JVC GR-DVL910A - DVL510 EA Only)

EN91
For Digital Still Camera (GR-DVL910A/DVL510A/DVL910EA/DVL510EA only)
Storage media : SD Memory Card/MultiMediaCard
Compression system : JPEG (compatible)
File size : VGA (640 x 480 pixels)
Picture quality : 2 modes (FINE/STANDARD)
Approximate number of storable images
with memory card [8 MB] (provided)
FINE : 100
STANDARD : 200
with memory card [16 MB] (optional)
FINE : 200
STANDARD : 400
with memory card [32 MB] (optional)
FINE : 400
STANDARD : 800
with memory card [64 MB] (optional)
FINE : 800
STANDARD : 1600
For Connectors
S-Video
Output : Y : 1 V (p-p), 75 Ω, analogue
C : 0.29 V (p-p), 75 Ω, analogue
Input (GR-DVL910A/DVL510A/ : Y : 0.8 V (p-p) – 1.2 V (p-p), 75 Ω, analogue
DVL910EA/DVL510EA only) C : 0.2 V (p-p) – 0.4 V (p-p), 75 Ω, analogue
AV
Video output :1 V
( p-p ) , 75 Ω, analogue
Video input (GR-DVL910A/DVL510A/DVL910EA/DVL510EA only)
: 0.8 V
( p-p ) – 1.2 V ( p-p ) , 75 Ω, analogue
Audio output : 300 mV (rms), 1 kΩ, analogue, stereo
Audio input (GR-DVL910A/DVL510A/DVL910EA/DVL510EA only)
: 300 mV (rms), 50 kΩ, analogue, stereo
DV
Output : 4-pin, IEEE 1394 compliant
Input : 4-pin, IEEE 1394 compliant
USB (GR-DVL910A/DVL510A/DVL910EA/DVL510EA only)
: 5-pin
PC (DIGITAL PHOTO)
(GR-DVL450A/DVL313A/DVL310A/DVL210A/DVL210EA only)
: ø2.5 mm, 3-pole
EDIT (GR-DVL910A/DVL510A/DVL910EA/DVL510EA only)
: ø3.5 mm, 2-pole
JLIP (GR-DVL450A/DVL313A/DVL310A/DVL210A/DVL210EA only)
: ø3.5 mm, 4-pole
AC Adapter AP-V10A or AP-V10EA
Power requirement : AC 110 V to 240 V`, 50 Hz/60 Hz
Output : DC 11 V
, 1 A
Dimensions (W x H x D) : 59 mm x 31 mm x 84 mm
Weight : Approx. 140 g (not including Power Cord)
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject
to change without notice.
