2
MONITOR ASSEMBLY <M5>
500 MONITOR ASSY LYH20246-043B LYH20246-042B
501 MONITOR COVER ASSY LY20863-001B LY20864-001C
501F EARTH MON LY43784-001A LY43785-001A
501G WINDOW(M.MEGA) LY32704-001A LY32704-002A
501H PLATE LY32706-001B LY32707-001B
502 MONITOR CASE ASSY LY20874-001A LY20598-002A
504 HOLDER LY20674-001A LY20568-001A
506 BACK LIGHT QLL0121-001 QLL0123-001
507 LCD MODULE QLD0154-001 QLD0203-001
511 SPACER(A) —
*
LY30029-0Y4A
* * *
———
512 SPACER(A) —————LY30029-0Y6A
!
REF.
MODEL
GR-DVL765EG-X GR-DVL820A GR-DVL820A-S GR-DVL820EA GR-DVL820SH GR-DVL1020A GR-DVL1020EA GR-DVL1020SH
NO.
ITEM
MAIN BOARD ASSEMBLY <01>
PW MAIN BOARD ASSY YB10391QC YB10391PD-01 YB10391QD-03
!
REF.
MODEL
GR-DVL765EG-X GR-DVL820A GR-DVL820A-S GR-DVL820EA GR-DVL820SH GR-DVL1020A GR-DVL1020EA GR-DVL1020SH
NO.
ITEM
MONITOR BOARD ASSEMBLY <02>
PW MONITOR BOARD ASSY YB10360PG-02 YB10360PJ
IC7101 IC(DIGITAL) TC7SH32FU ——
Q7101 TRANSISTOR 2SA1774/QR/-X ——
Q7102 TRANSISTOR 2SC4617/QR/-X ——
R7110 MG RESISTOR NRSA63J-562X ——
R7111 MG RESISTOR NRSA63J-0R0X ——
R7113 MG RESISTOR NRSA63J-0R0X ——
R7114 MG RESISTOR NRSA63J-271X ——
R7116 MG RESISTOR NRSA63J-102X ——
R7604 MG RESISTOR —————NRSA63J-0R0X
R7612 CMF RESISTOR NRVA63D-223X NRSA63D-682X
R7624 CMF RESISTOR —————NRVA63D-223X
R7625 CMF RESISTOR —————NRVA63D-223X
R7626 CMF RESISTOR —————NRVA63D-183X
R7627 CMF RESISTOR —————NRVA63D-334X
R7634 MG RESISTOR —————NRSA63J-0R0X
R7635 MG RESISTOR —————NRSA63J-0R0X
R7636 MG RESISTOR NRSA63J-101X NRSA63J-221X NRSA63J-101X
R7637 MG RESISTOR NRSA63J-101X NRSA63J-221X NRSA63J-101X
R7638 MG RESISTOR NRSA63J-101X NRSA63J-221X NRSA63J-101X
R7640 MG RESISTOR —————NRSA63J-0R0X
R7643 MG RESISTOR —————NRSA63J-0R0X
R7644 MG RESISTOR —————NRSA63J-0R0X
R7645 MG RESISTOR —————NRSA63J-0R0X
R7646 MG RESISTOR —————NRSA63J-0R0X
C7101 CAPACITOR NDC31HJ-221X ———
C7102 CAPACITOR NCF31CZ-104X ———
C7636 CAPACITOR —————NCF31CZ-104X
C7638 CAPACITOR —————NCB21AK-225X
C7639 T CAPACITOR —————NBE21AM-106X
L7605 COIL NQL365K-100X ——
L7606 COIL —————NQL365K-100X
OT2 SPACER — LY43869-001A
!
REF.
MODEL
GR-DVL765EG-X GR-DVL820A GR-DVL820A-S GR-DVL820EA GR-DVL820SH GR-DVL1020A GR-DVL1020EA GR-DVL1020SH
NO.
ITEM
DSC BOARD ASSEMBLY <10>
PW DSC BOARD ASSY YB20931F-01 YB20931D-01
IC8003 IC(MICRO C ROM) MBV160TE90PTA29 MBV160TE90PTA41
IC8007 IC MM1385EN ———
IC8301 IC —————ISP1181ADGG
Q8001 DIGI TRANSISTOR DTA114EE ———
R8020 MG RESISTOR NRSA6AJ-0R0W ———
R8027 MG RESISTOR NRSA6AJ-152W ———
R8028 MG RESISTOR NRS181J-270X ———
R8029 MG RESISTOR NRS181J-270X ———
R8030 MG RESISTOR NRSA6AJ-105W NRSA6AJ-0R0W
R8031 MG RESISTOR NRSA6AJ-105W NRSA6AJ-0R0W
R8036 MG RESISTOR NRSA6AJ-105W ———
R8056 MG RESISTOR —————NRSA6AJ-0R0W
R8074 MG RESISTOR —————NRSA6AJ-473W
R8302 MG RESISTOR —————NRS181J-220X
R8303 MG RESISTOR —————NRS181J-220X
R8305 MG RESISTOR —————NRSA6AJ-105W
R8306 MG RESISTOR —————NRSA6AJ-103W
R8307 MG RESISTOR —————NRSA6AJ-103W
R8308 MG RESISTOR —————NRSA6AJ-103W
R8309 MG RESISTOR —————NRSA6AJ-103W
R8311 MG RESISTOR —————NRSA6AJ-0R0W
C8027 CAPACITOR NCB30JK-105X ———
C8028 CAPACITOR NCBA1AK-104W ———
C8029 T CAPACITOR NBE20JM-106X ———
C8301 T CAPACITOR —————NBE20JM-106X
C8305 CAPACITOR —————NCBA1AK-104W
C8306 CAPACITOR —————NCBA1AK-104W
C8307 CAPACITOR —————NCBA1AK-104W
C8310 CAPACITOR —————NCBA1AK-104W
C8311 CAPACITOR —————NCBA1AK-104W
L8301 FERRITE BEAD —————NQR0129-002X
X8002 C OSCILLATOR NAX0398-001X ———
X8301 RESONATOR —————NAX0522-001X
!
REF.
MODEL
GR-DVL765EG-X GR-DVL820A GR-DVL820A-S GR-DVL820EA GR-DVL820SH GR-DVL1020A GR-DVL1020EA GR-DVL1020SH
NO.
ITEM
Notes : Mark is same as left. Mark — is not used. Mark * reference model was also changed.
