JVC GR-DVL820

50 EN
RE NEON SC LCD / TV
UAOTIMETDATE /
T I ME CODE
–
–
–FFO
NRETUR
BEEP MELODY
NOTALLY
–
–
ID UNMERB–
60
DEMO MODE – NO
–NOSID L EED
NRETUR
CAM ERSET
MDOESOUND
MDOE
12 BIT
ROSYNCH
ODEREC M
COPY
STEREO–
SOUND
1
SP
OFF
–
–
–
–
OFF–
NRETUR
O.O
MSYSTE
AYDISPL
VIDEO SOUND MODE
MODE
MODE
12 BIT
NPUT
S/ AV I
SYNC ROH
REC
END
COPY
NPUT
S/ AV I
For Playback Menu
The following procedure applies to all except Synchro
Comp (Z pg. 62).
1 Set the VIDEO/MEMORY Switch to “VIDEO” (GR-
DVL1020/DVL820/DVL520 only), then set the Power
Switch to “PLAY” while pressing down the Lock
Button located on the switch.
2 Press the MENU/BRIGHT wheel in. The Menu
Screen appears.
3 Rotate the MENU/BRIGHT wheel to select the
desired function menu, and press it. The selected
function menu appears.
4 Rotate the MENU/BRIGHT wheel to select the
desired function, and press it to display the Sub Menu.
5 Rotate the MENU/BRIGHT wheel to select the
desired parameter and press it. Selection is complete.
6 Rotate the MENU/BRIGHT wheel to select “
RETURN” and press it twice to close the Menu Screen.
Display
Power Switch
MENU/BRIGHT Wheel
Recording
Start/Stop Button
NOTES:
● The date indication can also be turned on/off by
pressing DISPLAY on the remote control (provided).
● “REC MODE” can be set when the Power Switch is set
to “PLAY” or “
MANUAL
” (Z pg. 13, 47).
Menu Screen Explanations
Z pg. 51.
Z pg. 51.
Z pg. 62.
Allows you to set the tape
recording mode (SP or LP)
depending on your preference
(
Z pg. 13). It is recommended
you use “REC MODE” in the
“
VIDEO” Menu when using
this camcorder as a recorder
during dubbing (Z pg. 53).
ON: Enables dubbing of images
recorded on a tape to a memory
card (
Z pg. 32).
OFF: Enables snapshots to be
taken during tape playback.
ON: Enables audio/video signal
input from the AV and S-VIDEO
connectors (
Z pg. 52).
OFF: Enables audio/video signal
output to a TV, VCR, etc. via the
AV and S-VIDEO connectors
(Z pg. 22, 52).
SOUND MODE
12BIT MODE
SYNCHRO
REC MODE
COPY
(GR-DVL1020/
DVL820/DVL520
only)
S/AV INPUT
(GR-DVL1020/
DVL820 only)
SYSTEM DISPLAY
Each setting is linked with “
DISPLAY” or “ SYSTEM”, which
appears when the Power Switch is
set to “
MANUAL
” (Z pg. 48, 49).
The parameters are the same as in
the description on pg. 48, 49.
VIDEO
USING MENUS FOR DETAILED ADJUSTMENT (cont.)
Lock Button
* Actual menus differ by model and may appear
differently from these illustrations. Some menu items
may be unavailable on your model.
VIDEO/MEMORY Switch
(GR-DVL1020/DVL820/DVL520 only; open
the LCD monitor to access this switch.)
