JVC GR-DVL100U Technical Guide

2-30
•
••
•
Deck DSP (IC3001: JCY0106-2) pin functions (2/6)
Pin No. Label In/Out Description
195 - - Not used
12 YSO [0]
80 YSO [1]
143 YSO [2]
232 YSO [3]
13 BRSO [0]
81 BRSO [1]
196 BRSO [2]
144 BRSO [3]
14 - - Not used
233 VDDS - Power supply
82 YSI [0]
197 YSI [1]
145 YSI [2]
15 YSI [3]
83 BRSI [0]
16 BRSI [1]
146 BRSI [2]
84 BRSI [3]
17 VDD - Power supply
147 OUTH Out Horizontal reference pulse output for DVC PB, (To CAMERA DSP: IC4301)
85 OUTV Out Vertical reference pulse output for DVC PB, (To CAMERA DSP: IC4301)
18 INH In Horizontal reference pulse input for DVC REC, (From CAMERA DSP: IC4301, )
148 INV In Vertical reference pulse input for DVC REC, (From CAMERA DSP: IC4301)
86 GND - Ground
19 VDD - Power supply
87 OSC27I In 27MHz clock input, (From CAMERA DSP: IC4301)
20 OSC27O - Open (Not used)
149 GND - Ground
196 VDD - Power supply
234 - - Not used
88 RAMADRS [0]
21 RAMADRS [1]
150 RAMADRS [2]
89 RAMADRS [3]
199 VDDS - Power supply
22 RAMADRS [4]
235 RAMADRS [5]
151 RAMADRS [6]
90 RAMADRS [7]
23 GND - Ground
200 RAMADRS [8]
152 RAMADRS [9]
Out DRAM address output, (To 16M_DRAM: IC3002)
Out DRAM address output, (To 16M_DRAM: IC3002)
Out DRAM address output, (To 16M_DRAM: IC3002)
Out DVC playback digital luminance signal output, (To CAMERA_DSP: IC4301)
DVC playback digital color difference signal output, (To CAMERA_DSP: IC4301)Out
DVC record digital luminance signal input
(From CAMERA_DSP: IC4301, ANALOG VIDEO I/O: IC3801)
DVC record digital color difference signal input
(From CAMERA_DSP: IC4301, ANALOG VIDEO I/O: IC3801)
In
In
Table 2-5-4 Deck DSP (IC3001: JCY0106-2) pin functions (2/6)
