1 Make sure all units are turned off.
2 Connect the camcorder to a TV or VCR as shown
in the illustration. (墌 pg. 24)
If using a VCR, go to step 3.
If not, go to step 4.
3 Connect the VCR output to the TV input,
referring to your VCR’s instruction manual.
4 Turn on the camcorder, the VCR and the TV.
5 Set the VCR to its AUX input mode, and set the
TV to its VIDEO mode.
To choose whether or not the following displays
appear on the connected TV…
● Date/Time
Set “DATE/TIME” to “AUTO”, “ON” or “OFF”.
(墌 pg. 49)
Or, press DISPLAY on the remote control to turn
on/off the date indication.
● Time Code
Set “TIME CODE” to “ON” or “OFF”. (墌 pg. 49)
● Playback sound mode, tape speed and tape
running displays for video playback
Set “ON SCREEN” to “LCD” or “LCD/TV”.
(墌 pg. 49)
NOTES:
● It is recommended to use the AC Adapter as the
power supply instead of the battery pack.
(墌 pg. 11)
● To monitor the picture and sound from the
camcorder without inserting a tape or memory
card, set the camcorder’s Power Switch to “A” or
“M”, then set your TV to the appropriate input
mode.
● Make sure you adjust the TV sound volume to its
minimum level to avoid a sudden burst of sound
when the camcorder is turned on.
● If you have a TV or speakers that are not specially
shielded, do not place the speakers adjacent to the
TV as interference will occur in the camcorder
playback picture.
● While the Audio/Video cable is connected to the
AV connector, sound cannot be heard from the
speaker.
NOTE:
How to open the LCD monitor when using the
connectors beneath the cover...
1) Open the connector cover.
2) Pull out the connector cover fully.
3) Rotate the connector cover 90° to the left.
4) Open the LCD Monitor.
GR-DVX707EG_18-25.fm Page 25 Thursday, January 31, 2002 11:52 AM
