EN 85
AC Charger Station
General
Power : AC 110 to 240 V`, 50/60 Hz
Power consumption : 20 W
Output power : DC 7.2 V
, 0.77 A (charge)
DC 6.3 V , 1.8 A (VTR)
Operating temperature : 0°C to 40°C
(when charging, 10°C to 35°C)
Dimensions : 80 mm (W) x 39 mm (H) x 146 mm (D)
Weight : Approx. 410 g
Connectors
S-Video : Y: 1Vp-p, 75 Ω, analogue output
C: 0.29 Vp-p, 75 Ω, analogue output
Video : 1Vp-p, 75 Ω, analogue output
Audio : –8 dBs, 1 kΩ, analogue output
JLIP : ø3.5 mm, 4-pole, mini-head jack (compatible with RC-5325 plug)
Editing : ø3.5 mm diameter, 2-pole
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications
subject to change without notice.
