(No.YF034)3-11

C3050 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3055 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3064 NCBA1HK-102W C CAPACITOR 1000pF 50V K

C3077 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C3078 NCB30JK-105X C CAPACITOR 1uF 6.3V K

C3079 NBZ0015-106X TA E CAPACITOR 10uF 6.3V M

C3080 NCBA1HK-102W C CAPACITOR 1000pF 50V K

C3201 NBZ0015-106X TA E CAPACITOR 10uF 6.3V M

C3202 NCB21AK-105X C CAPACITOR 1uF 10V K

C3203 NCB21AK-105X C CAPACITOR 1uF 10V K

C3204 NBZ0015-106X TA E CAPACITOR 10uF 6.3V M

C3205 NBE20GM-476X TA E CAPACITOR 47uF 4V M

C3206 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3207 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3208 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3209 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3210 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3211 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3212 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3213 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3214 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3215 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3216 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C3217 NCB30JK-105X C CAPACITOR 1uF 6.3V K

C3218 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C3219 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C3220 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C3221 NCB30JK-105X C CAPACITOR 1uF 6.3V K

C3222 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C3223 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C3224 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C3225 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C3226 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C3227 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3228 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3229 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3230 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3231 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3232 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3233 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3234 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3235 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3236 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3237 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3240 NDCA1HJ-101W C CAPACITOR 100pF 50V J

B,C,D,E,F,G,H,J,K,L

C3501 NBZ0015-106X TA E CAPACITOR 10uF 6.3V M

C3502 NBZ0015-106X TA E CAPACITOR 10uF 6.3V M

C3503 NBZ0015-106X TA E CAPACITOR 10uF 6.3V M

C3504 NCBA1AK-473W C CAPACITOR 0.047uF 10V K

C3505 NCBA1CK-223W C CAPACITOR 0.022uF 16V K

C3506 NCJA0JK-105W-A C CAPACITOR 1uF 6.3V K

C3507 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3508 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3509 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3510 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C3511 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3512 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C3513 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C3514 NCBA1AK-473W C CAPACITOR 0.047uF 10V K

C3515 NCBA1AK-473W C CAPACITOR 0.047uF 10V K

C3516 NCBA1AK-473W C CAPACITOR 0.047uF 10V K

C3517 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3518 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3519 NCBA1HK-102W C CAPACITOR 1000pF 50V K

C3520 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3521 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C3522 NCB20JM-475X C CAPACITOR 4.7uF 6.3V M

C3523 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3524 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3525 NCB20JM-475X C CAPACITOR 4.7uF 6.3V M

C3526 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3527 NDCA1EJ-221W C CAPACITOR 220pF 25V J

C3528 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3701 NBZ0015-106X TA E CAPACITOR 10uF 6.3V M

C3706 NCJA0JK-105W-A C CAPACITOR 1uF 6.3V K

C3707 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3708 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C3709 NCBA1CK-103W C CAPACITOR 0.01uF 16V K



Symbol No.

Part No. Part Name Description Local

C3710 NBE90GM-226X TA E CAPACITOR 22uF 4V M

C3711 NBE90GM-226X TA E CAPACITOR 22uF 4V M

C3712 NBE20GM-107X TA E CAPACITOR 100uF 4V M

C3713 NBE20GM-107X TA E CAPACITOR 100uF 4V M

C3715 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C3731 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

B,C,D,E,F,G,H,J,K,L

C3732 NCBA1HK-102W C CAPACITOR 1000pF 50V K

B,C,D,E,F,G,H,J,K,L

C3733 NDCA1HJ-3R0W C CAPACITOR 3pF 50V J

B,C,D,E,F,G,H,J,K,L

C3734 NDCA1HJ-5R0W C CAPACITOR 5pF 50V J

B,C,D,E,F,G,H,J,K,L

C3735 NDCA1HJ-330W C CAPACITOR 33pF 50V J

B,C,D,E,F,G,H,J,K,L

C3736 NCBA1HK-102W C CAPACITOR 1000pF 50V K

B,C,D,E,F,G,H,J,K,L

C3738 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

B,C,D,E,F,G,H,J,K,L

C3739 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

B,C,D,E,F,G,H,J,K,L

C3740 NCJA0JK-105W-A C CAPACITOR 1uF 6.3V K

B,C,D,E,F,G,H,J,K,L

C3741 NCJA0JK-105W-A C CAPACITOR 1uF 6.3V K

B,C,D,E,F,G,H,J,K,L

C3742 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

B,C,D,E,F,G,H,J,K,L

C3743 NDCA1HJ-3R0W C CAPACITOR 3pF 50V J

B,C,D,E,F,G,H,J,K,L

C3744 NDCA1HJ-5R0W C CAPACITOR 5pF 50V J

B,C,D,E,F,G,H,J,K,L

C3745 NDCA1HJ-330W C CAPACITOR 33pF 50V J

B,C,D,E,F,G,H,J,K,L

C3746 NCB20JM-475X C CAPACITOR 4.7uF 6.3V M

B,C,D,E,F,G,H,J,K,L

C3747 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

B,C,D,E,F,G,H,J,K,L

C4201 NBE20GM-476X TA E CAPACITOR 47uF 4V M

C4202 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4203 NCB30JK-105X C CAPACITOR 1uF 6.3V K

C4204 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4205 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4206 NCB21CK-105X C CAPACITOR 1uF 16V K

C4207 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4208 NCB30JK-105X C CAPACITOR 1uF 6.3V K

C4209 NCBA1CK-223W C CAPACITOR 0.022uF 16V K

C4210 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4211 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4212 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4213 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4214 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4215 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4216 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4217 NCB30JK-105X C CAPACITOR 1uF 6.3V K

C4218 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4219 NBE20GM-476X TA E CAPACITOR 47uF 4V M

C4301 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4302 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4303 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4304 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4305 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4306 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4307 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4308 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4309 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4310 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4311 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4312 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4313 NBZ0015-106X TA E CAPACITOR 10uF 6.3V M

C4314 NCBA1AK-104W C CAPACITOR 0.1uF 10V K

C4315 NBZ0015-106X TA E CAPACITOR 10uF 6.3V M

C4316 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C4317 NBZ0015-106X TA E CAPACITOR 10uF 6.3V M

C4701 NBZ0015-106X TA E CAPACITOR 10uF 6.3V M

C4702 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z

C4703 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z

C4704 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z

C4705 NCB30JK-105X C CAPACITOR 1uF 6.3V K

C4707 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z

C4708 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C4709 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z

C4710 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z

C4711 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z

C4901 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z

C4902 NBZ0015-106X TA E CAPACITOR 10uF 6.3V M

C4903 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z

C4904 NBZ0015-106X TA E CAPACITOR 10uF 6.3V M

C4905 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z

C4906 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z

C4907 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z

C4908 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z

C4909 NCBA1CK-103W C CAPACITOR 0.01uF 16V K

C4911 NDCA1HJ-680W C CAPACITOR 68pF 50V J

C4912 NCFA1AZ-104W C CAPACITOR 0.1uF 10V Z



Symbol No.

Part No. Part Name Description Local

MODEL MARK

GR-DX67EK

GR-DX77EK

GR-DX77ER

GR-DX77EX

MODEL MARK

GR-DX77EY

GR-DX77EZ

GR-DX78EX

GR-DX97EK

MODEL MARK

GR-DX97EX

GR-DX97EY

GR-DX97EZ
