SPECIFICATIONS
Camcorder
General
Power supply :
DC 11.0 V (Using AC Adapter)
DC 7.2 V (Using battery pack)
Power consumption
LCD monitor off,
viewfinder on : Approx. 3.4 W
LCD monitor on,
viewfinder off : Approx. 4.7 W
Dimensions
(W x H x D) : 69 mm x 94 mm x 143 mm
(with the LCD monitor closed and
the viewfinder pushed back in)
Weight : Approx. 525 g
Operating
temperature :0°C to 40°C
Operating
humidity : 35% to 80%
Storage
temperature : –20°C to 50°C
Pickup : 1/6" CCD
Lens : F 1.6, f = 2.7 mm to 43.2 mm,
16:1 power zoom lens
Filter diameter : ø37 mm
LCD monitor : 2.5" diagonally measured, LCD
panel/TFT active matrix system
Viewfinder : Electronic viewfinder with 0.24"
black/white LCD
Speaker : Monaural
Digital Video Camera
Format : DV format (SD mode)
Signal format : PAL standard
Recording/
Playback format : Video:
Digital component recording
: Audio: PCM digital recording,
32 kHz 4-channel (12-bit),
48 kHz 2-channel (16-bit)
Cassette : Mini DV cassette
Tape speed : SP : 18.8 mm/s
LP : 12.5 mm/s
Maximum
recording time : SP : 80 min.
(using 80 min. LP : 120 min.
cassette)
Connectors
S-Video
Output : Y : 1 V (p-p), 75 Ω, analogue
C : 0.29 V (p-p), 75 Ω, analogue
Input* : Y : 0.8 V (p-p) – 1.2 V (p-p), 75 Ω,
analogue
C : 0.2 V (p-p) – 0.4 V (p-p), 75 Ω,
analogue
AV
Video output : 1 V (p-p), 75 Ω, analogue
Video input* : 0.8 V (p-p) – 1.2 V (p-p), 75 Ω,
analogue
Audio output : 300 mV (rms), 1 kΩ, analogue,
stereo
Audio input* : 300 mV (rms), 50 kΩ, analogue,
stereo
DV
Output : 4-pin, IEEE 1394 compliant
Input* : 4-pin, IEEE 1394 compliant
USB** : 5-pin
EDIT : ø3.5 mm, 2-pole
* GR-D50/D30 only
** GR-D50/D40 only
AC Adapter
Power requirement
: AC 110 V to 240 V`, 50 Hz/60 Hz
Output : DC 11 V , 1 A
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject
to change without notice.
