CAUTIONS:
‘8 The video fight beromes extremely bot. Do not touch
it either while in operation of soon etter turning # off,
‘otherwise serious Injury may resutt
© Do not place the VideoMovis inte the carrying case
[Immediately aflér using the video tight, since it
remains extremely hot. .
= When operating, keep a distance of sbou!
30 em bonween the video light and people or object.
© Do not use near flammable or explosive materials.
LIGHTING — To apply more fight to the
Scene (GR-AX60 only} -- :
When fiatural lighting is foo dim, you can brighten thie
by using the bult-In video ight. thers
EB Slide the LIGHT open knob to open the builtin video fight.
IB] Set the LGHT ON/AUTO as required.
‘ON: Always keeps the light on'as long as the
‘VideoMovie is tuned on.
AUTO: Automatically turns on the light when the
VideoMovie senses insutticient lighting on
the subject.
& Push @ to retract the video light
— The light automaticaly turns otf,
‘4 The video light can be used with the VideoMovie's power
on.
4 it is recommended to set the white balance to indoor
mode (%) (7 P20) when you use the video Eg.
= When nat using the video light, retract it to save battery
power.
Notes:
© Even if the battery warning indication (75) does not
‘appear in the viewfinder, it the battery pack’s charge is low,
the VideoMovie may turn of automatically when you turn
fn the video light, oF when you start recording with the
Video light turned on.
|& When the LIGHT ON/AUTO is set to "AUTO:
© Depending on the lighting condition, the video tight may
not be slably tumed on oF of. In this. case, switch the
light op manually or retract i to turn it ot
'* While he Sports, High-Speed Shutter or Portrait: mode
(EF P. 18) is engaged, the fights txely to stay on.
© While the Twilight mode (C7 P. 18) is’ engaged, the light
wil not activate.
HOW TO REPLACE THE VIDEO LIGHT
BULB
{tis recommended to consuit your nearest JVC dealer for
replacing the bulb. However, if you wish to do it yourselt,
proceed as follows:
[1 Turn and toosen the screw with a screw driver.
[&) Putt out the lamp cover.
[3 Pus out the tuib.
B Insert a new but.
= At steps [3] and [1] use the tweezers provided with new
bulb to hold the bulb. Do nat touch the bulb directly,
[H} Reattach the lamp cover and tighten the screw.
ADVANCED VIDEOGRAPHY TECHNIQUES (Cont'd)
Viewfinder
RM-V704U
(Provided with
GR-AXTO/AX60,
‘optional for GR-AX40)
To release the Self-Timer mode:
CAUTIONS:
The video tight unit and the bulb are very not
intmediately alter the power is tured off. Bulb
replacement should be performed affer It has cooted.
(Ut wil take approx. 30 minutes to c00i sufficiently.)
™ Do net touch the bulb cirectiy. {1 # becomes dirty,
smoke. cr reduced service life may result, When
‘accidentally touched by fingers directly, wipe @ with
soft cloth.
™ Give the part number PEDPO%52 when ordering a
‘Video fight bulb.
= Use the exclusive halogen bulb which is available at
your nearest JVC dealer.
2I
[Wien "=" ta norbtinking:
Press INT. TIME continuously unli* @* goes off.
When "" Is blinking:
| Press StartiStop to stop the biinking, then press INT.
TIME confounusly unt "2" goes off.
‘= Turning the power off and on once engages the regular
Record Pause mode.
INDEX CODE MARKING
The VHS index-Search System. (ViSS) gives you
automatic access to any point you select on.a
recording. Only the marking aspect of the index
Search System is included th this unit, 1 altows index
codes to be placed on recorded tape for convenient
dubbing or editing on VCRs with an index Search
function.
Auto marking
‘An index code is always marked at the beginning of
the first recording after the date advances and a
cassette is inserted.
— "INDEX" blinks while marking,
Manual marking
The AM-V704U remote contro! unit allows index codes
to be marked in any desired position.
HE Press ViSS once to put an Index code onto the
tape.
— "INDEX" blinks during the marking process.
"If VSS has been pressed in the Record-Pause
mode, an index code is put at the point where
START/STOP is pressed.
SELF-TIMER
This Solf-Timer function’ aflows you to set the amount
of time delay before recording starts after. StarvStop
has been pressed. If the VideoMovie has been
secured, the operator can enter the picture belore
actual recording begins,
89 Put the VideoMovie into the Record-Pause mode.
Press INT. TIME to select the interval time,
~The following sequence of time setting Is
displayed with each press of INT. TIME:
158 —» 30S ~--» 1MIN —» SMIN
(regular recording mode)
Viewfinder
a Ifthe VideoMovie's PROGRAM AE is set fo
*“®*(Seli-Timer mode), the 158 mode will be
selected.
Bi Press START/STOP.
& When the selected time has elapsed, recording
bagins automatically.
m When performing Sell-Timer shooting, the tally
lamp will start blinking approximately 10 seconds
before the actuat recording begins. Then when.
recording starts, the famp lights normally to
indicate recording is in progress.
