JVC FS-SD58V User Manual

FS-SD58V/FS-SD78V/FS-SD98V
3-11
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 02
A
C7222 NDC31HJ-101X C.CAPACITOR
C7223 NDC31HJ-101X C.CAPACITOR
C7230 NDC31HJ-220X C CAPACITOR
C7231 NCB31HK-103X C CAPACITOR
C7241 NCS21HJ-200X C CAPACITOR
C7242 NDC31HJ-220X C CAPACITOR
C7251 QEKC1AM-107Z E.CAPACITOR 100MF 20% 10V
C7252 NCB31HK-103X C CAPACITOR
D5301 MTZJ6.8C-T2 Z DIODE I/M V.OUT
D5302 1SS133-T2 SI DIODE L/O MUTE.D
D5303 1SS133-T2 SI DIODE SEIDENKI
D5304 1SS133-T2 SI DIODE SEIDENKI
D6001 1SS355-X DIODE
D6031 MTZJ5.6C-T2 ZENER DIODE
D6032 1SR35-100A-T5 SI DIODE
D6033 1SR35-100A-T5 SI DIODE
D6061 1SS355-X DIODE
D6062 1SS355-X DIODE
D6063 1SS355-X DIODE
D7001 1SS355-X DIODE
D7002 1SS355-X DIODE
D7003 1SS133-T2 SI DIODE
D7004 1SS133-T2 SI DIODE
D7005 1SS133-T2 SI DIODE
D7006 1SS355-X DIODE
D7007 MTZJ5.1C-T2 ZENER DIODE
D7008 1SS133-T2 SI DIODE
D7009 MTZJ8.2B-T2 DIODE
D7201 1SS133-T2 SI DIODE
IC501 BD3861FS-X IC FUNC/VOL
IC601 AN8806SB-W IC
IC602 LA6541-X IC
IC603 MN35510 IC
IC701 UPD780024AGKB20 IC(MASK) MASK-MICON
IC702 KIA78S06P-T IC
IC711 UPD780053GC-031 IC CD-MICOM
J5301 QNS0047-001 JACK LINE IN
J5302 QNS0047-001 JACK LINE OUT
J5303 QNN0017-002 PIN JACK VIDEOOUT
J6001 GP1FA550TZ OPT TRANSMITTER OPT OUT
K5301 QQR0779-001Z INDUCTOR CDAG
K5303 QQR0779-001Z INDUCTOR V.GND
K5304 QQR0779-001Z INDUCTOR V.OUT
K6051 QQR0779-001Z INDUCTOR
K6201 NQR0155-005X INDUCTOR I.M
K6202 NQR0155-005X INDUCTOR I.M
K6203 NQR0155-005X INDUCTOR I.M
K7001 QQR0779-001Z INDUCTOR
K7201 QQR0779-001Z INDUCTOR
LF501 QQR0797-002 INDUCTOR V.OUT
LF511 QQR0590-001 FILTER MPX.F
LF521 QQR0590-001 FILTER MPX.F
L7001 QQL01BK-100Z INDUCTOR
L7002 QQL01BK-100Z INDUCTOR
L7201 QQL01BK-100Z INDUCTOR
Q
5101 2SD2114K/VW/-X CHIP TR.C.M L/O MUTE
Q
5201 2SD2114K/VW/-X CHIP TR.C.M L/O MUTE
Q
5301 DTA114EKA-X DIGITAL.TRANSIS L/O MUTE.D
Q
6001 2SA1037AK/R/-X TRANSISTOR
Q
6031 2SC2060/QR/-T TRANSISTOR
Q
6500 DTD123TK-X CHIP D.TR.C.M
Q
7001 2SC2814/4-5/-X TRANSISTOR
Q
7002 2SC2814/4-5/-X TRANSISTOR
Q
7003 DTA114TKA-X DIGITAL.TR
Q
7004 2SC2412K/R/-X TRANSISTOR
Q
7006 2SC2412K/R/-X TRANSISTOR
Q
7007 DTC114EKA-X TR
Q
7008 DTA114EKA-X DIGITAL.TRANSIS
Q
7201 DTC114EKA-X TR
Q
7202 DTA114EKA-X DIGITAL.TRANSIS
R5101 NRSA63J-223X MG RESISTOR LINE IN
R5102 NRSA63J-683X MG RESISTOR LINE IN
R5103 NRSA63J-392X MG RESISTOR CD IN
R5105 NRSA63J-473X MG RESISTOR LINE OUT
R5106 NRSA63J-392X MG RESISTOR LINE OUT
R5107 NRSA63J-102X MG RESISTOR LINE OUT
R5108 NRSA63J-222X MG RESISTOR L/O MUTE
R5110 NRSA63J-332X MG RESISTOR BASS
R5111 NRSA63J-122X MG RESISTOR MPX.F
R5112 NRSA63J-562X MG RESISTOR MPX.F
R5201 NRSA63J-223X MG RESISTOR LINE IN
R5202 NRSA63J-683X MG RESISTOR LINE IN
R5203 NRSA63J-392X MG RESISTOR CD IN
R5205 NRSA63J-473X MG RESISTOR LINE OUT
R5206 NRSA63J-392X MG RESISTOR LINE OUT
R5207 NRSA63J-102X MG RESISTOR LINE OUT
R5208 NRSA63J-222X MG RESISTOR L/O MUTE
R5210 NRSA63J-332X MG RESISTOR BASS
R5211 NRSA63J-122X MG RESISTOR MPX.F
R5212 NRSA63J-562X MG RESISTOR MPX.F
R5301 NRSA63J-223X MG RESISTOR L/O MUTE D
R5302 NRSA63J-104X MG RESISTOR V.OUT
R5305 NRSA63J-1R5X MG RESISTOR VCC
R6001 NRSA63J-123X MG RESISTOR
R6002 NRSA63J-225X MG RESISTOR
R6003 NRSA63J-102X MG RESISTOR
R6005 NRSA63J-274X MG RESISTOR
R6006 NRSA63J-473X MG RESISTOR
R6007 NRSA63J-273X MG RESISTOR
R6008 NRSA63J-564X MG RESISTOR
R6009 NRSA63J-563X MG RESISTOR
R6010 NRSA63J-104X MG RESISTOR
R6012 NRSA63J-103X MG RESISTOR
R6013 NRSA63J-121X MG RESISTOR
R6014 NRSA63J-100X MG RESISTOR
R6015 NRSA63J-120X MG RESISTOR
R6016 NRSA63J-910X MG RESISTOR
R6021 NRSA63J-270X MG RESISTOR
R6024 NRSA63J-154X MG RESISTOR
R6025 NRSA63J-154X MG RESISTOR
R6026 NRSA63J-393X MG RESISTOR
R6027 NRSA63J-393X MG RESISTOR
R6028 NRSA63J-393X MG RESISTOR
R6029 NRSA63J-393X MG RESISTOR
R6031 NRSA63J-102X MG RESISTOR
R6032 NRSA63J-102X MG RESISTOR
R6033 NRSA63J-102X MG RESISTOR
R6040 NRSA63J-102X MG RESISTOR
R6041 NRSA63J-104X MG RESISTOR
R6042 NRSA63J-472X MG RESISTOR
R6043 NRSA63J-123X MG RESISTOR
R6044 NRSA63J-683X MG RESISTOR
R6045 NRSA63J-433X MG RESISTOR
R6046 NRSA63J-392X MG RESISTOR
R6047 NRSA63J-332X MG RESISTOR
R6048 NRSA63J-222X MG RESISTOR
(CD board)
Item
Parts number Parts name Area
Remarks
A
