EN
67
Controls
1 OPEN/EJECT Switch ............................ 墌 pg. 12
2 • Stop Button [5] .................................... 墌 pg. 19
• BACKLIGHT Button ............................. 墌 pg. 30
3 • Rewind Button [
2
] ............................. 墌 pg. 19
• NIGHT Button ...................................... 墌 pg. 24
4 Play/Pause Button [
4
/6] ....................... 墌 pg. 19
5 Fast-Forward Button [
3
] ...................... 墌 pg. 19
6 Monitor Open Button [PUSH OPEN] ..... 墌 pg. 15
7 Diopter Adjustment Control ................... 墌 pg. 10
8 Battery Release Button
[BATT. RELEASE] ................................... 墌 pg. 8
9 Recording Start/Stop Button .................. 墌 pg. 15
0 • MENU Wheel [+, –, PUSH].................. 墌 pg. 32
• LCD Monitor BRIGHT (Brightness)
Control [+, –] ........................................ 墌 pg. 15
! Snapshot Button
[SNAPSHOT] ................................... 墌 pg. 15, 28
@ • Power Zoom Lever [T/W]..................... 墌 pg. 17
• Speaker Volume Control [VOL.] .......... 墌 pg. 19
# • FOCUS Button..................................... 墌 pg. 29
• BLANK Button ..................................... 墌 pg. 22
$ Lock Button............................................ 墌 pg. 16
% Power Switch
[
AUTO
,
MANUAL
, PLAY, OFF] ................. 墌 pg. 16
Connectors
The connectors ^ to * are located beneath a cover.
^ Audio/Video Output Connector
[AV] ............................................ 墌 pg. 20, 38, 44
& J Terminal
[JLIP (Joint Level Interface Protocol)] .... 墌 pg. 44
You can also connect to a JLIP-compatible
camcorder or VCR to control it from the
computer using the optional Software HS-V16U.
* DC Input Connector ............................. 墌 pg. 8, 9
( Digital Video Connector
[DV IN/OUT] (i.Link*) ....................... 墌 pg. 39, 50
*i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.Link
standard.
) S-Video Output Connector
[S-VIDEO] .................................. 墌 pg. 20, 38, 44
q PC Connector ........................................ 墌 pg. 50
Indicators
w Tally Lamp ....................................... 墌 pg. 15, 34
e CHARGE Lamp ....................................... 墌 pg. 8
r Power Lamp..................................... 墌 pg. 15, 16
Other Parts
t • Remote Sensor.................................... 墌 pg. 40
• Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
y Viewfinder .............................................. 墌 pg. 10
u Stereo Microphone ................................ 墌 pg. 48
i Viewfinder Cleaning Hatch .................... 墌 pg. 58
o Shoulder Strap Eyelets .......................... 墌 pg. 10
p Grip Strap .............................................. 墌 pg. 10
Q LCD Monitor .................................... 墌 pg. 15, 16
W Speaker ................................................. 墌 pg. 19
E Battery Pack Mount ................................. 墌 pg. 8
R Stud Hole ............................................... 墌 pg. 10
T Tripod Mounting Socket ......................... 墌 pg. 10
