56 EN
USING THE REMOTE CONTROL UNIT
When using the remote control, be sure to point it
at the remote sensor. The illustration shows the
approximate transmitted beam effective area for
indoor use.
The transmitted beam may not be effective or
may cause incorrect operation outdoors or when
the remote sensor is directly exposed to sunlight
or powerful lighting.
Remote sensor
The Full-Function Remote Control Unit can operate
this camcorder from a distance as well as the basic
operations (Playback, Stop, Pause, Fast-Forward and
Rewind) of your VCR. It also makes additional
playback functions possible.
Installing The Batteries (provided)
The remote control uses two ”AAA (R03)” size
batteries. See “General Battery Precautions”
(墌 pg. 85).
1
Open the battery compartment cover as
illustrated.
2
Insert two ”AAA (R03)” size batteries in the
correct direction.
3
Replace the battery compartment cover.
30°
30°
Transmitted beam
effective area
5 m (16 ft)
1
3
2
+
–
+
–
Tab
