EN55
Controls
1 Dioptre Adjustment Control ................. pg. 14
2 Lens Cover Open/Close Ring................ pg. 16
3 Video Light Switch
[LIGHT OFF/AUTO/ON]
(GR-SXM460A/SXM260A/
SXM46EA/SXM26EA only) ................... pg. 20
4 •Snapshot Button [SNAPSHOT]
(GR-SXM460A/SXM46EA only) .......... pg. 21
•5-Second Recording Button [5 SEC. REC]
(GR-SXM260A/SX210A/
SXM26EA/SX21EA only) .................... pg. 19
5 •Power Zoom Lever [T/W] .................. pg. 18
•Speaker Volume Control [VOL.]
(GR-SXM460A/SXM260A/
SXM46EA/SXM26EA only) ................. pg. 33
6 •Picture Stabiliser Button
[P.STABILIZER] .................................. pg. 18
•Time Base Corrector Button ............... pg. 34
7 Programme AE Button [P.AE] ................ pg. 23
8 Fade/Wipe Button [EFFECT] ................. pg. 22
9 •Retake Rewind Button [RETAKE R] ..... pg. 19
•Quick Review Button [ R] ............. pg. 19
•Rewind Button [REW] ....................... pg. 33
0 •Retake Forward Button [RETAKE F] .... pg. 19
•Fast-Forward Button [FF] ................... pg. 33
! Stop Button [STOP] .............................. pg. 33
@ Play/Pause Button [PLAY/PAUSE] ......... pg. 33
# •Select Wheel [PUSH] ........................ pg. 24
•Bright Dial [BRIGHT]
(GR-SXM460A/SXM260A/
SXM46EA/SXM26EA only) ............. pg. 16, 33
$ MENU/DISPLAY Button ................. pg. 17, 24
% •Recording Mode Button [SP/LP] ......... pg. 10
•Counter Reset/Memory Button
[COUNTER R/M] .............................. pg. 34
^ EJECT Switch ....................................... pg. 11
& Recording Start/Stop Button .................. pg. 16
* Power Switch
[ , OFF, AUTO, PRO.] .............. pg. 16, 33
( Battery Release Switch
[BATTERY RELEASE] .............................. pg. 7
) Close Button ........................................ pg. 11
Connectors
q DC IN Connector................................... pg. 7
The connectors w to t are located beneath the
cover.
w Video Output Connector ...................... pg. 36
e Audio Output Connector ..................... pg. 36
r S-Video Output Connector ................... pg. 36
t J Terminal [JLIP (Joint Level Interface Protocol)
Connector]
•Connect the editing cable when performing
Random Assemble Editing ( pg. 44 – 47).
•It is used to connect the camcorder to a device
such as a personal computer.
For further details consult your nearest JVC
dealer.
•JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with a
J terminal.
Indicators
y Power Lamp ........................................ pg. 16
Other Parts
u Battery Pack Mount ............................... pg. 7
i Viewfinder ........................................... pg. 14
o Grip Strap ............................................ pg. 14
p •Camera sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
•Remote Sensor .................................. pg. 40
Q Video Light
(GR-SXM460A/SXM260A/
SXM46EA/SXM26EA only) ................... pg. 20
W Microphone ......................................... pg. 43
E Eyepiece
R Speaker
(GR-SXM460A/SXM260A/
SXM46EA/SXM26EA only) ................... pg. 33
T LCD Monitor
(GR-SXM460A/SXM260A/
SXM46EA/SXM26EA only) ................... pg. 17
Y Shoulder Strap Eyelets .......................... pg. 15
U Clock Battery Slot .................................. pg. 8
I Tripod Mounting Socket ....................... pg. 15
To Next Page
