Controls
1 Diopter Adjustment Control ................. Z pg. 15
2 Lens Cover Open/Close Ring................ Z pg. 16
3 Video Light Switch
[LIGHT OFF/AUTO/ON]
(GR-SXM320/SX851 only) .................... Z pg. 20
4 5-Second Recording Button
[5 SEC. REC] ........................................ Z pg. 19
5 •Power Zoom Lever [T/W] .................. Z pg. 18
•Speaker Volume Control [VOL.]
(GR-SXM320 only) ............................ Z pg. 31
6 •Picture Stabilizer Button
[P.STABILIZER] .................................. Z pg. 18
•Time Base Corrector Button ............... Z pg. 32
7 Program AE Button [P.AE] ..................... Z pg. 22
8 Fade/Wipe Button [EFFECT] ................. Z pg. 21
9 •Retake Rewind Button [RETAKE R] ..... Z pg. 19
•Quick Review Button [ R] ............. Z pg. 19
•Rewind Button [REW] ....................... Z pg. 31
0 •Retake Forward Button [RETAKE F] .... Z pg. 19
•Fast-Forward Button [FF] ................... Z pg. 31
! Stop Button [STOP] .............................. Z pg. 31
@ Play/Pause Button
[PLAY/PAUSE] ..................................... Z pg. 31
# •Select Wheel [PUSH] ........................ Z pg. 23
•Bright Dial [BRIGHT]
(GR-SXM320 only) ...................... Z pg. 16, 31
$ MENU/DISPLAY Button ................. Z pg. 17, 23
% •Recording Mode Button [SP/EP] ......... Z pg. 12
•Counter Reset/Memory Button
[COUNTER R/M] .............................. Z pg. 32
^ EJECT Switch ....................................... Z pg. 10
& Recording Start/Stop Button.................. Z pg. 16
* Power Switch
[ , OFF, AUTO, PRO.] .............. Z pg. 16, 31
( Battery Release Switch
[BATTERY RELEASE] .............................. Z pg. 9
) PUSH Button ....................................... Z pg. 10
Connectors
q DC IN Connector................................... Z pg. 9
The connectors w to t are located beneath the
cover.
w Video Output Connector ...................... Z pg. 34
e Audio Output Connector ..................... Z pg. 34
r S-Video Output Connector
(GR-SXM320/SX851 only) .................... Z pg. 34
t J Terminal [JLIP (Joint Level Interface Protocol)
Connector]
•It is used to connect the camcorder to a device
such as a personal computer.
For further details consult your nearest JVC
dealer.
•JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with a
J terminal.
Indicators
y Power Lamp ........................................ Z pg. 16
Other Parts
u Battery Pack Mount ............................... Z pg. 9
i Viewfinder ........................................... Z pg. 15
o Grip Strap ............................................ Z pg. 15
p •Camera sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
•Remote Sensor
(GR-SXM320/SX851 only) ................. Z pg. 37
Q Video Light
(GR-SXM320/SX851 only) .................... Z pg. 20
W Microphone ......................................... Z pg. 39
E Eyepiece .............................................. Z pg. 50
R Speaker (GR-SXM320 only) .................. Z pg. 31
T LCD Monitor (GR-SXM320 only) .......... Z pg. 17
Y Shoulder Strap Eyelets .......................... Z pg. 15
U Clock Battery Slot ................................ Z pg. 10
I Tripod Mounting Socket ....................... Z pg. 15
