3.2.2 ASSEMBLY/DISASSEMBLY OF CABINET PARTS AND ELECTRICAL PARTS
zDisassembly procedure
NOTE 5 :
For disassembly of the [5] VF ASSEMBLY, refer to 3.2.3 AS-
SEMBLY/DISASSEMBLY OF [5] VF ASSEMBLY .
NOTE 6 :
Take care not to break or damage the FRAME.
NOTE 8a :
Take care not to cut the FPC wire.
NOTE 8b :
Insert and attach the SHEET(FPC) between the MONITOR
FPC and the UPPER CASE(M)ASSEMBLY.
NOTE 8c :
Attachment of the FPC.
NOTE 8d :
For disassembly of the [8] MONITOR ASSEMBLY, refer to
3.2.4 ASSEMBLY/DISASSEMBLY OF [8] MONITOR AS-
SEMBLY.
NOTE 9a :
Take care not to damage the OP BLOCK ASSEMBLY when
and after the FRONT CASE ASSEMBLY is removed.
NOTE 9b :
Attachment of the WIRE
NOTE12 :
Screwing sequence should be in order here first and others.
NOTE 16 :
For disassembly of the CCD BOARD ASSEMBLY, refer to
3.2.5 ASSEMBLY AND DISASSEMBLY OF [16] OP BLOCK
ASSEMBLY AND CCD BOARD ASSEMBLY .
NOTE 17 :
When attaching the MECHANISM ASSEMBLY to S.CASE
(MAIN), pull out the FPC CABLE not to be inserted between
the MECHANISM ASSEMBLY and S.CASE (MAIN).
zDestination of connectors
STEP
No.
PART NAME
Fig.
No.
POINT NOTE
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
CASE COVER(M) ASSY
LOWER CASE ASSY
TOP COVER ASSY
(Inc.TOP BOARD ASSY,VF ASSY)
TOP BOARD ASSY
VF ASSY
UPPER CASE(M) ASSY
(Inc.COVER(UPPER/M) ASSY,
MONITOR ASSY)
COVER(UPPER/M) ASSY
MONITOR ASSY
FRONT COVER ASSY
Inc. DC LIGHT,MIC
FRONT BOARD ASSY
MIC
FRONT FRAME SA
MAIN BOARD ASSY
OP FRAME ASSY
BRACKET OP ASSY
OP BLOCK ASSY
SIELD CASE(MAIN)
MECHANISM ASSY
REAR BOARD ASSY
FRAME ASSY
S1,2(L1)
7(S2),CN2a,CN2b
S3,CN3a, CN3b
2(S4)
3(S5)
6(S6a),S6b,L6,CN6
3(S7)
S8a,L8,SHEET(FPC),2(S8b)
CN9a,CN9b,S9,L9a,L9b
S10
S11
2(S12)
CN13a, b, c, d, e, f, g, h, 2(S13),
CN13j,L13
2(S14a), S14b
S15
-
S17a,S17b
2(S18a),S18b
2(S19)
-
FA1
FA2
FA3
FA4
FA5
FA6
FA7
FA8
FA9
-
-
-
-
NOTE5
NOTE6
-
NOTE8a,b,c,d
NOTE9a,b
-
-
NOTE12
-
-
-
NOTE16
NOTE17
-
-
-
CN2a MAIN CN27 SPEAKER - 2
CN2b MAIN CN13 ZOOM UNIT - 14
CN3a MAIN CN7301 B/W VF ASSY CN7401 14
CN3b MAIN CN18 TOP CN401 6
CN6 MAIN CN16 MONITOR BL CN7601 25
CN9a MAIN CN6 LAMP(DC LIGHT) - 3
CN9b MAIN CN8 MIC - 2
CN13a MAIN CN3 CAPSTAN MOTOR - 18
CN13b MAIN CN7 A/C HEAD - 11
CN13c MAIN CN22 CCD CN5301 14
CN13d MAIN CN15 OP BLOCK ASSY - 24
CN13e MAIN CN4 LOADING MOTOR - 2
CN13f MAIN CN1 DRUM_MOTOR - 10
CN13g MAIN CN5 HEAD(VIDEO,FLY.E) - 11
CN13h MAIN CN2 SENSOR - 14
CN13j MAIN CN28 REAR_UNIT - 10
CN.NO.
CONNECTOR
PIN
NO.
