JVC GR-SX150AS Service Manual

2
PACKING AND ACCESSORY ASSEMBLY <M1>
The following table indicate different parts number between models GR-SX25EX ,GR-SX150AS and GR-SX250AS.
!
REF.
MODEL
GR-SX25EX GR-SX150AS GR-SX250AS
No.
ITEM
1PACKING CASE LY33071-002B LY33073-012A LY33073-006A
2 CUSHION LY33075-001B LY33075-001A
! 5 INST BOOK(GERMAN) LYT1060-002C — —
! 5 INST BOOK(FRENCH) LYT1060-003C — —
! 5 INST BOOK(DUTCH) LYT1060-004C — —
! 5 INST BOOK(SPANISH) LYT1060-005C — —
! 5 INST BOOK(ITALIAN) LYT1060-006C — —
! 5 INST BOOK(ENGLISH) — LYT1063-001A
! 5 INST BOOK(CHINESE) — LYT1063-002A
! 5 INST BOOK(RUSSIAN) — LYT1063-003A
! 5 INST BOOK(ARABIC) — LYT1063-004A
8WARRANTY CARD BT-54013-5 — —
! 10 BATTERY PACK ASSY YQ10629E YQ10376AM
11 CONNECTOR PEMC1174 — —
! 14 AC ADAPTER LY20955-001C LY20955-002A
! 14 AC ADAPTER LY20956-001B — —
16 S CABLE QAM0004-003 — —
! 17 POWER CORD QMPL120-190-JR QMPS110-190-JR
! 18 CONVERSION PLUG — PEMC1012
! 20 SHEET(CON.PLUG) — LYT0609-001A
21 C.ADAPTER ASSY — YQ31963B-3
22 POLY BAG — YQ43446
23 BATTERY — AA(R6)
24 SPACER(PACKING) — LY44181-001A
25 REMOTE CTL UNIT — — LY42129-001A
26 BATTERY,X2 — — AAA(R03)
FINAL ASSEMBLY <M2>
!
REF.
MODEL
GR-SX25EX GR-SX150AS GR-SX250AS
No.
ITEM
101 C.COVER(S)ASSY LY20928-001D LY20928-005C LY20928-002C
101A P.PLATE(S) LY32959-001A LY32959-002A LY32959-001A
101F STICKER(C) LY44007-001A LY44007-002A
101H STICKER(B) LY43982-001A LY43982-002A LY43982-001A
102 TAP SCREW QYSLSF20D0R QYSLSF20D0D QYSLSF20D0R
104 UPPER CASE(S)ASSY LY20954-001D LY20954-002B LY20954-001B
121 LOWER CASE ASSY LY20925-002C LY20925-004C LY20925-002C
! 135 F.COVER ASSY LY20926-001C LY20926-004C LY20926-001C
135B RING LY32949-001A LY32949-002A LY32949-001A
135D STICKER(A) LY43983-001A LY43983-002A LY43983-001A
! 135E CAUTION LABEL LY44141-001A — LY44141-001A
135G COVER(LIGHT) — LY32965-002A —
137 DC LIGHT LY33067-001A — LY33067-001A
138 MIC LY32981-001A LY32981-002A LY32981-001A
145 FRAME ASSY LY20949-001B LY20949-001C
157 TOP OPE UNIT LY10392-001C LY10392-004B LY10392-001B
161 SPACER(A) LY30030-072A — —
MAIN BOARD ASSEMBLY <01>
!
REF.
MODEL
GR-SX25EX GR-SX150AS GR-SX250AS
No.
ITEM
PW1 MAIN BOARD ASSY YB10400EB1-02 YB10400EG1-02 YB10400EF1-02
IC1801 IR DETECT UNIT — — RPM7138
IC4002 IC(DIGITAL) MSM548331TA — MSM548331TA
Q6306 MOS FET 2SK3577-X — 2SK3577-X
C4024 C CAPACITOR NCF31EZ-104X — NCF31EZ-104X
C4044 C CAPACITOR NCB30JK-105X — NCB30JK-105X
C6307 E CAPACITOR NEA71CM-106X — NEA71CM-106X
R4013 MG RESISTOR NRSA63J-102X — NRSA63J-102X
R4036 MG RESISTOR NRSA63J-101X — NRSA63J-101X
R6306 MG RESISTOR NRSA63J-0R0X — NRSA63J-0R0X
R6307 MG RESISTOR NRSA63J-104X — NRSA63J-104X
R6314 MG RESISTOR NRS12BK-R47W — NRS12BK-R47W
CN6 CONNECTOR QGA1201C2-02X — QGA1201C2-02X
OT2 #500SPACER0.01 PU59915-105 — —
Notes : Mark is same as left.
Mark — is not used.
