FS-SD58V/FS-SD78V/FS-SD98V
3-14
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 03
A
C 101 NCF31EZ-104X C CAPACITOR
C 102 NCF31EZ-104X C CAPACITOR
C 103 NCF31EZ-104X C CAPACITOR
C 105 NCF31EZ-104X C CAPACITOR
C 106 NCF31EZ-104X C CAPACITOR
C 107 NCF31EZ-104X C CAPACITOR
C 110 NCF31EZ-104X C CAPACITOR
C 111 NCF31EZ-104X C CAPACITOR
C 112 NCF31EZ-104X C CAPACITOR
C 113 NCF31EZ-104X C CAPACITOR
C 115 NCF31EZ-104X C CAPACITOR
C 116 NCF31EZ-104X C CAPACITOR
C 122 NCS31HJ-150X C CAPACITOR
C 123 NCF31EZ-104X C CAPACITOR
C 124 NCF31EZ-104X C CAPACITOR
C 125 NCF31EZ-104X C CAPACITOR
C 127 NCF31EZ-104X C CAPACITOR
C 128 NEA70JM-107X E.CAPACITOR
C 131 NCF31EZ-104X C CAPACITOR
C 133 NCF31EZ-104X C CAPACITOR
C 134 NCF31EZ-104X C CAPACITOR
C 135 NCF31EZ-104X C CAPACITOR
C 136 NCB31HK-272X C CAPACITOR
C 141 NCB31HK-472X C CAPACITOR
C 143 NCB31HK-182X C CAPACITOR
C 144 NCB31HK-182X C CAPACITOR
C 151 NCF31EZ-104X C CAPACITOR
C 152 NEA70JM-226X E CAPACITOR
C 153 NCF31EZ-104X C CAPACITOR
C 154 NEA70JM-107X E.CAPACITOR
C 155 NCF31EZ-104X C CAPACITOR
C 156 NEA70JM-226X E CAPACITOR
C 157 NEA70JM-226X E CAPACITOR
C 158 NCF31EZ-104X C CAPACITOR
C 159 NCB31HK-102X C CAPACITOR
C 162 NCS31HJ-101X C.CAPACITOR
C 168 NCS31HJ-471X C CAPACITOR
C 170 NCS31HJ-471X C CAPACITOR
C 181 NCF31EZ-104X C CAPACITOR
C 191 NCS31HJ-101X C.CAPACITOR
C 198 NCF31EZ-104X C CAPACITOR
CN101 QGF1016F2-15W CONNECTOR C.M
CN102 QGA2001F2-12X CONNECTOR C.M
CN103 QGA2001F2-06X CONNECTOR C.M
D 141 UDZ4.7B-X ZENER DIODE
D 142 1SS355-X DIODE
IC101 CL480-F1 IC
IC102 MX23C10M12-586X IC C.M
IC103 V53C16258HK40-X IC C.M.
IC104 BU1424K IC
IC105 BU2173F-X IC
IC106 UPD6461GS-635-X IC
IC107 PQ20VZ11-X IC
IC108 TC7SH04FU-X IC C.M
IC111 MN171601AK8J2 IC
IC112 A625308M-70S-X IC C.M
IC113 HD74HCT244FP-XE IC C.M
IC114 HD74HCT245FP-XE IC
K 101 NQR0227-004X FERRITE BEADS
K 103 NQR0227-004X FERRITE BEADS
L 102 NQL012K-2R7X INDUCTOR
Q
101 DTA114EKA-X DIGITAL.TRANSIS
Q
141 2SC2412K/RS/-X CHIP TRANSISTOR
R 102 NRSA63J-473X MG RESISTOR
R 103 NRSA63J-103X MG RESISTOR
R 104 NRSA63J-105X MG RESISTOR
R 107 NRSA63J-122X MG RESISTOR
R 109 NRSA63J-750X MG RESISTOR
R 111 NRSA63J-182X MG RESISTOR
R 112 NRSA63J-112X MG RESISTOR
R 113 NRSA63J-102X MG RESISTOR
R 115 NRSA63J-0R0X MG RESISTOR
R 118 NRSA63J-392X MG RESISTOR
R 119 NRSA63J-392X MG RESISTOR
R 121 NRSA63J-102X MG RESISTOR
R 122 NRSA63J-102X MG RESISTOR
R 123 NRSA63J-102X MG RESISTOR
R 124 NRSA63J-102X MG RESISTOR
R 125 NRSA63J-102X MG RESISTOR
R 128 NRSA63J-103X MG RESISTOR
R 129 NRSA63J-103X MG RESISTOR
R 135 NRSA63J-121X MG RESISTOR
R 141 NRSA63J-750X MG RESISTOR
R 142 NRSA63J-562X MG RESISTOR
R 147 NRSA63J-471X MG RESISTOR
R 148 NRSA63J-152X MG RESISTOR
R 149 NRSA63J-152X MG RESISTOR
R 150 NRSA63J-0R0X MG RESISTOR
R 155 NRSA63J-271X MG RESISTOR
R 156 NRSA63J-391X MG RESISTOR
R 157 NRSA63J-0R0X MG RESISTOR
R 191 NRSA63J-820X MG RESISTOR
R 192 NRSA63J-820X MG RESISTOR
R 193 NRSA63J-820X MG RESISTOR
R 194 NRSA63J-0R0X MG RESISTOR
R 196 NRSA63J-221X MG RESISTOR
R 197 NRSA63J-0R0X MG RESISTOR
R 198 NRSA63J-181X MG RESISTOR
TC101 NAT3111-200X TRIM.CAPA.I.M
X 101 NAX0150-001X CRYSTAL
(VCD board)
Item
Parts number Parts name Area
Remarks
A
