COVER(ZOOM) Fig.1-3-1 (S1a),(S1b),2(L1a),2(L1b ) -
ASSY
2
UPPER CASE ASSY
Fig.1-3-2 (S2a),(S2b),(L2),(S2c) NOTE2
( Inc.E.VF UNIT 2(S2a),(S2d),4(S2a)
(B/W,COLOR), CAP(DC JACK)
SPEAKER/ 聽CN 2a
MONITOR)
3
FRONT COVER Fig.1-3-3 COVER(JACK),3(S3),(L3a) NOTE3a
ASSY (L3b),聽CN 3a NOTE3b
(Inc.DC LIGHT,MIC)
4
OP BLOCK ASSY Fig.1-3-4 聽CN 4a , 4b -
/BRACKET(OP) 2(S4),2(L4)
ASSY
5
REAR UNIT Fig.1-3-5 聽CN 5a NOTE5
4(S5)
6
LOWER CASE ASSY
Fig.1-3-6 聽CN 6a , 6b , 6c -
(Inc.ZOOMUNIT) (S6a),2(S6b),2(S6c)
/(L6a),(L6b)
7
JACK BOARD ASSY
(S7) NOTE7
8
JUNCTION BOARD
Fig.1-3-7 聽CN 8a , 8b , 8c NOTE8a
ASSY 2(S8),聽CN 8d NOTE8b
9
MAIN BOARD ASSY
Fig.1-3-8 (S9a),(L9a),SHIELD PLATE -
/ 聽CN 9a , 9b , 9c
0
/MECHANISM ASSY
2(S9b),(L9b),(L9c)
!
E.VF UNIT Fig.1-3-9 聽CN 11a ,(S!a),(S!b) NOTE!a
/(L!) NOTE!b
@
SPEAKER (S
@
),PLATE(SPK) -
聽CN 12a
#
MONITOR ASSY Fig.1-3-10 2(S#a),COVER(HINGE) NOTE#
/ 聽CN 13a , 2(S#b)
$
MONITOR BOARD 3(S$),(L$) NOTE$a
ASSY NOTE$b
NOTE$c
NOTE$d
STEP
No.
PART
Fig.No.
POINT NOTE
1.3.2 Disassembly method
Table-1-3-2
----------------- --------------------------------------
----------------- --------------------------------------
----------------- --------------------------------------
NOTE
2
:
Remove the CAP (DC JACK) before removing
these parts .
NOTE
3
a:
As it is difficult to remove (L
3
b), remove the
F. COVER ASSY by lowering it.
NOTE
3
b:
Be careful not to damage any parts.
Particularly, take care not to scratch or stain the
lenses.
NOTE
5
:
As screw No. 19 is hidden behind the cassette
cover, open the cassette cover to enable re-
moval of the screw.
NOTE
7
:
As screw No. 27 is hidden behind the cassette
cover, open it before removing the screw.
NOTE
8
a:
As the CN572 is located at the back of the as-
sembly, unplug the three connectors and re-
move the screws before disconnecting the
CN572.
NOTE
8
b:
Be careful not to damage any of the switches.
NOTE
!
a:
To remove the unit, unlock the connector and
pull out the unit together with the FPC.
NOTE
!
b:
When removing the unit, insert the FPC into the
gap.
NOTE
#
:
When reassembling the MONITOR ASSY, be
careful not to damage any of the parts.
NOTE
$
a:
To remove the assembly, pull the memory card
out in advance. (MMC compatible models only)
NOTE
$
b:
Be careful not to damage any of the parts.
NOTE
$
c:
Be careful not to damage any of the parts.
SW KNOB(DC LIGHT: Gray)
NOTE
$
d:
Be careful not to damage any of the parts.
SW KNOB(VIDEO-DSC: Violet)
CONN.
No.
Pin No.
CONNECTOR
Table-1-3-3
Note:
Remove the parts marked in .
2a MAIN CN101 ⇔ MONITOR CN761 50
3a MAIN CN106 ←→ MIC — 3
4a MAIN CN107 ⇔ CCD — 20
4b MAIN CN108 ⇔ OP BLOCK ASSY — 24
5a MAIN CN104 ←→ REAR UNIT CN1 10
6a MAIN CN109 ⇔ ZOOM UNIT — 15
6b MAIN CN102 ←→ JACK CN501 9
6c JACK CN502 ⇔ MAIN CN103 14
8a JUNCTION CN571 ⇔ MAIN CN113 34
8b JUNCTION CN574 ⇔
LOADING MOTOR
—6
8c JUNCTION CN573 ⇔ DRUM MOTOR — 11
8d JUNCTION CN572 ⇔ SENSOR — 15
9a MAIN CN110 ⇔ HEAD — 8
9b MAIN CN112 ⇔ CAPSTAN MOTOR — 18
9c MAIN CN111 ⇔ ROTARY ENCODER — 6
11a MONITOR CN763 ⇔
E.VF UNIT (C_B/W)
CN721/CN751
20
12a MONITOR CN765 ←→ SPEAKER — 2
13a MONITOR CN764 ⇔ LCD BL CN751 33/32
Fig. 1-3-1
1
1
(S
1
a)
2
(S 1
b)
(L 1
a)
(L 1
b)
