• MENU Wheel [–, +] ........................................... pg. 18
• BRIGHT Wheel [–, +]*
1
...................................... pg. 11
• TRACKING Wheel [–, +] ................................... pg. 14
2
• Snapshot Button [SNAPSHOT]*
2
...................... pg. 12
• 5-Second Recording Button
[5 SEC. REC]*
3
................................................. pg. 12
3
• Power Zoom Lever [T/W] .................................. pg. 13
• Speaker Volume Control [VOL.]*
1
...................... pg. 11
4
• Picture Stabiliser Button
[P.STABILIZER] ................................................
pg. 12
• Time Base Corrector Button [TBC] ...................
pg. 14
5
S-Video Output Connectors [S] ..................... pg. 15, 27
6
Audio Output Connector [A] .......................... pg. 15, 27
7
Video Output Connector [V] .......................... pg. 15, 27
8
Battery Release Switch
[BATTERY RELEASE] ..........................................
pg. 6
9
DC IN Connector .................................................. pg. 6
0
• Digital Connector [DIGITAL]*
4
• Edit Connector [EDIT]*
6
.................................... pg. 27
!
Recording Start/Stop Button ................................ pg. 11
@
Power Switch [ , OFF, , ] .................... pg. 11
#
Video Light Switch
[LIGHT OFF/AUTO/ON]*
2
................................... pg. 13
$
Stop Button [STOP] ............................................. pg. 11
%
• Retake Rewind Button [RETAKE R] ................. pg. 13
• Quick Review Button [
R] ............................ pg. 13
• Rewind Button [R] ..............................................
pg. 11
^
Play/Pause Button ............................................... pg. 11
&
• Retake Forward Button [RETAKE F] ................ pg. 13
• Fast-Forward Button [F] .....................................
pg. 11
*
CHARGE Lamp .................................................... pg. 6
(
REFRESH Lamp ................................................... pg. 6
)
• Fade/Wipe Button [FADE/WIPE] ...................... pg. 22
• Counter Reset/Memory Button
[COUNTER R/M] ..............................................
pg. 14
q
Programme AE Button [P.AE] ............................. pg. 23
w
Digital Effect Button [DIGIFECT] ......................... pg. 23
e
NIGHT-SCOPE Button*
2
..................................... pg. 22
r
REFRESH Button ................................................. pg. 6
t
EJECT Switch ....................................................... pg. 8
y
Shoulder Strap Eyelets ......................................... pg. 8
u
Battery Pack Mount ............................................... pg. 6
i
Close Button ......................................................... pg. 8
o
Dioptre Adjustment Control ................................... pg. 8
p
• Camera Sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
• Remote Sensor*
5
.......................................... pg. 9, 17
Q
Grip Strap ............................................................. pg. 8
W
Tripod Mounting Socket ........................................ pg. 8
E
Infrared Beam Transmitting Window ............... pg. 9, 17
R
ZOOM (T/W) Buttons .................................... pg. 13, 25
T
PLAY Button ......................................................... pg. 11
Y
REW Button (Functions the same as
%
)
U
STOP Button (Functions the same as
$
)
I
INSERT Button ................................................... pg. 25
O
• REC TIME Button ............................................. pg. 25
• ANIM. Button .................................................... pg. 25
P
START/STOP Button (Functions the same as
!
)
a
FF Button (Functions the same as
&
)
s
PAUSE Button ...................................................... pg. 11
d
A.DUB Button ...................................................... pg. 25
f
• INT.TIME Button ............................................... pg. 25
• SELF TIMER Button (non-functional)
1
Tape Remaining Time ......................................... pg. 21
2
Recording Mode Indicator ................................... pg. 20
3
• Digital Effect Indicator ....................................... pg. 23
• Programme AE Indicator ...................................
pg. 23
• Night-Scope Indicator*
2
..................................... pg. 22
• Fade/Wipe-Standby Indicator ...........................
pg. 22
4
Recording Format Indicator (S/S-ET) ................. pg. 20
5
Tape Length Indicator ......................................... pg. 21
6
Zoom Indicator Bar ............................................. pg. 13
Zoom Level Indicator
Approximate Zoom Ratio
7
Recording Indicator .............................................. pg. 11
8
Digital Effect Indicator ......................................... pg. 23
9
• Programme AE Indicator ................................... pg. 23
• Night-Scope Indicator*
2
..................................... pg. 22
0
Fade/Wipe-Standby Indicator ............................. pg. 22
!
Picture Stabiliser Indicator .................................. pg. 12
@
• Interval Time/Recording Time Indicator ............... pg. 21
• 5 Sec. Rec Mode Indicator*
3
............................. pg. 12
#
Bright Level Indicator*
1
......................................... pg. 11
$
Instant Title Display ............................................. pg. 19
%
Date/Time Display ............................................... pg. 19
^
Focus Indicator ................................................... pg. 18
&
Exposure Control Level Counter ......................... pg. 18
*
White Balance Mode Indicator ............................ pg. 19
(
S-VHS/S-VHS ET Recording
Indicator ..............................................................
pg. 20
)
Record-Standby Mode Indicator .......................... pg. 11
q
• : Cassette Indicator ...................................... pg. 8
• w: Insert Editing Indicator*
5
.............................. pg. 25
w
TBC Indicator ...................................................... pg. 14
e
Playback Special Effect Indicator*
2
..................... pg. 14
r
Recording Format Indicator (S/S-ET) ................. pg. 20
t
Tape Counter ................................................ pg. 14, 25
y
Recording Mode Indicator (SP/LP) ..................... pg. 20
u
Tape Running Indicator
4
: Playback
3
: Fast-Forward/Shuttle Search
2
: Rewind/Shuttle Search
6 : Pause
e
4
: Audio Dubbing*
5
i
Tracking Indicator ............................................... pg. 14
o
Tape Counter*
5
.................................................... pg. 25
p
• BRIGHT: Bright Level Indicator*
1
....................... pg. 11
• VOLUME: Speaker Volume Indicator*
1
............... pg. 11
*
1
Applicable models only.
*
2
GR-SXM78EA/SXM48EA/SXM780A/SXM480A/SXM280A
only.
*
3
GR-SXM180A/SX140A only.
*
4
GR-SXM78EA/SXM780A only.
*
5
GR-SXM78EA/SXM780A/SXM480A/SXM280A only.
*
6
GR-SXM480A/SXM280A only.
