3-8
CD mechanism
Block No. [M][B][M][M]
Symbol No.
Part No. Part Name Description Local
1 LV32651-008A CH.BASE ASSY
2 QAR0176-001 FEED MOTOR
3 VKZ4743-001 SPECIAL SCREW (x2)
4 LV42229-001A MOTOR GEAR
5 OPTIMA-725B2 CD PICK UP
6 LV20993-002A RACK PLATE
7 QYSPSGT1735M MINI SCREW
1.7mm x
3.5mm(x2)
8 E406777-002SM C.D SHAFT
9 LV41741-001A SPECIAL SCREW (x2)
10 LV31744-001A P.S.SPRING
11 QYSPSGT1425M TAP SCREW 1.4mm x 2.5mm
12 LV33756-001A STOPPER
13 QYSBSF2005Z SCREW 2mm x 5mm
14 QAR0252-001 SP.MOTOR
15 VKZ4743-001 SPECIAL SCREW (x2)
16 LV31844-005A T.TABLE
17 LV41113-001A R.SHEET
18 LV32318-002A DISC GUIDE
19 LV32319-001A BOTTOM COVER
20 LV42040-001A CHUCK SPRING (x3)
21 LV42041-001A CHUCK BALL (x3)
22 LVB30008-001A FPC
23 LV30225-0B6A SPACER (x2)
24 QYSBSF2005Z SCREW 2mm x 5mm(x3)
To Next Page
