JVC GR-D270US User Manual

R7004
27k
C7004
100p
R7002
2.7k
R7009
10k
Q7001
2SC4617/QR/-X
R7008
10k
R7003
82
D7001
E1S35AW0C501-X
C7001
0.1
R7001
6.8k
R7006
16k
C7003
100p
CN7002
QGF0530F3-15W
1 VSS
2 VDD
3 SLEEP
4EN
5 VST
6 VCK
7DWN
8 VREF
9 HST
10 HCK2
11 HCK1
12 VIDB
13 VIDG
14 VIDR
15 VCOM
R7005
56k
C7005
R7007
4.7k
CN7001
TO MAIN IF(CN106)
TO LCD(C-VF)PANEL
QGF0545F1-14X
1CVF_R
2CVF_G
3CVF_B
4HCK1
5HCK2
6HST
7VCK
8VST
9EN
10SLEEP
11VF_9V
12VFREG4.8
13GND
14GND
C7002
0.1
VF
80
y40147001a_rev0.1
VF SCHEMATIC DIAGRAM
NOTES: 1. For the destination of each signal and further line connections that are cut off from this diagram, refer to "BOARD INTERCONNECTIONS".
2. The parts with marked () is not used.
2-39(No.YF075)
