Controls
1 OPEN/EJECT Switch ............................ Z pg. 12
2 • Stop Button [5] .................................... Z pg. 21
• BACKLIGHT Button ............................. Z pg. 44
3 • Rewind Button [
2
] ............................. Z pg. 21
• NIGHT Button ...................................... Z pg. 38
4 Play/Pause Button [
4
/6] ....................... Z pg. 21
5 Fast-Forward Button [
3
] ..................... Z pg. 21
6 Monitor Open Button [PUSH OPEN] ..... Z pg. 16
7 Dioptre Adjustment Control .................... Z pg. 10
8 Battery Release Button
[BATT. RELEASE] ................................... Z pg. 8
9 Recording Start/Stop Button .................. Z pg. 16
0 • MENU Wheel [+, –, PUSH] .................. Z pg. 46
• LCD Monitor BRIGHT (Brightness)
Control [+, –] ........................................ Z pg. 16
! Snapshot Button
[SNAPSHOT] ....................... Z pg. 26, 27, 32, 42
@ • Power Zoom Lever [T/W]..................... Z pg. 18
• Speaker Volume Control [VOL.] .......... Z pg. 21
# • FOCUS Button..................................... Z pg. 43
• BLANK Button ..................................... Z pg. 24
$ Lock Button............................................ Z pg. 17
% Power Switch
[
AUTO
,
MANUAL
, PLAY, OFF] ................. Z pg. 17
^ INDEX Button
(GR-DVL1020/DVL820/DVL520 only) ... Z pg. 29
& INFO Button
(GR-DVL1020/DVL820/DVL520 only) ... Z pg. 29
* VIDEO/MEMORY Switch [VIDEO, MEMORY]
(GR-DVL1020/DVL820/DVL520 only) ... Z pg. 17
( E-MAIL Button
(GR-DVL1020/DVL820 only) ................. Z pg. 33
) SELECT Button
(GR-DVL1020/DVL820 only) ................. Z pg. 28
q Video Light Switch
[LIGHT OFF/AUTO/ON]......................... Z pg. 19
Connectors
The connectors w to r are located beneath a cover.
w Audio/Video Input (GR-DVL1020/DVL820 only)/
Output Connector [AV] ............... Z pg. 22, 52, 59
e • J Terminal [JLIP (Joint Level Interface Protocol)]
(GR-DVL320 only) ............................... Z pg. 59
You can also connect to a JLIP-compatible
camcorder or VCR to control it from the
computer using the optional Software
HS-V16KITE.
• Edit Connector [EDIT]
(GR-DVL1020/DVL820/DVL520 only) . Z pg. 59
r DC Input Connector ............................. Z pg. 8, 9
t Digital Video Connector
[DV IN/OUT] (i.Link*) ....................... Z pg. 53, 65
*i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.Link
standard.
y S-Video Input (GR-DVL1020/DVL820 only)/
Output Connector [S-VIDEO] .... Z pg. 22, 52, 59
u • PC Connector
(GR-DVL320 only) ............................... Z pg. 65
• USB (Universal Serial Bus) Connector
(GR-DVL1020/DVL820/DVL520 only)
....................................................... Z pg. 65, 66
Indicators
i Tally Lamp ....................................... Z pg. 16, 48
o CHARGE Lamp ....................................... Z pg. 8
p Side LED Indicator
(GR-DVL1020/DVL820 only) ................. Z pg. 49
Q Power Lamp .................................... Z pg. 16, 17
Other Parts
W • Remote Sensor.................................... Z pg. 54
• Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
E Viewfinder .............................................. Z pg. 10
R Video Light............................................. Z pg. 19
T Stereo Microphone ................................ Z pg. 63
Y Viewfinder Cleaning Hatch .................... Z pg. 74
U Shoulder Strap Eyelets .......................... Z pg. 10
I Grip Strap .............................................. Z pg. 10
O LCD Monitor .................................... Z pg. 16, 17
P Speaker ................................................. Z pg. 21
a Battery Pack Mount ................................. Z pg. 8
s Stud Hole ............................................... Z pg. 10
d Tripod Mounting Socket......................... Z pg. 10
f MEMORY CARD Cover
(GR-DVL1020/DVL820/DVL520 only) ... Z pg. 14
