JVC GR-SX150AS Service Manual

3
PACKING AND ACCESSORY ASSEMBLY <M1>
!
REF.
MODEL
GR-SXM49EX GR-SXM190AS GR-SXM290AS GR-SXM590AS
No.
ITEM
1PACKING CASE LY33071-001B LY33073-009A LY33073-003A LY33073-015A
2 CUSHION LY33075-001B LY33075-001A LY33075-001B
! 5 INST BOOK(GERMAN) LYT1060-002C — — —
! 5 INST BOOK(FRENCH) LYT1060-003C — — —
! 5 INST BOOK(DUTCH) LYT1060-004C — — —
! 5 INST BOOK(SPANISH) LYT1060-005C — — —
! 5 INST BOOK(ITALIAN) LYT1060-006C — — —
! 5 INST BOOK(ENGLISH) — LYT1063-001A
! 5 INST BOOK(CHINESE) — LYT1063-002A
! 5 INST BOOK(RUSSIAN) — LYT1063-003A
! 5 INST BOOK(ARABIC) — LYT1063-004A
8WARRANTY CARD BT-54013-5 — — —
! 10 BATTERY PACK ASSY YQ10629E YQ10376AM
11 CONNECTOR PEMC1174 — — —
! 14 AC ADAPTER LY20955-001C LY20955-002A
! 14 AC ADAPTER LY20956-001B — — —
16 S CABLE QAM0004-003 — — —
! 17 POWER CORD QMPL120-190-JR QMPS110-190-JR
! 18 CONVERSION PLUG — PEMC1012
! 20 SHEET(CON.PLUG) — LYT0609-001A
21 C.ADAPTER ASSY — YQ31963B-3
22 POLY BAG — YQ43446
23 BATTERY — AA(R6)
24 SPACER(PACKING) — LY44181-001A —
25 REMOTE CTL UNIT — — LY42129-001A
26 BATTERY,X2 — — AAA(R03)
Notes : Mark is same as left.
Mark — is not used.
The following table indicate different parts number between models GR-SXM49EX, GR-SXM190AS, GR-SXM290AS and
GR-SXM590AS.
FINAL ASSEMBLY <M2>
!
REF.
MODEL
GR-SXM49EX GR-SXM190AS GR-SXM290AS GR-SXM590AS
No.
ITEM
101 C.COVER(M)ASSY LY20927-002C LY20927-005C LY20927-004B LY20927-004C
101B LABEL(CAUTION) LY44124-001B LY44124-001A LY44124-001B
101F STICKER(C) LY44007-001A LY44007-002A
103 COV.(UPPER/M)ASSY LY33068-001C LY33068-002B LY33068-001B LY33068-001C
121 LOWER CASE ASSY LY20925-001D LY20925-003C LY20925-001C LY20925-001E
! 135 F.COVER ASSY LY20926-001C LY20926-004C LY20926-001C LY20926-001D
135B RING LY32949-001A LY32949-002A LY32949-001A
135D STICKER(A) LY43983-001A LY43983-002A LY43983-001A
! 135E CAUTION LABEL LY44141-001A — LY44141-001A
135G COVER(LIGHT) — LY32965-002A — —
137 DC LIGHT LY33067-001A — LY33067-001A
138 MIC LY32981-001A LY32981-002A LY32981-001A
145 FRAME ASSY LY20949-001B LY20949-001C LY20949-001D
157 TOP OPE UNIT LY10392-001C LY10392-004B LY10392-001B LY10392-001C
158 REAR BOARD ASSY LY20952-001C LY20952-001D
161 SPACER(A) LY30030-072A — — LY30030-072A
MONITOR ASSEMBLY <M5>
!
REF.
MODEL
GR-SXM49EX GR-SXM190AS GR-SXM290AS GR-SXM590AS
No.
ITEM
! 500 MONITOR ASSY LY20947-001A LY20947-004A LY20947-001A LY20947-006A
! 501 M.COVER ASSY/M.COVER(3.5)ASSY LY33066-001A LY33066-004A LY33066-001A LY33359-001C
501A STICKER(B) LY43982-001A LY43982-002A LY43982-001A
502 M.CASE ASSY/M.CASE(3.5)ASSY LY33077-001B LY21022-001B
502D SPACER(A) — — — LY30030-089A
503 MON.HINGE ASSY LY33005-001B LY33005-002B LY33005-001B LY33005-004B
504 LEVER SWITCH/PUSH SWITCH NSW0200-001X NSW0194-001X NSW0200-001X
505 WASHER LY44159-001A —LY44159-001A
506 S.CASE(2.5)/S.CASE(3.5) LY20814-001A LY32960-001B
507 LCD FRAME(2.5)/LCD FRAME(3.5) LY20798-001B LY32961-001A
509 LCD MODULE QLD0248-001 QLD0212-001
510 LIGHT SCREEN LY43938-001A —
511 LAMP QLL0142-001 —
512 HOLDER(LAMP),X2 LY43936-001A —
513 SHEET(REFLECT) LY43396-001A —
514 DIFF.SHEET(2.5) LY43362-001A —
516 TAP SCREW,X2/SPECIAL SCREW,X2 QYSLSF2060D LY30018-0F2A
521 BACK LIGHT — — — QLL0127-001
523 SPACER(A) — — — LY30030-091A
