FS-SD58V/FS-SD78V/FS-SD98V
3-10
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 02
A
CN501 QGF1201F3-08 CONNECTOR TO MAIN
CN502 QGA2001C1-04 4P PLUG ASSY TO TOPKEY
CN603 QGF1008F1-16 16PIN CONNECTOR TO PICK
CN605 QGA2001C1-06 6P PLUG ASSY TO PICK
CN701 QGF1201F3-09 CONNECTOR TO AMP/TUNER
CN702 QGF1201F3-20 FFC/FPC CONNE TO AMP/TUNER
CN703 QGA2001F1-13 CONNECTOR TO FUNCTION
CN704 QGB1216J1-14S CONNECTOR TO LCD
CN705 QGA2001F1-03 CONNECTOR TO CD DOOR DT1
CN706 QGA2001F1-02 2P CONNECTOR TO DISC LED
CN711 QGF1008F1-15 21-41 CONNECTOR TO VCD-BOARD
CN804 QGA2001F1-02 2P CONNECTOR
C5101 QETN1HM-475Z E CAPACITOR LINE IN
C5102 QETN1HM-475Z E CAPACITOR TU IN
C5103 QTE1V06-106Z E CAPACITOR CD IN
C5104 QTE1V06-106Z E CAPACITOR FUC.OUT
C5105 QETN1CM-106Z E CAPACITOR LINE OUT
C5106 QFN31HJ-562Z M CAPACITOR MPX.F
C5107 QTE1C06-226Z E CAPACITOR VOL OUT
C5108 QFN31HJ-332Z M CAPACITOR TRE.
C5109 QFVJ1HJ-154Z MF CAPACITOR BASS
C5110 QFVJ1HJ-154Z MF CAPACITOR BASS
C5111 NDC31HJ-151X C CAPACITOR LINE IN
C5112 NCB31HK-102X C CAPACITOR LINE OUT
C5201 QETN1HM-475Z E CAPACITOR LINE IN
C5202 QETN1HM-475Z E CAPACITOR TU IN
C5203 QTE1V06-106Z E CAPACITOR CD IN
C5204 QTE1V06-106Z E CAPACITOR FUC.OUT
C5205 QETN1CM-106Z E CAPACITOR LINE OUT
C5206 QFN31HJ-562Z M CAPACITOR MPX.F
C5207 QTE1C06-226Z E CAPACITOR VOL OUT
C5208 QFN31HJ-332Z M CAPACITOR TRE.
C5209 QFVJ1HJ-154Z MF CAPACITOR BASS
C5210 QFVJ1HJ-154Z MF CAPACITOR BASS
C5211 NDC31HJ-151X C CAPACITOR LINE IN
C5212 NCB31HK-102X C CAPACITOR LINE OUT
C5301 QETN1CM-107Z E CAPACITOR VCC
C5302 QTE1V06-476Z E CAPACITOR 1/2VCC
C5303 QETN1HM-105Z E CAPACITOR L/O MUTE.D
C5304 QETN1AM-477Z E CAPACITOR V.OUT
C5305 NDC31HJ-680X C CAPACITOR V.OUT
C5307 NCB31HK-103X C CAPACITOR AUX IN-G
C5308 NCB31HK-103X C CAPACITOR AUX OUT-G
C5309 NCB31HK-103X C CAPACITOR V.OUT-G
C5311 NDC31HJ-151X C CAPACITOR DATA-G
C5312 NDC31HJ-151X C CAPACITOR CLOCK-G
C6001 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V
C6002 QEK41CM-106 E CAPACITOR 10MF 20% 16V
C6003 NDC21HJ-3R5X C CAPACITOR x-f-:TDK
C6005 NDC31HJ-331X C CAPACITOR
C6007 NCB31HK-222X C CAPACITOR
C6008 QEKC1HM-105Z E.CAPACITOR 1.0MF 20% 50V
C6009 NDC31HJ-101X C.CAPACITOR
C6010 NCB31CK-273X C CAPACITOR
C6011 NCB31HK-222X C CAPACITOR
C6012 NCB31HK-103X C CAPACITOR
C6014 NCB31CK-104X C CAPACITOR
C6015 NCB31HK-223X C CAPACITOR
C6016 NCB31HK-223X C CAPACITOR
C6017 NCB31HK-223X C CAPACITOR
C6018 NCB31HK-222X C CAPACITOR
C6019 NDC31HJ-271X C CAPACITOR
C6020 NDC31HJ-181X C CAPACITOR
C6021 NDC31HJ-821X C CAPACITOR
C6022 QEKC0JM-476Z E.CAPACITOR 47MF 20% 6.3V
C6023 NCB31CK-104X C CAPACITOR
C6028 NCB31CK-473X C CAPACITOR
C6029 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V
C6031 QEKC1AM-227Z E CAPACITOR 220MF 20% 10V
C6032 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V
C6033 QEK41CM-106 E CAPACITOR 10MF 20% 16V
C6051 NDC31HJ-120X C CAPACITOR
C6052 NDC31HJ-150X C CAPACITOR
C6053 NCB31HK-223X C CAPACITOR
C6055 NCB31CK-473X C CAPACITOR
C6058 NDC31HJ-6R0X C CAPACITOR
C6061 NDC31HJ-471X C CAPACITOR
C6062 NCB31HK-223X C CAPACITOR
C6063 NCB31HK-223X C CAPACITOR
C6064 NCB31HK-223X C CAPACITOR
C6065 NCB21CK-334X C CAPACITOR
C6071 NCB31HK-222X C CAPACITOR
C6072 NCB31HK-222X C CAPACITOR
C6073 QEKC1AM-227Z E CAPACITOR 220MF 20% 10V
C6075 NCB31HK-102X C CAPACITOR
C6076 NCB31HK-102X C CAPACITOR
C6080 QEKC1AM-227Z E CAPACITOR 220MF 20% 10V
C6081 QEKC1AM-227Z E CAPACITOR 220MF 20% 10V
C6083 NCB31HK-223X C CAPACITOR
C6089 NCB31HK-472X C CAPACITOR
C6090 NCB31HK-153X C CAPACITOR
C6091 QENC1HM-105Z NP E.CAPA I.M 1.0MF 20% 50V
C6092 QENC1HM-225Z NP E.CAPA I.M 2.2MF 20% 50V
C6094 NCB31CK-104X C CAPACITOR
C6096 NDC31HJ-391X C CAPACITOR
C6097 NDC31HJ-391X C CAPACITOR
C6098 NDC31HJ-391X C CAPACITOR
C6099 NDC31HJ-391X C CAPACITOR
C6154 NDC31HJ-101X C.CAPACITOR
C6156 NDC31HJ-151X C CAPACITOR
C6157 NDC31HJ-151X C CAPACITOR
C6158 NDC31HJ-151X C CAPACITOR
C6159 NCB31CK-104X C CAPACITOR
C6251 NCB31HK-223X C CAPACITOR
C7001 NDC31HJ-180X C.CAPACITOR
C7002 NDC31HJ-180X C.CAPACITOR
C7003 NDC31HJ-390X C CAPACITOR
C7004 NCS21HJ-360X C CAPACITOR
C7005 NDC31HJ-220X C CAPACITOR
C7006 NCS21HJ-200X C CAPACITOR
C7007 NCB31HK-102X C CAPACITOR
C7008 NCB31HK-102X C CAPACITOR
C7009 NCB31HK-103X C CAPACITOR
C7010 QEKC1AM-107Z E.CAPACITOR 100MF 20% 10V
C7011 NCB31CK-104X C CAPACITOR
C7012 QEZ0229-479Z EDL.CAPACITOR 47000MF
C7013 QEKC1CM-107Z E.CAPACITOR 100MF 20% 16V
C7014 QFN31HJ-104Z M CAPACITOR .10MF 5% 50V
C7018 NCB31HK-103X C CAPACITOR
C7019 QEKC1HM-225Z E CAPACITOR 2.2MF 20% 50V
C7020 QEKC1HM-475Z E.CAPACITOR 4.7MF 20% 50V
C7022 NCB31HK-103X C CAPACITOR
C7207 NDC31HJ-101X C.CAPACITOR
C7208 NDC31HJ-220X C CAPACITOR
C7213 NDC31HJ-101X C.CAPACITOR
C7221 NDC31HJ-101X C.CAPACITOR
(CD board)
Item
Parts number Parts name Area
Remarks
A
