JVC GR-AX285

EN 53
SPECIFICATIONS
GENERAL
Format : VHS PAL standard
Power source : DC 6V
Power consumption
• GR-AX480 light on : 7.9 W
• GR-AX480 light off /
GR-AX285/AX280 : 5.0 W
• GR-AX380 : 5.1 W
Signal system : PAL-type
Video recording system
Luminance : FM recording
Colour : Converted sub-carrier
direct recording
Conforms to VHS
standard
Cassette : cassette
Tape speed : 23.39 mm/sec
Recording time (max.) : 60 minutes
(with EC-60 cassette)
Operating temperature : 0°C to +40°C
Operating humidity : 35% to 80%
Storage temperature : –20°C to +50°C
Weight
• GR-AX480 : Approx. 800 g
• GR-AX380 : Approx. 770 g
• GR-AX285/AX280 : Approx. 790 g
Dimensions
(Including viewfinder)
• GR-AX480/AX285/
AX280 : 113 (W) x 117 (H) x
242 (D) mm
• GR-AX380 : 113 (W) x 117 (H) x
222 (D) mm
CAMERA
Pick up : 1/4” format CCD
Lens : F1.6, f = 3.8 to 83.6 mm,
22:1 power zoom lens
with auto iris and macro
control, filter diameter
46 mm
Viewfinder : Electronic viewfinder with
• 0.5” B/W CRT
(GR-AX480/AX285/
AX280)
• 0.55” colour LCD
(GR-AX380)
White balance
adjustment : Auto/Manual adjustment
VIDEO
Output : 1 Vp-p, 75 ohms,
unbalanced (via VIDEO
OUT connector)
AUDIO
Output : –8 dBs, 1 k-ohm
(via AUDIO OUT
connector)
AC POWER ADAPTER/BATTERY CHARGER
(AA-V15EG)
Power requirement : AC 110 V to 240 V`,
50/60 Hz
Power consumption : 23 W
Output
Charge : DC 8.5 V , 1.3 A
VTR : DC 6.3 V , 1.8 A
Charging system : Constant current,
peak detection,
timer controlled
Dimensions : 140 (W) x 42 (H) x
68 (D) mm
Weight : Approx. 300 g
CASSETTE ADAPTER (C-P7U) (Provided only
with the GR-AX480/AX380/AX280)
Dimensions : 188 (W) x 25 (H) x
104 (D) mm
Weight : Approx. 240 g
Accessory : “R6 (AA)”-size battery x 1
Provided Accessories ...................... Z pg. 3
Optional Accessories
•Battery Packs BN-V12U, BN-V22U, BN-V25U
•Car Battery Charger BH-V3E
•RF Unit RF-V5E
•Compact VHS-C Cassettes EC-60/45/30
•Cassette Adapter C-P6U
•Active Carrying Bag CB-V7U
•Remote Control Unit RM-V700U
The Remote Control Unit RM-V700U can not be
used to operate the GR-AX380, GR-AX285 and
GR-AX280.
Some accessories are not available in some areas.
Please consult your nearest JVC dealer for details on
accessories and their availability.
E. & O. E. Design and specifications subject to
change without notice.
