EN 13
Align the screw on the tripod with the camcorder’s
mounting socket. Then tighten the screw.
● Some tripods are not equipped with studs.
While using the LCD monitor:
Make sure the viewfinder is pushed back in. Open
the LCD monitor fully. It can rotate 270º (90º
downward, 180º upward).
While using the viewfinder:
Make sure the LCD monitor is closed and locked.
Pull out the viewfinder fully.
● Be sure to pull out the viewfinder until you hear a
click, otherwise it may be pushed back in during
use.
Press MONITOR BRIGHT + or – until the bright
level indicator on the display moves and the
appropriate brightness is reached.
● It is also possible to adjust the brightness of the
viewfinder.
Tripod Mounting
CAUTION:
When attaching the camcorder to a tripod, extend
its legs to stabilise the camcorder. It is not advised
to use small sized tripods. This may cause damage
to the unit by falling over.
LCD Monitor And Viewfinder
Brightness Adjustment Of The
Display
180˚
90˚
To Next Page
