JVC GR-DVX44EG Service Manual

Notes : Mark is same as left.
Mark — is not used.
Mark * reference model was also changed.
!
REF. MODEL
GR-DVX88EG GR-DVX78A GR-DVX78A-S GR-DVX78EA
NO. ITEM
! 101 LOWER CASE ASSY LY20727-001A *LY20727-001B * *
191 PLATE LY42906-003A LY42906-007A
215 STICKER LY43130-002A LY43130-004A
216 SPACER(A) LY30029-0H7B *LY30029-0H7C * *
220 FRONT COVER ASSY LY20731-003B LY20731-001D
220H COVER(AV) LY32136-003A LY32136-006A
221 SCREW QYSPSGT1740Z QYSPSGT1740R
229 SCREW QYSPSGT1735Z * QYSPSGT1730Z * *
231 SCREW QYSPSGT1735Z * QYSPSGT1730Z * *
FINAL ASSEMBLY <M2>
!
REF. MODEL
GR-DVX88EG GR-DVX78A GR-DVX78A-S GR-DVX78EA
NO. ITEM
PW MAIN BOARD ASSY YB10319B-02 YB10319C-02
MAIN BOARD ASSEMBLY <01>
!
REF. MODEL
GR-DVX88EG GR-DVX78A GR-DVX78A-S GR-DVX78EA
NO. ITEM
IC4804 IC UPC358G2/5/-W *NJM3414AG * *
R4836 MG RESISTOR NRSA6AJ-102W * NRSA6AJ-0R0W * *
C4803 T CAPACITOR NBE20JM-106X *NBE80JM-106X * *
C4851 T CAPACITOR NBE20JM-106X *NBE80JM-106X * *
C4861 CAPACITOR NCBA1HK-102W * NCBA1CK-103W * *
C4862 CAPACITOR NCBA1HK-102W * NCBA1CK-103W * *
C4864 T CAPACITOR NBE20JM-106X *NBE80JM-106X * *
MDA BOARD ASSEMBLY <02>
!
REF. MODEL
GR-DVX88EG GR-DVX78A GR-DVX78A-S GR-DVX78EA
NO. ITEM
PW2 JUNCTION BOARD ASSY YB10323A2-01 *YB10323C2-02 * *
D8502 ZENER DIODE — *UMZ6.8EN * *
C8502 T CAPACITOR NBE20JM-106X *NBE80JM-106X * *
JUNCTION BOARD ASSEMBLY <06>
!
REF. MODEL
GR-DVX88EG GR-DVX78A GR-DVX78A-S GR-DVX78EA
NO. ITEM
PW2 AUDIO BOARD ASSY YB10320C2-02 YB10320A2-02
R2201 MG RESISTOR — NRSA6AJ-103W
R2202 MG RESISTOR — NRSA6AJ-103W
R2203 MG RESISTOR — NRSA6AJ-473W
R2204 MG RESISTOR — NRSA6AJ-473W
C2108 T CAPACITOR NBE20JM-106X *NBE80JM-106X * *
C2207 T CAPACITOR NBE20JM-106X *NBE80JM-106X * *
C2208 T CAPACITOR NBE20JM-106X *NBE80JM-106X * *
C2211 T CAPACITOR NBE20JM-106X *NBE80JM-106X * *
C2214 T CAPACITOR NBE20JM-106X *NBE80JM-106X * *
C2223 CAPACITOR NCBA1AK-104W ———
C2224 CAPACITOR NCBA1AK-104W ———
C2301 T CAPACITOR NBE20JM-106X *NBE80JM-106X * *
C2402 T CAPACITOR NBE20JM-106X *NBE80JM-106X * *
C2751 T CAPACITOR NBE20JM-106X *NBE80JM-106X * *
AUDIO BOARD ASSEMBLY <08>
!
REF. MODEL
GR-DVX88EG GR-DVX78A GR-DVX78A-S GR-DVX78EA
NO. ITEM
PW1 JACK BOARD ASSY YB10323B1 *YB10323B1-01 * *
Q2801 TRANSISTOR — *2SD1979/S/-X * *
R2801 MG RESISTOR — *NRSA63J-103X * *
R2805 MG RESISTOR — *NRSA63J-0R0X * *
C2801 CAPACITOR — *NCB31CK-683X * *
C2803 CAPACITOR — *NCB31EK-153X * *
JACK BOARD ASSEMBLY <09>
3
