REFERENCES
EN 51
MasterPage: Ref_Heading0_Right
SPECIFICATIONS
Camcorder
Power supply
DC 11 V (Using AC Adapter)
DC 7.2 V (Using battery pack)
Power consumption
Approx. 3.1 W (3.8W*) (LCD monitor off, viewfinder on)
Approx. 3.9 W (4.6W*) (LCD monitor on, viewfinder off)
* Using LED Light
Dimensions (W x H x D)
52 mm x 93 mm x 94 mm
(with the LCD monitor closed and the viewfinder pushed
back in)
Weight
Approx. 430 g
(without cassette and battery)
Approx. 530 g
(incl. cassette and battery)
Operating temperature
0°C to 40°C
Operating humidity
35% to 80%
Storage temperature
–20°C to 50°C
Pickup
1/6" CCD
Lens
F 1.2, f = 2.6 mm to 31.2 mm, 12:1 power zoom lens
Filter diameter
ø27 mm
LCD monitor
3.0"*/2.5"** diagonally measured, LCD panel/TFT active
matrix system
* GR-DX97/57/48
** GR-DX77/67/37/28/27
Viewfinder
Electronic viewfinder with 0.3" colour LCD
Speaker
Monaural
LED Light
Effective distance: 1.5 m
Format
DV format (SD mode)
Signal format
PAL standard
Recording/Playback format
Video: Digital component recording
Audio: PCM digital recording, 32 kHz 4-channel (12-BIT),
48 kHz 2-channel (16-BIT)
Cassette
Mini DV cassette
Tape speed
SP: 18.8 mm/s, LP: 12.5 mm/s
Maximum recording time (using 80 min. cassette)
SP: 80 min., LP: 120 min.
Storage media
SD Memory Card/MultiMediaCard
Compression system
Still image: JPEG (compatible)
Moving image: MPEG4 (compatible)
File size
Still image:
2 modes (1024 x 768 pixels/640 x 480 pixels)
Moving image:
1 mode (160 x 120 pixels)
Picture quality
2 modes (FINE/STANDARD)
Approximate number of storable images
墌 pg. 21
AV
S-Video input (GR-DX97/77/57/37 only):
Y: 0.8 V to 1.2 V (p-p), 75 Ω, analogue
C: 0.2 V to 0.4 V (p-p), 75 Ω, analogue
S-Video output:
Y: 1.0 V (p-p), 75 Ω, analogue
C: 0.29 V (p-p), 75 Ω, analogue
Video input (GR-DX97/77/57/37 only): 0.8 V to 1.2 V (p-
p), 75 Ω, analogue
Video output: 1.0 V (p-p), 75 Ω, analogue
Audio input (GR-DX97/77/57/37 only): 300 mV (rms),
50 kΩ, analogue, stereo
Audio output: 300 mV (rms), 1 kΩ, analogue, stereo
Edit: ø3.5 mm, 2-pole
Microphone input
ø3.5 mm, stereo
DV
Input*/output: 4-pin, IEEE 1394 compliant
* GR-DX97/77/57/37 only
USB (except GR-DX27)
5-pin
AC Adapter
Power requirement
AC 110 V to 240 Vd, 50 Hz/60 Hz
Output
DC 11 V G, 1 A
Specifications shown are for SP mode unless otherwise
indicated. E & O.E. Design and specifications subject to
change without notice.
For General
For Digital Video Camera
For Digital Still Camera (GR-DX97/77/67 only)
For Connectors
GR-DX97PAL_09Spec.fm Page 51 Thursday, January 22, 2004 10:49 AM
