(No.YF034)3-15
R4951 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R4952 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R4953 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R4954 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R4955 NRSA6AJ-101W MG RESISTOR 100
Ω
1/16W J
R4956 NRSA6AJ-4R7W MG RESISTOR 4.7
Ω
1/16W J
R4957 NRSA6AJ-4R7W MG RESISTOR 4.7
Ω
1/16W J
R4958 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R4959 NRSA6AJ-4R7W MG RESISTOR 4.7
Ω
1/16W J
R4960 NRSA6AJ-4R7W MG RESISTOR 4.7
Ω
1/16W J
R4961 NRSA6AJ-271W MG RESISTOR 270
Ω
1/16W J
R4962 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R4963 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R4964 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R4965 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R5001 NRSA6AJ-104W MG RESISTOR 100k
Ω
1/16W J
R5003 NRSA6AJ-220W MG RESISTOR 22
Ω
1/16W J
R5004 NRSA6AJ-220W MG RESISTOR 22
Ω
1/16W J
R5005 NRSA6AJ-220W MG RESISTOR 22
Ω
1/16W J
R5006 NRSA6AJ-100W MG RESISTOR 10
Ω
1/16W J
R5007 NRSA6AJ-100W MG RESISTOR 10
Ω
1/16W J
R5008 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R5009 NRSA6AJ-470W MG RESISTOR 47
Ω
1/16W J
R5011 NRSA6AJ-470W MG RESISTOR 47
Ω
1/16W J
R5012 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R5013 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R5014 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R6001 NRSA6AJ-224W MG RESISTOR 220k
Ω
1/16W J
R6002 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R6003 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R6005 NRSA6AD-513W MG RESISTOR 51k
Ω
1/16W D
R6006 NRSA6AD-243W MG RESISTOR 24k
Ω
1/16W D
R6101 NRSA6AD-103W MG RESISTOR 10k
Ω
1/16W D
R6102 NRSA6AJ-751W MG RESISTOR 750
Ω
1/16W J
R6103 NRSA6AD-622W MG RESISTOR 6.2k
Ω
1/16W D
R6104 NRSA6AJ-333W MG RESISTOR 33k
Ω
1/16W J
R6105 NRSA6AJ-562W MG RESISTOR 5.6k
Ω
1/16W J
R6106 NRSA6AJ-223W MG RESISTOR 22k
Ω
1/16W J
R6107 NRSA6AJ-472W MG RESISTOR 4.7k
Ω
1/16W J
R6108 NRSA6AJ-823W MG RESISTOR 82k
Ω
1/16W J
R6109 NRSA6AJ-823W MG RESISTOR 82k
Ω
1/16W J
R6110 NRSA6AD-153W MG RESISTOR 15k
Ω
1/16W D
R6112 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R6113 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R6202 NRSA6AD-223W MG RESISTOR 22k
Ω
1/16W D
R6204 NRSA6AD-822W MG RESISTOR 8.2k
Ω
1/16W D
R6205 NRSA6AJ-473W MG RESISTOR 47k
Ω
1/16W J
R6206 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R6207 NRSA6AD-183W MG RESISTOR 18k
Ω
1/16W D
R6208 NRSA6AD-123W MG RESISTOR 12k
Ω
1/16W D
R6210 NRSA6AD-123W MG RESISTOR 12k
Ω
1/16W D
R6211 NRSA6AD-153W MG RESISTOR 15k
Ω
1/16W D
R6213 NRSA6AD-183W MG RESISTOR 18k
Ω
1/16W D
R6215 NRSA6AD-472W MG RESISTOR 4.7k
Ω
1/16W D
R6216 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R6217 NRSA6AJ-152W MG RESISTOR 1.5k
Ω
1/16W J
R6219 NRSA6AD-243W MG RESISTOR 24k
Ω
1/16W D
R6220 NRSA6AD-302W MG RESISTOR 3k
Ω
1/16W D
R6221 NRSA6AD-104W MG RESISTOR 100k
Ω
1/16W D
R6222 NRSA6AD-123W MG RESISTOR 12k
Ω
1/16W D
R6223 NRSA6AD-103W MG RESISTOR 10k
Ω
1/16W D
R6225 NRSA6AD-473W MG RESISTOR 47k
Ω
1/16W D
R6226 NRSA6AD-562W MG RESISTOR 5.6k
Ω
1/16W D
R6227 NRSA6AD-273W MG RESISTOR 27k
Ω
1/16W D
R6228 NRSA6AD-473W MG RESISTOR 47k
Ω
1/16W D
R6229 NRSA6AJ-272W MG RESISTOR 2.7k
Ω
1/16W J
R6230 NRSA6AD-473W MG RESISTOR 47k
Ω
1/16W D
R6231 NRSA6AD-332W MG RESISTOR 3.3k
Ω
1/16W D
R6232 NRSA6AD-123W MG RESISTOR 12k
Ω
1/16W D
R6233 NRSA6AD-203W MG RESISTOR 20k
Ω
1/16W D
R6234 NRSA6AJ-101W MG RESISTOR 100
Ω
1/16W J
R6235 NRSA6AJ-222W MG RESISTOR 2.2k
Ω
1/16W J
R6236 NRSA6AD-563W MG RESISTOR 56k
Ω
1/16W D
R6237 NRSA6AD-473W MG RESISTOR 47k
Ω
1/16W D
R6238 NRSA6AJ-104W MG RESISTOR 100k
Ω
1/16W J
R6239 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R6701 NRV142F-R20X CMF RESISTOR 0.2
Ω
1/4W F
R6702 NRSA6AD-104W MG RESISTOR 100k
Ω
1/16W D
Symbol No.
Part No. Part Name Description Local
R6703 NRSA6AD-123W MG RESISTOR 12k
Ω
1/16W D
R6704 NRSA6AD-823W MG RESISTOR 82k
Ω
1/16W D
R6705 NRSA6AD-333W MG RESISTOR 33k
Ω
1/16W D
R6706 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R8002 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R8005 NRSA6AJ-220W MG RESISTOR 22
Ω
1/16W J
R8007 NRSA6AJ-102W MG RESISTOR 1k
Ω
1/16W J
R8008 NRSA6AJ-561W MG RESISTOR 560
Ω
1/16W J
R8009 NRSA6AJ-105W MG RESISTOR 1M
Ω
1/16W J
R8011 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R8012 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R8016 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R8017 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R8019 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R8021 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R8022 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R8023 NRSA6AJ-472W MG RESISTOR 4.7k
Ω
1/16W J
R8025 NRSA6AJ-472W MG RESISTOR 4.7k
Ω
1/16W J
R8027 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R8028 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R8029 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R8030 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R8031 NRSA6AJ-100W MG RESISTOR 10
Ω
1/16W J
R8032 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R8033 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R8036 NRSA6AJ-220W MG RESISTOR 22
Ω
1/16W J
R8037 NRSA6AJ-221W MG RESISTOR 220
Ω
1/16W J
R8041 NRSA6AJ-220W MG RESISTOR 22
Ω
1/16W J
R8042 NRSA6AJ-220W MG RESISTOR 22
Ω
1/16W J
R8302 NRS181J-220X MG RESISTOR 22
Ω
1/8W J
R8303 NRS181J-220X MG RESISTOR 22
Ω
1/8W J
R8306 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R8307 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R8308 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R8309 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R8310 NRSA6AJ-153W MG RESISTOR 15k
Ω
1/16W J
R8313 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
R8314 NRSA6AJ-105W MG RESISTOR 1M
Ω
1/16W J
R8315 NRSA6AJ-105W MG RESISTOR 1M
Ω
1/16W J
R8316 NRSA6AJ-104W MG RESISTOR 100k
Ω
1/16W J
R8317 NRSA6AJ-154W MG RESISTOR 150k
Ω
1/16W J
RA1001 NRZ0034-473W NET RESISTOR 47k
Ω
1/32W J
RA1002 NRZ0034-104W NET RESISTOR 100k
Ω
1/32W J
RA1003 NRZ0034-104W NET RESISTOR 100k
Ω
1/32W J
RA1004 NRZ0034-104W NET RESISTOR 100k
Ω
1/32W J
RA1005 NRZ0034-103W NET RESISTOR 10k
Ω
1/32W J
RA1006 NRZ0034-102W NET RESISTOR 1k
Ω
1/32W J
RA1007 NRZ0034-102W NET RESISTOR 1k
Ω
1/32W J
RA1008 NRZ0034-104W NET RESISTOR 100k
Ω
1/32W J
RA3001 NRZ0034-560W NET RESISTOR 56
Ω
1/32W J
RA3002 NRZ0034-560W NET RESISTOR 56
Ω
1/32W J
RA3003 NRZ0034-100W NET RESISTOR 10
Ω
1/32W J
RA3004 NRZ0034-103W NET RESISTOR 10k
Ω
1/32W J
RA3005 NRZ0040-0R0X NET RESISTOR 0
Ω
1/16W J
RA3201 NRZ0034-101W NET RESISTOR 100
Ω
1/32W J
RA3202 NRZ0034-101W NET RESISTOR 100
Ω
1/32W J
RA4201 NRZ0034-100W NET RESISTOR 10
Ω
1/32W J
RA4202 NRZ0034-100W NET RESISTOR 10
Ω
1/32W J
RA4301 NRZ0034-101W NET RESISTOR 100
Ω
1/32W J
RA4302 NRZ0034-101W NET RESISTOR 100
Ω
1/32W J
RA4303 NRZ0034-101W NET RESISTOR 100
Ω
1/32W J
RA4304 NRZ0034-101W NET RESISTOR 100
Ω
1/32W J
RA4305 NRZ0034-100W NET RESISTOR 10
Ω
1/32W J
RA4306 NRZ0034-100W NET RESISTOR 10
Ω
1/32W J
RA4307 NRZ0034-100W NET RESISTOR 10
Ω
1/32W J
RA4308 NRZ0034-100W NET RESISTOR 10
Ω
1/32W J
RA8001 NRZ0034-101W NET RESISTOR 100
Ω
1/32W J
RA8002 NRZ0034-101W NET RESISTOR 100
Ω
1/32W J
RA8003 NRZ0034-101W NET RESISTOR 100
Ω
1/32W J
RA8004 NRZ0034-101W NET RESISTOR 100
Ω
1/32W J
L1001 NQL402M-100X COIL 10uH M
L1002 NQL402M-100X COIL 10uH M
L2101 NQL402M-100X COIL 10uH M
L2401 NQL402M-100X COIL 10uH M
L2402 NQL402M-100X COIL 10uH M
L2601 NQR0269-013X FERRITE BEADS
L2602 NQR0269-013X FERRITE BEADS
Symbol No.
Part No. Part Name Description Local
MODEL MARK
A
B
C
D
GR-DX67EK
GR-DX77EK
GR-DX77ER
GR-DX77EX
MODEL MARK
E
F
G
H
GR-DX77EY
GR-DX77EZ
GR-DX78EX
GR-DX97EK
MODEL MARK
J
K
L
GR-DX97EX
GR-DX97EY
GR-DX97EZ
