JVC GR-DVX44EG Service Manual

2
Notes : Mark is same as left.
Mark — is not used.
Mark * reference model was also changed.
!
REF. MODEL
GR-DVX44EG GR-DVX48A GR-DVX48A-S GR-DVX48EA GR-DVX49A
NO. ITEM
IC1401 CSP IC ASSY YQ44887A *YQ44888A * * *
R1413 MG RESISTOR — *NRSA6AJ-331W * * *
R6014 MG RESISTOR — *NRSA63J-0R0X * * *
C3001 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
C3005 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
C3008 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
C3035 CAPACITOR NDCA1HJ-270W *NDCA1HJ-180W * * *
C3501 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
C3502 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
C3503 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
C3701 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
C4305 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
C4307 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
C4310 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
C4315 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
C4324 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
C4331 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
C6003 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
OT7 SPACER(A) — *LY30029-0Q4A * * *
MAIN BOARD ASSEMBLY <01>
!
REF. MODEL
GR-DVX44EG GR-DVX48A GR-DVX48A-S GR-DVX48EA GR-DVX49A
NO. ITEM
C4803 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
C4851 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
C4861 T CAPACITOR NCBA1HK-102W * NCBA1CK-103W * * *
C4862 T CAPACITOR NCBA1HK-102W * NCBA1CK-103W * * *
C4864 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
MDA BOARD ASSEMBLY <02>
!
REF. MODEL
GR-DVX44EG GR-DVX48A GR-DVX48A-S GR-DVX48EA GR-DVX49A
NO. ITEM
PW2 JUNCTION BOARD ASSY YB10323B2-01 *YB10323B2-02
JUNCTION BOARD ASSEMBLY <06>
!
REF. MODEL
GR-DVX44EG GR-DVX48A GR-DVX48A-S GR-DVX48EA GR-DVX49A
NO. ITEM
C2108 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
C2207 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
C2208 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
C2211 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
C2214 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
C2402 T CAPACITOR NBE20JM-106X *NBE80JM-106X * * *
AUDIO BOARD ASSEMBLY <08>
!
REF. MODEL
GR-DVX44EG GR-DVX48A GR-DVX48A-S GR-DVX48EA GR-DVX49A
NO. ITEM
PW1 JACK BOARD ASSY YB10323C1 *YB10323C1-01
JACK BOARD ASSEMBLY <09>
The following table indicate different parts number between models GR-DVX88EG, GR-DVX78A, GR-DVX78A-S and GR-DVX78EA.
!
REF. MODEL
GR-DVX88EG GR-DVX78A GR-DVX78A-S GR-DVX78EA
NO. ITEM
1 PACKING CASE LY32032-007A LY32032-009A LY32032-022A
4 POLY BAG QPA02003006 QPA02003506 QPA02003006
9 WARRANTY CARD BT-54013-2 ——BT-56001-2
11 CD ROM LY32210-004A *LY32210-004B * *
! 12 AC ADAPTER LY20688-013A LY20688-003A LY20688-014A LY20688-007A
14 JACK BOX LY32142-001A *LY32142-001B * *
! 28 POWER CORD QMPL120-190-JR QMPS110-190-JR QMPH020-190-JR
29 ADAPTER PLUG QAM0302-001 ———
31 SER.NET CARD ———BT-56002-2
32 CORE FILTER — QQR0918-001
33 SHEET(CON.PLUG) — LYT0609-001A —
! 34 CONVERSION PLUG — PEMC1012-02 PEMC1012 —
PACKING AND ACCESSORY ASSEMBLY <M1> Note: As for IB (INSTRUCTIONS), refer to sec.5.
