-SD58V
R1206 NRSA63J-152X MG RESISTOR FS-SD58V
R1206 NRSA63J-392X MG RESISTOR FS-SD98V/78V
R1207 NRSA63J-153X MG RESISTOR AHB
R1208 NRSA63J-302X MG RESISTOR FS-SD58V
R1208 NRSA63J-432X MG RESISTOR FS-SD98V/78V
R1209 NRSA63J-153X MG RESISTOR AHB
R1210 NRSA63J-184X MG RESISTOR FS-SD58V
R1210 NRSA63J-224X MG RESISTOR FS-SD98V/78V
R1211 NRSA63J-103X MG RESISTOR AHB
R1212 NRSA63J-332X MG RESISTOR HP
R1213 NRSA63J-563X MG RESISTOR HP
R1214 NRSA63J-102X MG RESISTOR HP
R1215 NRSA63J-471X MG RESISTOR HP
R1216 NRSA63J-222X MG RESISTOR HP.MUTE
R1301 NRSA63J-513X MG RESISTOR AHB
R1302 NRSA02J-471X MG RESISTOR
A
AHB
R1303 NRSA63J-102X MG RESISTOR AHB
R1304 NRSA63J-154X MG RESISTOR FS-SD58V
R1304 NRSA63J-224X MG RESISTOR FS-SD98V/78V
R1305 NRSA63J-124X MG RESISTOR AHB
R1306 NRSA63J-513X M.G.RESISTOR FS-SD58V
R1306 NRSA63J-563X MG RESISTOR FS-SD98V/78V
R1307 NRSA63J-912X MG RESISTOR HP
R1308 NRSA63J-103X MG RESISTOR HP
R1309 NRSA02J-100X MG RESISTOR HP
R1310 NRSA63J-102X MG RESISTOR HP.MUTE.D
R1311 NRSA63J-102X MG RESISTOR S.MUTE.D
R1312 NRSA02J-471X MG RESISTOR
A
R1313 NRSA02J-471X MG RESISTOR
A
R1801 NRSA63J-471X MG RESISTOR M.DRIVER
R1802 NRSA63J-153X MG RESISTOR M.DRIVER
R1803 NRSA63J-473X MG RESISTOR M.DRIVER
R1804 NRSA63J-100X MG RESISTOR M.DRIVER
R1805 NRSA63J-100X MG RESISTOR M.DRIVER
R1806 NRSA63J-183X MG RESISTOR M.DRIVER
R1807 NRSA63J-471X MG RESISTOR
A
R1808 NRSA63J-471X MG RESISTOR
A
R1902 NRSA02J-1R0X MG RESISTOR
A
SW10
R1903 NRSA02J-1R0X MG RESISTOR
A
SW10
R1904 NRSA02J-1R0X MG RESISTOR
A
SW10
(Main board)
Item
Parts number Parts name Area
Remarks
A
