EN 93
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject
to change without notice.
For Connectors
S/AV
S-Video input : Y: 0.8 V to 1.2 V (p-p), 75 Ω, analogue
C: 0.2 V to 0.4 V (p-p), 75 Ω, analogue
S-Video output : Y: 1.0 V (p-p), 75 Ω, analogue
C: 0.3 V (p-p), 75 Ω, analogue
Video input : Y: 0.8 V to 1.2 V (p-p), 75 Ω, analogue
Video output : Y: 1.0 V (p-p), 75 Ω, analogue
Audio input : 300 mV (rms), 50 kΩ, analogue, stereo
Audio output : 300 mV (rms), 1 kΩ, analogue, stereo
Edit : ø3.5 mm, 2-pole
Headphone output :Stereo
DV
Input/output : 4-pin, IEEE 1394 compliant
USB :5-pin
AC Power Adapter/Charger
For General
Power requirement : AC 110 V to 240 Vd, 50 Hz/60 Hz
Power consumption :23W
Output
Charge : DC 7.2 V G, 1.2 A
VTR : DC 6.3 V G, 1.8 A
Weight : Approx. 260 g (AA-V100EA)
Approx. 250 g (AA-V100A)
Approx. 250 g (AA-V100A-S)
Approx. 325 g (AA-V100SH)
Approx. 250 g (AA-V100ED)
