EN 45
SPECIFICATIONS
GENERAL
Format : VHS PAL standard
Power source : DC 6V
Power consumption
• GR-AX558 light on : 8.0 W
• GR-AX558 light off : 5.1 W
• GR-AX358 : 5.0 W
Signal system : PAL-type
Video recording system
Luminance : FM recording
Colour : Converted sub-carrier
direct recording
Conforms to VHS
standard
Cassette : cassette
Tape speed
SP : 23.39 mm/sec.
LP : 11.70 mm/sec.
Recording time (max.)
SP : 60 minutes
LP : 120 minutes
(with EC-60 cassette)
Operating temperature : 0°C to +40°C
Operating humidity : 35% to 80%
Storage temperature : –20°C to +50°C
Weight
• GR-AX558 : Approx. 780 g
• GR-AX358 : Approx. 790 g
Dimensions
(Including viewfinder)
• GR-AX558 : 113 (W) x 117 (H) x
222 (D) mm
• GR-AX358 : 113 (W) x 117 (H) x
242 (D) mm
CAMERA
Pick up : 1/4” format CCD
Lens : F1.6, f = 3.8 to 83.6 mm,
22:1 power zoom lens
with auto iris and macro
control, filter diameter
46 mm
Viewfinder : Electronic viewfinder
with
• 0.55” colour LCD
(GR-AX558)
• 0.5” black/white CRT
(GR-AX358)
White balance
adjustment : Auto/Manual adjustment
VIDEO
Output : 1 Vp-p, 75 ohms,
unbalanced (via VIDEO
OUT connector)
AUDIO
Output : –8 dBs, 1 k-ohm
(via AUDIO OUT
connector)
AC POWER ADAPTER/BATTERY CHARGER
(AA-V15EG)
Power requirement : AC 110 V to 240 V`,
50/60 Hz
Power consumption : 23 W
Output
Charge : DC 8.5 V , 1.3 A
VTR : DC 6.3 V , 1.8 A
Charging system : Constant current,
peak detection,
timer controlled
Dimensions : 140 (W) x 42 (H) x
68 (D) mm
Weight : Approx. 300 g
CASSETTE ADAPTER (C-P7U)
Dimensions : 188 (W) x 25 (H) x
104 (D) mm
Weight : Approx. 240 g
Accessory : “AA (R6)”-size battery x 1
Provided Accessories ...................... Z pg. 3
Optional Accessories
•Battery Packs BN-V12U, BN-V22U, BN-V25U
•Car Battery Charger BH-V3E
•RF Unit RF-V5E
•Compact VHS-C Cassettes EC-60/45/30
•Active Carrying Bag CB-V7U
Some accessories are not available in some areas.
Please consult your nearest JVC dealer for details on
accessories and their availability.
Specifications shown are for SP mode unless
otherwise indicated.
E. & O. E. Design and specifications subject to
change without notice.
