EN61
Controls
1 Monitor Open Button [PUSH OPEN] ... pg. 12
2 Dioptre Adjustment Control ................... pg. 8
3 Battery Release Button
[BATTERY RELEASE] .............................. pg. 7
4 MENU Wheel [+, –, PUSH] ............... pg. 20
LCD Monitor BRIGHT
(Brightness) Control [+, –] .................. pg. 12
5 Snapshot Button [SNAPSHOT] ....... pg. 14, 15
6 Power Zoom Lever [T/W] .................. pg. 16
Speaker Volume Control [VOL.] ........ pg. 29
7 Snapshot Mode Button [MODE] ........... pg. 14
8 OPEN/EJECT Switch ............................. pg. 10
9 Stop Button [5] ................................... pg. 29
0 Rewind Button [
2
] ......................... pg. 29
BACKLIGHT Button .......................... pg. 27
! Play/Pause Button [
4
/6] ...................... pg. 29
@ Fast-Forward Button [
3
] ................. pg. 29
FOCUS Button .................................. pg. 19
# Power Switch [
, , , OFF] ...... pg. 13
$ Recording Start/Stop Button .................. pg. 12
% Lock Button ......................................... pg. 12
^ Video Light Switch
[LIGHT OFF/AUTO/ON] ...................... pg. 18
Connectors
To connect cables to the following connectors
&
and
*
,
open the LCD monitor.
& PC (DIGITAL PHOTO) Connector ........ pg. 34
* J Terminal/Edit Connector [JLIP (Joint Level
Interface Protocol)/EDIT] ...................... pg. 44
Connect the editing cable when performing
Random Assemble Editing.
Connect to a JLIP-compatible camcorder or VCR
to control it from the computer using the
provided Software.
( DC Input Connector .............................. pg. 7
The connectors ) to w are located beneath a cover.
) Audio/Video Output Connector
[AV] ........................................ pg. 32, 36, 44
q Digital Video Connector
[DV IN/OUT] (i.link*) ........ pg. 34, 35, 37, 38
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The
logo
is used for products compliant with the i.Link
standard.
w S-Video Output Connector [S] ... pg. 32, 36, 44
Indicators
e Tally Lamp ........................................... pg. 12
r Side LED Indicator
(GR-DVL600/DVL500/DVL400 only) ... pg. 22
t Power Lamp ........................................ pg. 12
Other Parts
y Remote Sensor .................................. pg. 39
Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
u Viewfinder ............................................. pg. 8
i Video Light .......................................... pg. 18
o Stereo Microphone .............................. pg. 49
p Shoulder Strap Eyelets ............................ pg. 8
Q Grip Strap .............................................. pg. 8
W Battery Pack Mount ............................... pg. 7
E LCD Monitor ................................. pg. 12, 13
R Speaker ............................................... pg. 29
T Stud Hole .............................................. pg. 8
Y Tripod Mounting Socket ......................... pg. 8
