FS-SD58V/FS-SD78V/FS-SD98V
3-13
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 02
A
R7213 NRSA63J-102X MG RESISTOR
R7214 NRSA63J-223X MG RESISTOR
R7215 NRSA63J-102X MG RESISTOR
R7216 NRSA63J-103X MG RESISTOR
R7217 NRSA63J-102X MG RESISTOR
R7218 NRSA63J-102X MG RESISTOR
R7219 NRSA63J-102X MG RESISTOR
R7220 NRSA63J-102X MG RESISTOR
R7221 NRSA63J-102X MG RESISTOR
R7222 NRSA63J-102X MG RESISTOR
R7223 NRSA63J-102X MG RESISTOR
R7224 NRSA63J-222X MG RESISTOR
R7225 NRSA63J-222X MG RESISTOR
R7251 NRSA63J-223X MG RESISTOR
R7302 NRSA63J-0R0X MG RESISTOR
R7310 NRSA63J-103X MG RESISTOR
R7311 NRSA63J-103X MG RESISTOR
R7312 NRSA63J-103X MG RESISTOR
SP603 VYH7653-001 IC HOLDER IC603 IC-HOLDER
SP701 VYH7653-002 IC HOLDER
SP711 VYH7653-001 IC HOLDER
S8021 QSW0851-001 DETECT SWITCH
S8022 QSW0851-001 DETECT SWITCH
TH701 QAD0015-103Z THERMISTOR
TW701 QUB220-08HPDM SIN TWIST WIRE
WR 1 QUB220-07HPDM SIN TWIST WIRE ANT GND - BOTTO
W3001 QJK002-061901 SIN CR C-B WIRE POWER - MAIN
W3002 QJK019-040704 SIN CR C-B WIRE SPK - POWER
W3901 QJK019-072002 SIN CR C-B WIRE POWER - MAIN
W5001 QJK018-130503 SIN CR C-B WIRE FUNCTION - MICO
W7002 QJK021-121700 SIN CR C-B WIRE MICOM - VCD
W7003 QJK018-060901 SIN CR C-B WIRE MICOM - VCD
W8001 QJK018-020502 SIN CR C-B WIRE LCD BACKLIGHT -
W8002 QJK018-040504 SIN CR C-B WIRE TOPKEY - FUNCTI
W8003 QJK018-021202 SIN CR C-B WIRE TOPKEY - DOOR D
W8004 QJK018-030503 SIN CR C-B WIRE DOOR DT1 - MICO
W8005 QJK018-020502 SIN CR C-B WIRE DISC LED - MICO
X6051 QAX0413-001Z CRYSTAL
X7001 QAX0401-001 CRYSTAL
X7002 QAX0410-001 CERA LOCK
X7201 QAX0410-001 CERA LOCK
(CD board)
