JVC GR-DX77EK User Manual

(No.YF034)3-9
MONITOR ASSEMBLY <M5>
MAIN BOARD ASSEMBLY <01>
 Symbol No. Part No. Part Name Description Local
 800 MU04D32501E MONITOR UNIT ASSY JAPAN A,B,C,D,E,F,G
 800 MU04D33001E MONITOR UNIT ASSY JAPAN H,J,K,L
801 LY33795-001C HINGE UNIT ASSY
802 NSW0217-001X DETECT SWITCH
803 LY21191-001D MONITOR CASE(2.5) A,B,C,D,E,F,G
803 LY21130-001D MONITOR CASE(3) H,J,K,L
804 LY33793-001A LCD BKT 3 (1) H,J,K,L
804 LY33902-001A LCD BKT 2.5(1) A,B,C,D,E,F,G
805 QLD0314-001 LCD MODULE A,B,C,D,E,F,G
805 QLD0315-001 LCD MODULE H,J,K,L
806 LY33794-001A LCD BKT 3 (2) H,J,K,L
806 LY33903-001A LCD BKT 2.5(2) A,B,C,D,E,F,G
807 QLL0157-001 BACK LIGHT A,B,C,D,E,F,G
807 QLL0158-001 BACK LIGHT H,J,K,L
809 LY30031-041A SPECIAL SCREW MONPWB-BKT
 810 LY21131-001E MONITOR COVER ASSY
810A LY33790-001B MARK
810B LY30034-069A SPACER(A)
810C LY44620-001B STICKER
811 LY30031-013A SPECIAL SCREW MCOV-HINGE(x2)
812 LY30031-0E6A SPECIAL SCREW MCOV2-BKT(x2)
813 LY30031-0E5A SPECIAL SCREW MCOV1-FRM
814 LY33977-001C FRAME(UP)ASSY
814A LY30032-006A SPECIAL SCREW
814B LY33975-001A KNOB(MONI.LOCK)
814C LY44517-001B TORSION SPRING
814D LY30034-049A SPACER(A)
814E LY30034-057A SPACER(A)
814F LY30034-065A SPACER(A)
814G LY30034-070A SPACER(A)
815 LY30031-009A SPECIAL SCREW HING-FRMUP(x2)
816 LY21128-001C POWER(OPE)UNIT
817 LY30031-016A SPECIAL SCREW FRMUP-POWE(x2)
818 LY30031-005A SPECIAL SCREW FPC-FRMUP(x3)
 Symbol No. Part No. Part Name Description Local
PW1 YB10456B-03 MAIN BOARD ASSY A
PW1 YB10456A-03 MAIN BOARD ASSY B,C,D,E,F,G,H,J,K,L
IC1001 MN103S33NJY IC(MICRO C ROM) MASK A
IC1001 or MN103SF33NY4JY IC(MICRO C ROM) FLASH A
IC1001 MN103S33NJX IC(MICRO C ROM) MASK B,C,D,E,F,G,H,J,K,L
IC1001 or MN103SF33NY4JX IC(MICRO C ROM) FLASH B,C,D,E,F,G,H,J,K,L
IC1002 MB90097PFV153-X IC(MICRO C ROM) MB90099
IC1003 SN74AHC1G00K-X IC
IC1003 or SN74AHC1G00DC-X IC
IC1003 or 74HC1G00GW-X IC
IC1003 or MC74HC1G00DF-X IC
IC1004 NJU7108F3-X IC
IC1004 or TC75S56FU-X IC
IC1005 M95320-WDW6-X IC
IC1006 RS5C314-X IC
IC1007 IC-PST3423U-X IC
IC1007 or S-80823CNNB-X IC
IC1701 BA10358FVM-W IC REELAMP5V
IC1702 NJM2407R-W IC REELSMT
IC2101 AK4550VT-X IC
IC2201 AK4564VQ IC 48P0.5
IC3001 JCY0152 IC JCY0152
IC3006 JCY0177-W IC
IC3201 JCP8075 IC
IC3501 JCY0132 IC
IC3502 SN74AHC1G04K-X IC
IC3502 or SN74AHC1G04DC-X IC(DIGITAL)
IC3701 BH7612FV-X IC
IC3731 MM1504XN-X IC
B,C,D,E,F,G,H,J,K,L
IC4201 HD49340NP-X IC CDS/AD QFN
IC4202 MM1613AN-X IC REG 3V
IC4301 JCY0200 IC CAMERA DSP
IC4302 R1160N151B-X IC REG 1.5V
IC4701 NJM2143R-X IC
IC4701 or TA75W01FU-X IC
IC4702 NJM2143R-X IC
IC4702 or TA75W01FU-X IC
IC4703 NJM2143R-X IC
IC4703 or TA75W01FU-X IC
IC4704 NJM3414AV-X IC
IC4901 JCY0207 IC
IC4902 NJM3414AV-X IC
IC4951 AN41902A IC
IC5001 JCY0185 IC TG/VDR
IC6001 XC6202P33M-X IC
IC6002 R1224N102G-X IC
IC6101 FA3698F IC SW_REG IC
IC8001 TMS320DSC24GHKL IC DSC24
IC8002 K4S643233F-SE75 IC 64MSDRAM
IC8002 or K4S643233F-DE75 IC 64MSDRAM
IC8003 MR27T1602F19HLA IC(MICRO C ROM) OTP
IC8004 BU2360FV-X IC FS PLL
IC8301 ISP1181ABS IC USBQNF\2.6
Q1001 DTA114EM-X DIGI TRANSISTOR
Q1002 EMD3-W PAIR TRANSISTOR
Q1003 EMD3-W PAIR TRANSISTOR
Q1004 EMD3-W PAIR TRANSISTOR
Q1005 DTC143XM-X DIGI TRANSISTOR
Q1007 2SC5658/QRS/-X TRANSISTOR
Q1008 DTC124EM-X DIGI TRANSISTOR
Q1009 2SJ347-X MOS FET
Q1010 DTC144EM-X DIGI TRANSISTOR
Q1011 DTC143EM-X DIGI TRANSISTOR
Q1012 EMD3-W PAIR TRANSISTOR
Q2201 DTC144EE-X DIGI TRANSISTOR
Q2201 or UN9213J-X DIGI TRANSISTOR
Q2401 2SC5658/QRS/-X TRANSISTOR
Q2403 2SC5658/QRS/-X TRANSISTOR
Q2601 2SA2029/QRS/-X TRANSISTOR
Q2801 EMX1-W TRANSISTOR
Q3001 2SC5658/QRS/-X TRANSISTOR
Q3003 2SC5658/QRS/-X TRANSISTOR
Q3701 EMT1-W PAIR TRANSISTOR
Q3702 EMZ1-W PAIR TRANSISTOR
Q3704 2SA2029/QRS/-X TRANSISTOR
Q3705 EMT1-W PAIR TRANSISTOR
Q3706 DTC114EE-X DIGI TRANSISTOR B,C,D,E,F,G,H,J,K,L
Q3706 or UN9211J-X DIGI TRANSISTOR B,C,D,E,F,G,H,J,K,L
Q3707 DTC114EE-X DIGI TRANSISTOR B,C,D,E,F,G,H,J,K,L
Q3707 or UN9211J-X DIGI TRANSISTOR B,C,D,E,F,G,H,J,K,L
Q3731 2SC5658/QRS/-X TRANSISTOR B,C,D,E,F,G,H,J,K,L
Q3733 EMZ1-W PAIR TRANSISTOR B,C,D,E,F,G,H,J,K,L
Q3734 2SC5658/QRS/-X TRANSISTOR B,C,D,E,F,G,H,J,K,L
Q3735 EMZ1-W PAIR TRANSISTOR B,C,D,E,F,G,H,J,K,L
Q4701 2SC4655J/BC/-X TRANSISTOR
Q4951 DTC114EM-X DIGI TRANSISTOR
Q6001 QS6U24-W MOS FET
Q6201 QS6U24-W MOS FET
Q6202 2SA1577/RS/-X TRANSISTOR
Q6203 QS6U24-W MOS FET
Q6204 QS6U24-W MOS FET
Q6205 2SA1577/RS/-X TRANSISTOR
Q6206 DTC124TM-X DIGI TRANSISTOR
Q6207 QS6U24-W MOS FET
Q6208 QS6U24-W MOS FET
Q6209 SSM3J14T-X MOS FET
Q6210 2SC5658/QRS/-X TRANSISTOR
Q6211 2SC5658/QRS/-X TRANSISTOR
Q6212 EMZ1-W PAIR TRANSISTOR
Q6213 SSM3J14T-X MOS FET
Q6214 2SK3019-X MOS FET
Q6701 SSM3J14T-X MOS FET
Q8001 2SA1774/RS/-X TRANSISTOR 2SA1774
Q8001 or 2SB1462J/RS/-X TRANSISTOR
D1001 DA221-X DIODE ARRAY
D1001 or MA133-X SI DIODE
D3001 EC2C01C-TR-X VARI CAP DIODE
D3002 EC2C01C-TR-X VARI CAP DIODE
 Symbol No. Part No. Part Name Description Local
MODEL MARK
A
B
C
D
GR-DX67EK
GR-DX77EK
GR-DX77ER
GR-DX77EX
MODEL MARK
E
F
G
H
GR-DX77EY
GR-DX77EZ
GR-DX78EX
GR-DX97EK
MODEL MARK
J
K
L
GR-DX97EX
GR-DX97EY
GR-DX97EZ
