(No.YF034)3-7
2. PARTS LIST
PACKING AND ACCESSORY ASSEMBLY <M1>
FINAL ASSEMBLY <M2>
 Symbol No. Part No. Part Name Description Local
001 LY30023-003A POLY BAG
002 LY33819-001A PACKING CASE JVM B,C,D,E,F,H,J,K,L
002 LY33819-010A PACKING CASE JVM G
002 LY33819-011A PACKING CASE A
003 LY21227-001B CUSHION
004 QPA02503505P POLY BAG 25cm x 35cm
006 QAM0542-001 MULTI CABLE MULTI
008 QAM0572-001 AUDIO CABLE MIC
009 QQR0917-002 CORE FILTER MIC 2T
010 QAM0538-001 USB CABLE USB
011 QQR0491-002 FERRITE CORE USB 1T
 012 LY21104-012A AC ADAPTER L-ANGLE TYPE AP-V14E
 012 or LY21153-003A AC ADAPTER L-ANGLE TYPE AP-V15E
 014 QMPL270-190-JR POWER CORD(EK) CEE PULG 1.9m BLACK C,D,E,F,G,J,K,L
 014 QMPP210-190-JR POWER CORD(EK) BS PULG 1.9m BLACK A,B,H
015 QAM0302-001 ADAPTOR PLUG PERI-RCAS
016 LY21185-002A REMOTE CONTROL UNIT RM-V719U G
016 LY21186-002A REMOTE CONTROL UNIT RM-V720U A,B,C,D,E,F,H,J,K,L
 017 LY32203-003A BATTERY PACK ASSY BN-V107U-S
018 LY33772-001D HOOD CAP ASSY
019 QAM0515-001 RM CABLE EDIT EXT G
051 QPA02003506 POLY BAG DOCUMENT 20cm x 35cm C,D,E,F,G,J,K,L
051 YQM30061-3 POLY BAG DOCUMENT A,B,H
052 LY32210-081B CD ROM ASSY A,B,D,G,H,J
052 LY32210-082C CD ROM ASSY C,E,F,K,L
 053 LYT1246-001A INST BOOK(EN) (ENGLISH) A,B,H
 053 LYT1246-002A INST BOOK(GE) (GERMAN) D,E,J,K
 053 LYT1246-003A INST BOOK(FR) (FRENCH) D,J
 053 LYT1246-004A INST BOOK(DU) (DUTCH) D,J
 053 LYT1246-005A INST BOOK(SP) (SPANISH) D,J
 053 LYT1246-006A INST BOOK(IT) (ITALIAN) D,J
 053 LYT1246-007A INST BOOK(DA) (DANISH) E,K
 053 LYT1246-008A INST BOOK(FI) (FINN) E,K
 053 LYT1246-009A INST BOOK(SW) (SWEDISH) E,K
 053 LYT1246-010A INST BOOK(NO) (NORWEGIAN) E,K
 053 LYT1246-011A INST BOOK(RU) (RUSSIAN) C,F,L
 053 LYT1246-012A INST BOOK(CZ) (CZECH) F,L
 053 LYT1246-013A INST BOOK(PO) (POLISH) F,L
 053 LYT1246-014A INST BOOK(HU) (HUNGARIAN) F,L
 053 LYT1246-015A INST BOOK(PT) (PORTUGUESE) D,J
 053 LYT1248-001A INST BOOK(EN) (ENGLISH) G
054 LYT1247-001A INST BOOK(SOFT.EN) (SOFT.ENGLISH) A,B,G,H
054 LYT1247-002A INST BOOK(SOFT.GE) (SOFT.GERMAN) D,E,J,K
054 LYT1247-003A INST BOOK(SOFT.FR) (SOFT.FRENCH) D,J
054 LYT1247-004A INST BOOK(SOFT.DU) (SOFT.DUTCH) D,J
054 LYT1247-005A INST BOOK(SOFT.SP) (SOFT.SPANISH) D,J
054 LYT1247-006A INST BOOK(SOFT.IT) (SOFT.ITALIAN) D,J
054 LYT1247-007A INST BOOK(SOFT.DA) (SOFT.DANISH) E,K
054 LYT1247-008A INST BOOK(SOFT.FI) (SOFT.FINN) E,K
054 LYT1247-009A INST BOOK(SOFT.SW) (SOFT.SWEDISH) E,K
054 LYT1247-010A INST BOOK(SOFT.NO) (SOFT.NORWEGIAN) E,K
054 LYT1247-011A INST BOOK(SOFT.RU) (SOFT.RUSSIAN) C,F,L
054 LYT1247-018A INST BOOK(SOFT.PT) (SOFT.PORTUGUESE) D,J
055 ------------ WARRANTY CARD C,D,E,F,G,J,K,L
056 LYT0194-001B Q.CARD A,B,H
057 YU30878 REGIST. CARD A,B,H
058 BT-54008-6 GUARANTY CARD A,B,H
999 LY44670-001A SHEET
 Symbol No. Part No. Part Name Description Local
101 LY34147-001A BKT(MECHA)ASSY
101A LY42796-001A BUSH (x3)
102 LY30032-002A SPECIAL SCREW MECHA-BKT(x3)
103 LY34174-001A BKT(PRE-REC)
104 LY30031-015A SPECIAL SCREW BKTP/R-MEC
106 LY30031-015A SPECIAL SCREW MDAPWB-MEC(x2)
108 WJT0137-001B E-CARD WIRE FRONT-MAIN
109 LY34061-001A SHIELD COVER
110 LY30031-041A SPECIAL SCREW SH.P/R-M.B(x2)
111 LY30034-054A SPACER(A) SENSOR FPC
112 LY33959-001A BRACKET(OP)ASSY
112A LY42796-003A BUSH (x2)
113 LY30032-007A SPECIAL SCREW OP-OP BKT(x2)
114 LY30031-016A SPECIAL SCREW
OP/BKT-ARM(x2)
115 LY30032-007A SPECIAL SCREW ARM-OP
116 LY30031-016A SPECIAL SCREW VF-ARM(x3)
117 LY30031-016A SPECIAL SCREW M.BKT-ARM(x3)
119 WJT0143-001A E-CARD WIRE SD-MAIN
120 LY30031-016A SPECIAL SCREW SD PWB-ARM
121 LY30031-016A SPECIAL SCREW FRMUP-ARM(x5)
122 LY34230-001A BKT(TOP)ASSY JVM
122A LY44634-001A SPACER JVM
123 LY30031-016A SPECIAL SCREW BKTT1-ARM(x2)
124 LY30031-016A SPECIAL SCREW BKTT2-ARM(x2)
125 LY33785-001H REAR COVER ASSY(SD)
126 LY33787-001C CAMERA OPE UNIT
127 LY30031-016A SPECIAL SCREW REAR-ARM(x2)
128 LY21122-001G FRONT COVER ASSY JVM B,C,D,E,F,H,J,K,L
128 LY21122-007C FRONT COVER ASSY JVM G
128 LY21122-008C FRONT COVER ASSY JVM A
128A LY33763-001A RING
128B LY33764-001B HOOD
128C LY30031-039A SPECIAL SCREW (x3)
128D LY30034-077A SPACER(A)
129 LY33770-001B MIC ASSY
130 LY44631-001A BKT(MIC) ASSY JVM
130A LY30034-058A SPACER(A) JVM
131 LY30031-031A SPECIAL SCREW HOLDER-FRT(x2)
132 LY30031-016A SPECIAL SCREW FRONT-ARM(x5)
 133 LY33901-001F UPPER CASE ASSY
133A LY44602-001B SHEET(CAUTION)
133B LY42350-001A FOOT (x4)
134 LY33784-001A SUB OPE UNIT
135 LY30031-016A SPECIAL SCREW UPPR-FRMUP(x4)
136 LY33905-001C COVER(DV)ASSY
137 LY33776-001F SIDE COVER(L)ASSY
138 LY30031-016A SPECIAL SCREW SCOVL-FRM(x4)
139 LY30031-016A SPECIAL SCREW SCOVL-BKTT(x2)
141 LY30031-0E7A SPECIAL SCREW SCOVL-FRMU
142 LY21127-001B TOP COVER B,C,D,E,F,G,H,J,K,L
142 LY21127-004A TOP COVER A
143 LY30031-016A SPECIAL SCREW TPCOV-BKTT(x2)
144 LY21124-001B SIDE COVER(R)
145 LY30031-027A SPECIAL SCREW SCOVR-ARM
 146 LY33778-001F CASSETTE COVER ASSY
146A LY33779-001B KNOB(B.LOCK)
146B LY33780-001B HOLDER(B.LOCK)
146C LY44442-001A SPRING SHAFT
146D LY42350-001A FOOT (x2)
146E LY44600-001B TORSION SPRING
146F LY30031-002A SPECIAL SCREW
HOLDER-RCA(x2)
 146G LY34169-001A LABEL(C.COVER)
147 LY33782-001A HOOK(F)
148 LY30031-016A SPECIAL SCREW C.COV-ARM(x4)
149 LY30031-016A SPECIAL SCREW HOOK-ARM(x2)
150 LY30031-016A SPECIAL SCREW SCOVR-ARMF
151 LY30034-044A SPACER(A) OP FPC
152 LY44619-001A SPACER CCD PWB
201 LY44560-001A COVER(JIG CON)
202 LY30031-016A SPECIAL SCREW COVJIG-FRM
203 LY34157-001B COVER(ADJ)
204 LY30031-016A SPECIAL SCREW COVADJ-ARM
205 LY33907-001C JACK COVER ASSY
206 LY21225-001B GRIP BELT ASSY
207 LY40699-002A LABEL(PUSH)
208 LY32001-004A LABEL(HOUSING)
209 QAM0404-002 MEMORY CARD MMC 8MB*
210 LY34218-001B DUMMY BATTERY
212 LY30031-023A SPECIAL SCREW SCOV-FRONT
213 LY30034-060A SPACER(A) F-WINDOW
301 J3H-101A OP BLOCK ASSY
301A LY44455-001A J3H FOCUS MOTOR
301B LY44456-001A J3H ZOOM MOTOR
301C LY44457-001B J3H IRIS
301D QYSPSGU1430ZA TAP SCREW (x3)
301E LY44596-001A SPECIAL SCREW (x2)
 Symbol No. Part No. Part Name Description Local
MODEL MARK
A
B
C
D
GR-DX67EK
GR-DX77EK
GR-DX77ER
GR-DX77EX
MODEL MARK
E
F
G
H
GR-DX77EY
GR-DX77EZ
GR-DX78EX
GR-DX97EK
MODEL MARK
J
K
L
GR-DX97EX
GR-DX97EY
GR-DX97EZ
