6
Getting Started
Getting StartedGetting Started
Getting Started
FS-SD550(A)/ GNT0008-010A/ English
CAUTION:
Make all connections before plugging the System into an AC power outlet.
Connecting the Speakers
1. Open each of the terminals to connect the speaker wire leads.
2. Connect the speaker cords between the Speaker terminals of the Unit and the terminals of the Speakers.
Connect the cords with a black line to the (–) terminals and cords without a black line to the (+) terminals.
3. Close each of the terminals to securely connect the cords.
Since both speakers are the same, you can put either one to the right or left side.
CAUTION:
A TV may display irregular colors if located near the speakers. If this happens, set the speak-
ers away from the TV.
Removing the speaker grilles
The speaker grilles can be moved.
When removing:
1. Pull the top forwards you with your fingers.
2. Also pull the bottom towords you.
When removing the speaker grille from the FS-
SD990’s speaker, be careful not to damage the cab-
inet.
When attaching the speaker grille:
SPEAKERS IMPEDANCE 4 16
RL
Marked with a black line
Right side (rear view)
Left side (rear view)
Speaker
grille
(FS-SD550) (FS-SD770 and FS-SD990)
Speaker
grille
(FS-SD550)
(FS-SD770 and FS-SD990)
