JVC GR-D750UC - Page 13

(No.YF173)1-13
Fig.3-2-4-2
<LCD SA>
CASE(B.LIGHT)
VF BOARD ASSY
VF SW
L4d
L4f
L4g
L4h
L4e
L4c
CASE(VF)
LCD SA
STOPPER(POLA)
CUSHION(2)
SHEET(POLA)
SHEET(DIFF.)
SHEET(POLA)
CUSHION(1)
LCD MODULE
HOLDER(LCD)
FPC
CN4
NOTE4f
NOTE4d
NOTE4e
