36 EN
PLAYBACK
Advanced Connections
Connection To A Personal
Computer
This camcorder can transfer still images to a PC by using
the provided software when connected as shown in the
illustration (GR-DVL507 only).
It is also possible to transfer still images to a PC with a DV
connector-equipped capture board installed.
1
Make sure the camcorder and PC are turned off.
2
Connect the camcorder to your PC using the
appropriate cable as shown in the illustration.
3
Turn the camcorder’s Power Switch to “ ” while
pressing down the Lock Button located on the switch
and turn on the PC.
NOTES:
●
It is recommended to use the AC Power Adapter/
Charger as the power supply instead of the battery pack
(
pg. 9).
●
For GR-DVL507 Owners: Never connect the PC
connection cable and the DV cable simultaneously to
the camcorder. Connect only the cable you wish to use
to the camcorder.
●
The date/time information cannot be captured into the
PC.
●
Refer to the instruction manuals of the provided
Software.
●
Also refer to the manufacturer’s instruction manual for
the DV connector-equipped capture board.
●
When using a DV cable, be sure it has a core filter
attached. The core filter reduces interference.
To DV
IN/OUT
To
RS-232C
DV cable
(optional)
To DV
connector
PC connection
cable (provided*)
To PC
(DIGITAL
PHOTO)*
Power Switch
PC with DV
connector-equipped
capture board
PC
Core filter
Connector
cover
* GR-DVL507 only
Core filter
