Notes: Mark — is not used.
Mark * reference model was also changed.
2
!
REF. MODEL
GR-DVL510U GR-DVL512U
NO. ITEM
PW MAIN BOARD ASSY *YB10317B-03 YB10317B-04
IC1401 IC *YQ44881A YQ44882A
IC1403 IC *SN74AHC2G53T —
R1410 MG RESISTOR *NRSA6AJ-331W —
R1411 MG RESISTOR *NRSA6AJ-473W —
R1412 MG RESISTOR *NRSA6AJ-331W —
R1413 MG RESISTOR *— NRSA6AJ-331W
R6014 MG RESISTOR *— NRSA63J-0R0X
R8013 MG RESISTOR *NRSA6AJ-821W —
C1008 CAPACITOR *NCBA1CK-103W —
C1013 CAPACITOR *NCBA1CK-103W —
C1018 CAPACITOR *NCBA1CK-103W —
C1024 CAPACITOR *NDCA1HJ-100W —
C1025 CAPACITOR *NDCA1HJ-100W —
C8030 CAPACITOR *NDCA1HJ-150W —
X1001 C OSCILLATOR *NAX0424-001X NAX0474-001X
S6001 SLIDE SWITCH *NSW0096-001X —
MAIN BOARD ASSEMBLY <01>
!
REF. MODEL
GR-DVL510U GR-DVL512U
NO. ITEM
PW1 MONITOR BOARD ASSY *YB10324H1-03 YB10326H-01
C7616 CAPACITOR *NCB31HK-102X NCB31EK-103X
C7640 CAPACITOR *— NCB31EK-103X
CN766 SD CARD CONNECTOR *NNZ0052-001X NNZ0058-001X
MONITOR BOARD ASSEMBLY <02>
!
REF. MODEL
GR-DVL510U GR-DVL512U
NO. ITEM
PW2 LCD BL BOARD ASSY *YB10324B2-02 YB10325B
LCD BL BOARD ASSEMBLY <03>
!
REF. MODEL
GR-DVL510U GR-DVL512U
NO. ITEM
PW1 JACK BOARD ASSY *YB10314B1-01 YB10314B1-03
HD1 HOLDER(J.PWB) *LY32086-001ALY32086-001B
JACK BOARD ASSEMBLY <06>
