JVC GR GR-DVL307

EN71
For Connectors
S :Y:1 V ( p-p ) , 75 Ω, analog output
C : 0.29 V ( p-p ) , 75 Ω, analog output
AV
Video output :1 V ( p-p ) , 75 Ω, analog
Audio output : 300 mV (rms), 1 kΩ, analog, stereo
DV
Input/output : 4-pin, IEEE 1394 compliant
PC (DIGITAL PHOTO)
Digital still output : ø2.5 mm, 3-pole
(GR-DVL507 only)
JLIP/EDIT : ø3.5 mm, 4-pole
AC Power Adapter/Charger AA-V40U
Power requirement
U.S.A. and Canada : AC 120 V`, 60 Hz
Other countries : AC 110 V to 240 V`, 50 Hz/60 Hz
Power consumption : 23 W
Output
Charge : DC 7.2 V , 1.2 A
VTR : DC 6.3 V , 1.8 A
Dimensions (W x H x D) : 68 mm x 38 mm x 110 mm (2-11/16" x 1-1/2" x 4-3/8")
Weight : Approx. 250 g (0.56 lbs)
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject
to change without notice.
