1 • MENU Wheel [–, +] ................................ pg. 18
• BRIGHT Wheel [–, +]*
1
........................... pg. 11
• Speaker Volume Control [VOL.]*
1
........... pg. 11
• TRACKING Wheel [–, +] ........................ pg. 14
2 • Snapshot Button [SNAPSHOT]*
2
........... pg. 12
• 5-Second Recording Button
[5 SEC. REC]*
3
...................................... pg. 12
3 Power Zoom Lever [T/W] ......................... pg. 13
4 • Manual Focus Button [ FOCUS] ........ pg. 12
• Time Base Corrector Button [TBC] ........ pg. 14
5 S-Video Output Connector [S]*
2
.............. pg. 15
6 Audio Output Connector [A] ..................... pg. 15
7 Video Output Connector [V] ..................... pg. 15
8 Battery Release Switch
[BATTERY RELEASE] ............................... pg. 6
9 DC IN Connector ....................................... pg. 6
0 Recording Start/Stop Button ..................... pg. 11
! Lock Button ............................................... pg. 11
@ Power Switch [ , OFF, , ] ........... pg. 11
# Video Light Button [LIGHT]*
4
................... pg. 13
$ POWER Lamp ........................................... pg. 6
% Digital Effect Button [DIGIFECT] ............. pg. 24
^ Programme AE Button [P.AE] .................. pg. 24
& Play/Pause Button .................................... pg. 11
* • Retake Forward Button [RETAKE F] ..... pg. 13
• Fast-Forward Button [F] .......................... pg. 11
( EJECT Switch ............................................ pg. 8
) CHARGE Lamp ......................................... pg. 6
q • REFRESH Button .................................... pg. 6
• NIGHT Button*
2
...................................... pg. 23
w • Fade/Wipe Button [FADE/WIPE] ........... pg. 23
• Counter Reset/Memory Button
[COUNTER R/M] ................................... pg. 14
e • Retake Rewind Button [RETAKE R] ...... pg. 13
• Quick Review Button [ R] ................. pg. 13
• Rewind Button [R] ................................... pg. 11
r • Stop Button [STOP] ................................ pg. 11
• Backlight Compensation Button
[BACK LIGHT] ....................................... pg. 12
t Shoulder Strap Eyelets .............................. pg. 8
y Battery Pack Mount ................................... pg. 6
u Close Button .............................................. pg. 8
i Dioptre Adjustment Control ........................ pg. 8
o Camera Sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
p Grip Strap .................................................. pg. 8
Q Tripod Mounting Socket ............................. pg. 8
W Tape Remaining Time .............................. pg. 21
E Recording Mode Indicator ....................... pg. 20
R Video Light Indicator*
4
............................. pg. 13
T Backlight Compensation Indicator ........... pg. 12
Y Recording Format Indicator (S/S-ET)*
2
... pg. 20
U • Digital Effect Indicator ............................ pg. 24
• Programme AE Indicator ....................... pg. 24
• Night-Scope Indicator*
2
.......................... pg. 23
• Fade/Wipe-Standby Indicator ................ pg. 23
I Tape Length Indicator .............................. pg. 21
O Zoom Indicator Bar .................................. pg. 13
Zoom Level Indicator
Approximate Zoom Ratio
P Recording Indicator .................................. pg. 11
a Digital Effect Indicator .............................. pg. 24
s • Programme AE Indicator ....................... pg. 24
• Night-Scope Indicator*
2
.......................... pg. 23
d Fade/Wipe-Standby Indicator .................. pg. 23
f Picture Stabiliser Indicator ....................... pg. 18
g • Interval Time/Recording Time Indicator .... pg. 21
• 5 Sec. Rec Mode Indicator*
3
.................. pg. 12
h Instant Title Display ................................. pg. 19
j Date/Time Display ................................... pg. 21
k Bright Level Indicator*
1
....................... pg. 11, 22
l Focus Indicator ........................................ pg. 12
; Exposure Control Level Counter ............. pg. 18
A White Balance Mode Indicator ................. pg. 19
S S-VHS/S-VHS ET Recording
Indicator*
2
................................................ pg. 20
D Record-Standby Mode Indicator ............... pg. 11
F : Cassette Indicator ............................. pg. 8
G TBC Indicator ........................................... pg. 14
H Playback Special Effect Indicator*
2
.......... pg. 14
J Recording Format Indicator (S/S-ET)*
2
... pg. 20
K Tape Counter ........................................... pg. 14
L Recording Mode Indicator (SP/LP) .......... pg. 20
: Tape Running Indicator
4
: Playback
3
: Fast-Forward/Shuttle Search
2
: Rewind/Shuttle Search
6 : Pause
z Tracking Indicator .................................... pg. 14
x • BRIGHT: Bright Level Indicator*
1
............ pg. 11
• VOLUME: Speaker Volume Indicator*
1
.... pg. 11
*
1
Applicable models only.
*
2
GR-SXM50/SX26 only.
*
3
GR-FXM404/FXM40/FX16 only.
*
4
GR-SXM50/FXM404/SX26 only.
01 GR-SXM50EX_EN 10/29/03, 11:36 AM10
