JVC GR-D728EK - Controls, Connectors, and Indicators

EN 9
GETTING STARTED
MasterPage: Start_Right
GETTING STARTED
Controls
a : Left / Rewind [ 3 ] (墌 pg. 21) / Quick
Review [QUICK REVIEW] (墌 pg. 18)
: Right / Fast-Forward [ 5 ] (墌 pg. 21) /
LED Light [LIGHT] (墌 pg. 29)
: Up/Play/Pause [4/9] (墌 pg. 21) /
Manual Focus [FOCUS] (墌 pg. 29)
: Down / Stop [8] (墌 pg. 21) / Backlight
Compensation (墌 pg. 30) /
Spot Exposure (墌 pg. 30)
Press down: SET
B 16:9 Wide Screen Button [16:9] (墌 pg. 17)
Blank Search [BLANK] (墌 pg. 22)
C Menu Button [MENU] (墌 pg. 24)
D Data Battery Button [DATA] (墌 pg. 14)
E Auto Button [AUTO] (墌 pg. 20)
F Dioptre Adjustment Control (墌 pg. 15)
G Snapshot Button [SNAPSHOT] (墌 pg. 29)
H Power Zoom Lever [T/W] (墌 pg. 19)
Speaker Volume Control [VOL. +, –]
(墌 pg. 21)
I Recording Start/Stop Button [START/STOP]
(墌 pg. 18)
J Power Switch [REC, PLAY, OFF]
K Lock Button
L Battery Release Button [BATT.] (墌 pg. 13)
M Cassette Open/Eject Switch [OPEN/EJECT]
(墌 pg. 16)
Connectors
N Digital Video Connector [DV OUT] (i.LINK*)
(墌 pg. 33, 34)
* i.LINK refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.LINK
standard.
The connectors are located beneath the covers.
O DC Input Connector [DC] (墌 pg. 13)
P Audio/Video Output Connector
[AV] (墌 pg. 23, 33)
Indicators
Q POWER/CHARGE Lamp (墌 pg. 13)
Other Parts
R LCD Monitor (墌 pg. 8)
S Viewfinder (墌 pg. 15)
T Battery Pack Mount (墌 pg. 13)
U Shoulder Strap Eyelet (墌 pg. 12)
V Grip Strap (墌 pg. 12)
W Speaker (墌 pg. 21)
X Lens
Y LED Light
Z Camera Sensor
(Be careful not to cover this area, a sensor
necessary for shooting is built-in here.)
a Stereo Microphone
b Stud Hole (墌 pg. 16)
c Tripod Mounting Socket (墌 pg. 16)
d Cassette Holder Cover (墌 pg. 16)
e Connector Cover
Power Switch Position
REC:
To perform recording on the tape.
OFF:
To switch off the camcorder.
PLAY:
To play back a recording on the tape.
CONTINUED ON NEXT PAGE
