JVC FS-X3 Service Manual

3-9
Electrical parts list
Power board
Block No. [0][1][0][0]
 Symbol No. Part No. Part Name Description Local
IC431 HA17558AF-X IC
 IC451 TA8409F-W IC Motor driver
IC481 LC75342M-X IC E. volume
IC492 HA17558AF-X IC
 IC901 STR-F6256S SW.IC
 IC920 PC123Y22 PHOTO COUPLER
 IC931 BA00ASFP-X IC
Q4101 2SC3661-X TRANSISTOR
Q4102 2SC3661-X TRANSISTOR
Q4111 2SC3661-X TRANSISTOR
Q4161 2SC2812N/6/-X TRANSISTOR
Q4201 2SC3661-X TRANSISTOR
Q4202 2SC3661-X TRANSISTOR
Q4211 2SC3661-X TRANSISTOR
Q4261 2SC2812N/6/-X TRANSISTOR
Q4301 UN211L-X TRANSISTOR
Q4311 UN2113-X TRANSISTOR
Q4321 2SC3661-X TRANSISTOR
Q4322 UN211E-X DIGI TRANSISTOR
Q4323 UN2211-X TRANSISTOR
Q4324 UN2111-X TRANSISTOR
Q4501 2SC2812N/6/-X TRANSISTOR
Q9011 2SB709A/Q/-X TRANSISTOR
Q9301 2SC2235/OY/-T TRANSISTOR
Q9302 UN2212-X TRANSISTOR
Q9303 UN2111-X TRANSISTOR
Q9304 UN2212-X TRANSISTOR
Q9305 UN2111-X TRANSISTOR
Q9401 UN2212-X TRANSISTOR
Q9402 2SC2412K/R/-X TRANSISTOR
Q9403 2SC2412K/R/-X TRANSISTOR
Q9404 UN2215-X TRANSISTOR
Q9405 UN2212-X TRANSISTOR
Q9406 2SC2412K/R/-X TRANSISTOR
Q9407 UN2111-X TRANSISTOR
 Q9431 2SA1037AK/R/-X TRANSISTOR
Q9432 UN2212-X TRANSISTOR
Q9601 2SA1362/G/-X TRANSISTOR
Q9602 UN2211-X TRANSISTOR
Q9603 2SA1362/G/-X TRANSISTOR
Q9604 UN2211-X TRANSISTOR
D4301 UDZS6.8B-X SI DIODE
D4311 MA153-X DIODE
D4312 1SS355-X SI DIODE
D4321 1SS355-X SI DIODE
D4341 1SS388-X SB DIODE
D4501 GS1J-X DIODE
D4502 GS1J-X DIODE
D4503 CRS01-W SB DIODE
D4506 GS1J-X DIODE
D4801 GS1J-X DIODE
D4901 UDZS4.7B-X Z DIODE
D4911 MA152WK-X SI DIODE
D4912 1SS355-X SI DIODE
D4915 UDZS4.7B-X Z DIODE
D9001 1N4148WS-X DIODE C.M
D9010 1N4148WS-X DIODE C.M
 D9101 D3SBA60 DIODE
 D9111 D2F60-X SI DIODE
 D9112 D2F60-X SI DIODE
 D9113 SARS03 SI DIODE
D9115 M1FL20U-X FR DIODE
D9116 M1FL20U-X FR DIODE
D9117 M1FL20U-X FR DIODE
D9118 M1FL20U-X FR DIODE
D9119 UDZS10B-X Z DIODE
 D9202 FCH10A06 SB DIODE
D9301 M1FL20U-X FR DIODE
D9302 UDZS36B-X Z DIODE
D9303 M1FL20U-X FR DIODE
 D9304 RD3.0ES/B2/-T2 Z DIODE
D9305 RD3.0ES/B2/-T2 Z DIODE
D9401 UDZS13B-X Z DIODE
D9402 UDZS5.6B-X Z DIODE 1.5k Ω 1/10W J
D9403 1SS355-X SI DIODE
D9404 MA153-X DIODE
D9405 1SS355-X SI DIODE
D9411 UDZS5.1B-X Z DIODE
C4101 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C4102 NCS31HJ-151X C CAPACITOR 150pF 50V J
C4103 NCS31HJ-151X C CAPACITOR 150pF 50V J
C4104 QETN1AM-227Z E CAPACITOR 220uF 10V M
C4111 NCS31HJ-151X C CAPACITOR 150pF 50V J
C4112 NCS31HJ-151X C CAPACITOR 150pF 50V J
C4131 NEA71CM-226X E CAPACITOR 22uF 16V M
C4132 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4133 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4134 NCB31HK-122X C CAPACITOR 1200pF 50V K
C4136 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C4137 NEA71CM-106X E CAPACITOR 10uF 16V M
C4138 NEA71CM-106X E CAPACITOR 10uF 16V M
C4139 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4140 NEA71CM-106X E CAPACITOR 10uF 16V M
C4155 NFV41CJ-393X MPPS CAPACITOR 0.039uF 16V J X1C,X1J
C4156 NFV41CJ-103X MPPS CAPACITOR 0.01uF 16V J X3C,X3J
C4162 NFV41CJ-104X MPPS CAPACITOR 0.1uF 16V J
C4163 NFV41CJ-104X MPPS CAPACITOR 0.1uF 16V J
C4165 NEA71CM-226X E CAPACITOR 22uF 16V M
C4166 NEA71CM-106X E CAPACITOR 10uF 16V M
C4201 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C4202 NCS31HJ-151X C CAPACITOR 150pF 50V J
C4203 NCS31HJ-151X C CAPACITOR 150pF 50V J
C4204 QETN1AM-227Z E CAPACITOR 220uF 10V M
C4211 NCS31HJ-151X C CAPACITOR 150pF 50V J
C4212 NCS31HJ-151X C CAPACITOR 150pF 50V J
C4231 NEA71CM-226X E CAPACITOR 22uF 16V M
C4232 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4233 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C4234 NCB31HK-122X C CAPACITOR 1200pF 50V K
C4236 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C4237 NEA71CM-106X E CAPACITOR 10uF 16V M
C4238 NEA71CM-106X E CAPACITOR 10uF 16V M
C4239 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4240 NEA71CM-106X E CAPACITOR 10uF 16V M
C4255 NFV41CJ-393X MPPS CAPACITOR 0.039uF 16V J X1C,X1J
C4256 NFV41CJ-103X MPPS CAPACITOR 0.01uF 16V J X3C,X3J
C4262 NFV41CJ-104X MPPS CAPACITOR 0.1uF 16V J
C4263 NFV41CJ-104X MPPS CAPACITOR 0.1uF 16V J
C4265 NEA71CM-226X E CAPACITOR 22uF 16V M
C4266 NEA71CM-106X E CAPACITOR 10uF 16V M
C4301 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C4302 NEA71CM-107X E CAPACITOR 100uF 16V M
C4303 NEA71CM-476X E CAPACITOR 47uF 16V M
C4311 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C4312 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C4321 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C4323 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C4341 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4342 NBE41AM-106X E CAPACITOR 10uF 10V M
C4502 NEA71AM-476X E CAPACITOR 47uF 10V M
C4503 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C4801 NEB11CM-476X E CAPACITOR 47uF 16V M
C4802 NEA71CM-476X E CAPACITOR 47uF 16V M
C4901 NEA71CM-476X E CAPACITOR 47uF 16V M
C4911 NBE51AM-476X E CAPACITOR 47uF 10V M
C4912 NEA71AM-476X E CAPACITOR 47uF 10V M
C4913 NEA71CM-106X E CAPACITOR 10uF 16V M
C4915 NEA71HM-105X E CAPACITOR 1uF 50V M
C7507 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C7508 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7509 QETN1CM-107Z E CAPACITOR 100uF 10V M
 C9101 QFZ9075-104 MPP CAPACITOR 0.1uF AC275V M
 C9102 QFZ9075-104 MPP CAPACITOR 0.1uF AC275V M
 Symbol No. Part No. Part Name Description Local
