(No.YF034)3-13
R1035 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R1037 NRSA6AJ-561W MG RESISTOR 560
Ω
1/16W J
R1039 NRSA6AJ-152W MG RESISTOR 1.5k
Ω
1/16W J
R1041 NRSA6AJ-682W MG RESISTOR 6.8k
Ω
1/16W J
R1042 NRSA6AJ-223W MG RESISTOR 22k
Ω
1/16W J
R1043 NRSA6AJ-104W MG RESISTOR 100k
Ω
1/16W J
R1044 NRSA6AJ-104W MG RESISTOR 100k
Ω
1/16W J
R1045 NRSA6AJ-105W MG RESISTOR 1M
Ω
1/16W J
R1046 NRSA6AJ-104W MG RESISTOR 100k
Ω
1/16W J
R1047 NRSA6AJ-104W MG RESISTOR 100k
Ω
1/16W J
R1048 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R1049 NRSA6AJ-623W MG RESISTOR 62k
Ω
1/16W J
R1050 NRSA6AJ-823W MG RESISTOR 82k
Ω
1/16W J
R1051 NRSA6AJ-473W MG RESISTOR 47k
Ω
1/16W J
R1052 NRSA6AJ-104W MG RESISTOR 100k
Ω
1/16W J
R1053 NRSA6AJ-222W MG RESISTOR 2.2k
Ω
1/16W J
R1054 NRSA6AJ-104W MG RESISTOR 100k
Ω
1/16W J
R1055 NRSA6AJ-334W MG RESISTOR 330k
Ω
1/16W J
R1056 NRSA6AJ-334W MG RESISTOR 330k
Ω
1/16W J
R1057 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R1058 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R1059 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R1060 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R1061 NRSA6AJ-561W MG RESISTOR 560
Ω
1/16W J
R1062 NRSA6AJ-224W MG RESISTOR 220k
Ω
1/16W J
R1065 NRSA6AJ-153W MG RESISTOR 15k
Ω
1/16W J
R1067 NRSA6AJ-334W MG RESISTOR 330k
Ω
1/16W J
R1068 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R1069 NRSA6AJ-104W MG RESISTOR 100k
Ω
1/16W J
R1070 NRSA6AJ-154W MG RESISTOR 150k
Ω
1/16W J
R1071 NRSA6AJ-272W MG RESISTOR 2.7k
Ω
1/16W J
R1072 NRSA6AJ-183W MG RESISTOR 18k
Ω
1/16W J
R1073 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R1074 NRSA6AJ-472W MG RESISTOR 4.7k
Ω
1/16W J
R1075 NRSA6AJ-473W MG RESISTOR 47k
Ω
1/16W J
R1076 NRSA6AJ-473W MG RESISTOR 47k
Ω
1/16W J
R1077 NRSA6AJ-104W MG RESISTOR 100k
Ω
1/16W J
R1078 NRSA6AJ-393W MG RESISTOR 39k
Ω
1/16W J
R1079 NRSA6AJ-223W MG RESISTOR 22k
Ω
1/16W J
R1080 NRSA6AJ-822W MG RESISTOR 8.2k
Ω
1/16W J
R1081 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R1082 NRSA6AJ-123W MG RESISTOR 12k
Ω
1/16W J
R1083 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R1084 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R1085 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R1086 NRSA6AJ-332W MG RESISTOR 3.3k
Ω
1/16W J
R1087 NRSA6AJ-332W MG RESISTOR 3.3k
Ω
1/16W J
R1088 NRSA6AJ-332W MG RESISTOR 3.3k
Ω
1/16W J
R1089 NRSA6AJ-332W MG RESISTOR 3.3k
Ω
1/16W J
R1090 NRSA6AJ-682W MG RESISTOR 6.8k
Ω
1/16W J
R1091 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R1092 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R1093 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R1094 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R1095 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R1097 NRSA6AJ-104W MG RESISTOR 100k
Ω
1/16W J
R1098 NRSA6AJ-223W MG RESISTOR 22k
Ω
1/16W J
R1701 NRSA6AJ-823W MG RESISTOR 82k
Ω
1/16W J
R1702 NRSA6AJ-222W MG RESISTOR 2.2k
Ω
1/16W J
R1703 NRSA6AJ-222W MG RESISTOR 2.2k
Ω
1/16W J
R1704 NRSA6AJ-222W MG RESISTOR 2.2k
Ω
1/16W J
R1705 NRSA6AJ-222W MG RESISTOR 2.2k
Ω
1/16W J
R1706 NRSA6AJ-823W MG RESISTOR 82k
Ω
1/16W J
R1707 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R1708 NRSA6AJ-124W MG RESISTOR 120k
Ω
1/16W J
R1709 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R1710 NRSA6AJ-124W MG RESISTOR 120k
Ω
1/16W J
R1711 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R1712 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R1713 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
R2101 NRSA6AJ-471W MG RESISTOR 470
Ω
1/16W J
R2102 NRSA6AJ-471W MG RESISTOR 470
Ω
1/16W J
R2103 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R2201 NRSA6AJ-224W MG RESISTOR 220k
Ω
1/16W J
R2202 NRSA6AJ-564W MG RESISTOR 560k
Ω
1/16W J
R2203 NRSA6AJ-393W MG RESISTOR 39k
Ω
1/16W J
R2204 NRSA6AJ-154W MG RESISTOR 150k
Ω
1/16W J
R2206 NRSA6AJ-333W MG RESISTOR 33k
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
R2207 NRSA6AJ-333W MG RESISTOR 33k
Ω
1/16W J
R2208 NRSA6AJ-223W MG RESISTOR 22k
Ω
1/16W J
R2209 NRSA6AJ-223W MG RESISTOR 22k
Ω
1/16W J
R2212 NRSA6AJ-2R7W MG RESISTOR 2.7
Ω
1/16W J
R2213 NRSA6AJ-2R7W MG RESISTOR 2.7
Ω
1/16W J
R2217 NRSA6AJ-100W MG RESISTOR 10
Ω
1/16W J
R2225 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R2226 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R2227 NRSA6AJ-822W MG RESISTOR 8.2k
Ω
1/16W J
R2228 NRSA6AJ-822W MG RESISTOR 8.2k
Ω
1/16W J
R2229 NRSA6AJ-333W MG RESISTOR 33k
Ω
1/16W J
R2230 NRSA6AJ-333W MG RESISTOR 33k
Ω
1/16W J
R2231 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R2401 NRSA6AJ-472W MG RESISTOR 4.7k
Ω
1/16W J
R2402 NRSA6AJ-472W MG RESISTOR 4.7k
Ω
1/16W J
R2407 NRSA6AJ-100W MG RESISTOR 10
Ω
1/16W J
R2601 NRSA6AJ-222W MG RESISTOR 2.2k
Ω
1/16W J
R2602 NRSA6AJ-222W MG RESISTOR 2.2k
Ω
1/16W J
R2604 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R2605 NRSA6AJ-332W MG RESISTOR 3.3k
Ω
1/16W J
R2607 NRSA6AJ-223W MG RESISTOR 22k
Ω
1/16W J
R2608 NRSA6AJ-223W MG RESISTOR 22k
Ω
1/16W J
R2609 NRSA6AJ-334W MG RESISTOR 330k
Ω
1/16W J
R2610 NRSA6AJ-334W MG RESISTOR 330k
Ω
1/16W J
R2611 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R2612 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R2613 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R2614 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R2615 NRSA6AJ-334W MG RESISTOR 330k
Ω
1/16W J
R2616 NRSA6AJ-334W MG RESISTOR 330k
Ω
1/16W J
R2801 NRSA6AJ-821W MG RESISTOR 820
Ω
1/16W J
R2802 NRSA6AJ-821W MG RESISTOR 820
Ω
1/16W J
R2803 NRSA6AJ-564W MG RESISTOR 560k
Ω
1/16W J
R2804 NRSA6AJ-564W MG RESISTOR 560k
Ω
1/16W J
R2805 NRSA6AJ-332W MG RESISTOR 3.3k
Ω
1/16W J
R2806 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R2807 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R2808 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R2809 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R3002 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R3004 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R3005 NRSA6AJ-100W MG RESISTOR 10
Ω
1/16W J
R3006 NRSA6AJ-100W MG RESISTOR 10
Ω
1/16W J
R3007 NRSA6AJ-562W MG RESISTOR 5.6k
Ω
1/16W J
R3008 NRSA6AJ-222W MG RESISTOR 2.2k
Ω
1/16W J
R3009 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R3010 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R3011 NRSA6AJ-224W MG RESISTOR 220k
Ω
1/16W J
R3013 NRSA6AJ-242W MG RESISTOR 2.4k
Ω
1/16W J
R3014 NRSA6AJ-392W MG RESISTOR 3.9k
Ω
1/16W J
R3015 NRSA6AJ-392W MG RESISTOR 3.9k
Ω
1/16W J
R3016 NRVA6AD-560W CMF RESISTOR 56
Ω
1/16W D
R3017 NRVA6AD-560W CMF RESISTOR 56
Ω
1/16W D
R3018 NRVA6AD-560W CMF RESISTOR 56
Ω
1/16W D
R3019 NRVA6AD-560W CMF RESISTOR 56
Ω
1/16W D
R3020 NRVA6AD-512W CMF RESISTOR 5.1k
Ω
1/16W D
R3021 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R3025 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R3027 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R3029 NRSA6AJ-822W MG RESISTOR 8.2k
Ω
1/16W J
R3030 NRSA6AJ-224W MG RESISTOR 220k
Ω
1/16W J
R3031 NRSA6AJ-224W MG RESISTOR 220k
Ω
1/16W J
R3032 NRSA6AJ-105W MG RESISTOR 1M
Ω
1/16W J
R3034 NRSA6AJ-222W MG RESISTOR 2.2k
Ω
1/16W J
R3036 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R3037 NRSA6AJ-681W MG RESISTOR 680
Ω
1/16W J
R3038 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R3042 NRSA6AJ-823W MG RESISTOR 82k
Ω
1/16W J
R3043 NRSA6AJ-123W MG RESISTOR 12k
Ω
1/16W J
R3044 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R3046 NRSA6AJ-181W MG RESISTOR 180
Ω
1/16W J
R3047 NRSA6AJ-472W MG RESISTOR 4.7k
Ω
1/16W J
R3049 NRSA6AJ-561W MG RESISTOR 560
Ω
1/16W J
R3050 NRSA6AJ-561W MG RESISTOR 560
Ω
1/16W J
R3053 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R3057 NRSA6AJ-151W MG RESISTOR 150
Ω
1/16W J
R3071 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R3077 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
MODEL MARK
A
B
C
D
GR-DX67EK
GR-DX77EK
GR-DX77ER
GR-DX77EX
MODEL MARK
E
F
G
H
GR-DX77EY
GR-DX77EZ
GR-DX78EX
GR-DX97EK
MODEL MARK
J
K
L
GR-DX97EX
GR-DX97EY
GR-DX97EZ
