JVC GR-SX210A - SPECIFICATIONS; Camcorder General Specifications; Component Specifications

58 EN
SPECIFICATIONS
Camcorder
General
Format : S-VHS/VHS PAL standard
Power source : DC 6.0 V
Power consumption
LCD monitor* off, viewfinder on : 4.2 W (GR-SXM460A/SXM260A/SXM46EA/SXM26EA)
3.7 W (GR-SX210A/SX21EA)
LCD monitor* on, viewfinder off : 4.6 W (GR-SXM460A/SXM260A/SXM46EA/SXM26EA)
LCD monitor* on, viewfinder on : 5.2 W (GR-SXM460A/SXM260A/SXM46EA/SXM26EA)
Video light* : 3.0 W
* GR-SXM460A/SXM260A/SXM46EA/SXM26EA only.
Signal system : PAL-type
Video recording system
Luminance : FM recording
Colour : Converted sub-carrier direct recording
Conforms to VHS standard
Cassette : / cassette
Tape speed
SP : 23.39 mm/sec.
LP : 11.70 mm/sec.
Recording time (max.)
SP : 60 minutes
LP : 120 minutes (with EC-60 cassette)
Operating temperature :0°C to 40°C
Operating humidity : 35% to 80%
Storage temperature : –20°C to 50°C
Weight : Approx. 980 g (GR-SXM460A/SXM46EA)
Approx. 970 g (GR-SXM260A/SXM26EA)
Approx. 830 g (GR-SX210A/SX21EA)
Dimensions (W x H x D) : 198 mm x 119 mm x 99 mm (GR-SXM460A/SXM260A/SXM46EA/
SXM26EA)
198 mm x 119 mm x 91 mm (GR-SX210A/SX21EA)
(with the LCD monitor* closed and with the viewfinder fully tilted
downward)
* GR-SXM460A/SXM260A/SXM46EA/SXM26EA only.
Pickup : 1/4" format CCD
Lens : F1.6, f = 3.9 mm to 62.4 mm, 16:1 power zoom lens with auto iris and
macro control, filter diameter 40.5 mm
Viewfinder : Electronic viewfinder with 0.5" black/white CRT
White balance adjustment : Auto/Manual adjustment
LCD monitor : 3" diagonally measured, LCD panel/TFT active matrix system
(GR-SXM460A/SXM46EA)
2.5" diagonally measured, LCD panel/TFT active matrix system
(GR-SXM260A/SXM26EA)
Speaker : Monaural
(GR-SXM460A/SXM260A/
SXM46EA/SXM26EA only)
(GR-SXM460A/SXM260A/
SXM46EA/SXM26EA only)
